DMS Seals hydraulic oil seal wholesale

Company Advantages
1. In the selection of raw materials, DMS Seals is paid 100% attention. Our quality team adopts the highest standard for the selection of raw materials and thus ensures the high quality of the product.
2. The adoption of advanced equipment and the lean production method make DMS Seals hydraulic oil seal more cost-effective.
3. DMS Seals is innovative with an improvement on production process.
4. The product responds quickly in a short period of time. It can run high-performance control programs with fast processing and no latency.
5. This product has the characteristics of high efficiency. It produces the expected results in the shortest amount of time without any serious errors.
6. This product has high light color accuracy. It is able to make the thing being illuminated look the same as its original color.
7. This product is highly resistant to bacteria. Its edges and joints have minimal gaps, which provides an effective barrier to prevent bacteria.
8. This product contains no toxic substances. Made of environmentally-friendly materials, it is free of benzene and formaldehyde harmful substances.
9. The product does not give off clicking sounds intermittently after being used for an extended amount of time, which brings the quiet enjoyment for people.
10. The product has been widely regarded as a high-performance sealing material since it can be used under extreme operating working conditions.
11. People can handle the product by recycling it for designated institutions to reduce pollution on water, land, and air.
12. Being less likely to wrinkle, this product tends to be an easier care option. And it is machine-washable to accommodate a busy lifestyle.

1. Installation Recommendation

2. Application and properties

Suitable for long stroke, a wide range of fluids and high temperature occasions. The application of heavy duty double acting piston sealing under high pressure conditions is excellent. Applicable to larger piston clearance , it has good leakage control, extrusion resistance and wear resistance in heavy duty and construction machinery cylinder piston sealing system. Good static sealing property, simple groove structure, larger extrusion clearances can be allowed, be able to work in dusty condition.

3. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM

Back-up ring: POM / PA

4. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
50 - 350mm	0 - 50MPa	-30℃ +100℃	1.5 m/s	hydraulic oil, flame retardant liquid, water and others

5. Installation Dimensions

Nominal Size of Packing, and Housing dimensions			L+0.2	Order No.
D1	dN	H
50 55 60	36 41 46	8.5 8.5 8.5	9 9 9	SPGW50*36*8.5 SPGW55*41*8.5 SPGW60*46*8.5
63 65 70	48 50 55	10.5 10.5 10.5	11 11 11	SPGW63*48*10.5 SPGW65*50*10.5 SPGW70*55*10.5
75 80 85	60 65 70	10.5 10.5 10.5	11 11 11	SPGW75*60*10.5 SPGW80*65*10.5 SPGW85*70*10.5
90 95 100	75 80 85	10.5 10.5 12	11 11 12.5	SPGW90*75*10.5 SPGW95*80*10.5 SPGW100*85*12
105 110 115	90 95 100	12 12 12	12.5 12.5 12.5	SPGW105*90*12 SPGW110*95*12 SPGW115*100*12
120 125 130	105 102 107	12 15.5 15.5	12.5 16 16	SPGW120*105*12 SPGW125*102*15.5 SPGW130*107*15.5
135 140 145	112 117 122	15.5 15.5 15.5	16 16 16	SPGW135*112*15.5 SPGW140*117*15.5 SPGW145*122*15.5
150 155 160	127 132 137	15.5 15.5 15.5	16 16 16	SPGW150*127*15.5 SPGW155*132*15.5 SPGW160*137*15.5
165 170 180	142 147 157	15.5 15.5 15.5	16 16 16	SPGW165*142*15.5 SPGW170*147*15.5 SPGW180*157*15.5
185 190 200	162 167 177	15.5 15.5 15.5	16 16 16	SPGW185*162*15.5 SPGW190*167*15.5 SPGW200*177*15.5
210 220 225	187 197 202	15.5 15.5 17	16 16 17.5	SPGW210*187*15.5 SPGW220*197*15.5 SPGW225*202*15.5
230 240 250	207 217 222	17 17 17	17.5 17.5 17.5	SPGW230*207*15.5 SPGW240*217*15.5 SPGW250*222*17
260 270 280	232 242 252	17 17 17	17.5 17.5 17.5	SPGW260*232*17 SPGW270*242*17 SPGW280*252*17
300 320 350	272 292 322	17 17 17	17.5 17.5 17.5	SPGW300*272*17 SPGW320*292*17 SPGW350*322*17

Company Features
1. Dms Seals Technology Co.,limited is one of point key enterprises in Chinese profession's hydraulic oil seal industry. Dms Seals Technology Co.,limited is the backbone enterprise of the domestic mechanical seal selection manufacturing industry. Excellent shaft seals for pumps and perfect service make DMS Seals the most popular star in the rubber seal molding market. DMS Seals is more and more mature in the development and operation of mechanical seal buyer . While expanding the scale of , DMS Seals actively expands the varieties of mechanical seals pune production.
2. We have both developed the domestic and international markets. Our broad business partners or clients, especially those in Australia, America, and Europe, have helped us seize numerous chances to achieve better business results. Our products goes all over the world. We have clients spread across the globe in countries such as North America, Germany, China, Korea, and Singapore. People are at the core of our company. They use their industry insights, a comprehensive portfolio of activities, and digital resources to create products that enable businesses to thrive.
3. Our values are service excellence, flexibility, and creativity. We will equip our company with all the resources and talents to excel in areas of quality, service, and innovation competitiveness. Our commitment to our customers is to be the best and most flexible supplier with the ability to adapt to changing market needs. Call! Our company's goal is to bridge the gap between the client's vision and a beautifully crafted product ready to market. Call!
