Best hydraulic cylinder seal design company for light and medium hydraulic systems

Company Advantages
1. The design of hydraulic cylinder seal design is in compliance with the regulations of .
2. With features of and , hydraulic cylinder seal design is the best choice for you.
3. It is hydraulic cylinder seal design that makes it more reliable.
4. According to the specific customers requirements, we offer a wide range of hydraulic cylinder seal design in various sizes, and etc.
5. Dms Seals Technology Co.,limited can offer customers all kinds of hydraulic cylinder seal design with different sizes and colors.
6. This product is known for its moisture resistance. It has a specially coated surface, which allows it to stand up to seasonal changes in humidity.
7. This product is free of bacteria. Its surface has been added with an antimicrobial agent that can inhibit the ability of microorganisms to grow.
8. This product is free of tip-over hazards. Thanks to its strong and stable construction, it is not prone to wobble in any situation.
9. It showcases products in an aesthetically pleasing way. It appeals to customers, thus bringing sales and profit success.
10. People can be assured that it can offer them effective power solution with its safe and reliable electricity performance with large capacity.
11. The product is in high demand among people's life or work. It has been widely used for residential, commercial and industrial.

1. Installation Recommendation

2. Installation Sizes

Bore Diameter                         DN H9			Groove Diameter	Groove Width	Radius	Radial Clearance                S max.			O-Ring Cross-Section
Standard Application	Light Application	Heavy Duty Application	d1 h9	L1+0.2	R1	10MPa	20MPa	40MPa	d2
8-14.9	15-39.9	-	DN-4.9	2.2	0.4	0.3	0.20	0.15	1.78
15-39.9	40-79.9	-	DN-7.5	3.2	0.6	0.4	0.25	0.15	2.62
40-79.9	80-132.9	15-39.9	DN-11.0	4.2	1.0	0.4	0.25	0.20	3.53
80-132.9	133-329.9	40-79.9	DN-15.5	6.3	1.3	0.5	0.30	0.20	5.33
133-329.9	330-699.9	80-132.9	DN-21.0	8.1	1.8	0.6	0.35	0.25	7.00
330-669.9	670-99.9	133-329.9	DN-24.5	8.1	1.8	0.6	0.35	0.25	7.00
670-999.9	≥1000	330-669.9	DN-28.0	9.5	2.5	0.7	0.50	0.30	8.40
≥1000	≥1000	≥1000	DN-38.0	13.8	3.0	1.0	0.70	0.60	12.00

3. Application and properties

Standard double acting seal. Suitable for reciprocating motion, allowing larger extrusion clearances, has wide application. Dynamic and static sealing property are excellent, be able to work in dusty condition. Low friction, simple groove, strong adaptability to work conditions.

4. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM

5. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3 - 1600mm	0 - 60MPa	-45℃ +200℃	15 m/s	hydraulic oil, flame retardant liquid, water and others

6. Installation Dimensions

Bore Dia.	Groove Dia.	Groove Width	Order No.	O-Ring Dimensions
DN H9	d1 h9	L1+0.2
8 10 12	3.1 5.1 7.1	2.2 2.2 2.2	GSF8*3.1*2.2 GSF10*5.1*2.2 GSF12*7.1*2.2	2.90*1.78 4.80*1.8 6.70*1.8
14 15 15	9.1 10.1 7.5	2.2 2.2 3.2	GSF14*9.1*2.2 GSF15*10.1*2.2 GSF15*7.5*3.2	8.75*1.8 7.59*2.62 8.75*1.8
16 16 18	11.1 8.5 13.1	2.2 3.2 2.2	GSF16*11.1*2.2 GSF16*8.5*3.2 GSF18*13.1*2.2	10.82*1.78 7.59*2.62 12.42*1.78
18 20 20	10.5 15.1 12.5	3.2 2.2 3.2	GSF18*10.5*3.2 GSF20*15.1*2.2 GSF20*12.5*3.2	9.19*2.62 14.00*1.78 12.37*2.62
24 24 25	19.1 16.5 17.5	2.2 3.2 3.2	GSF24*19.1*2.2 GSF24*16.5*3.2 GSF25*17.5*3.2	18.77*1.78 15.54*2.62 17.12*2.62
25 28 28	14 20.5 17	4.2 3.2 4.2	GSF25*14*4.2 GSF28*20.5*3.2 GSF28*17*4.2	13.87*3.53 20.29*2.62 15.47*3.53
30 30 32	22.5 19 24.5	3.2 4.2 3.2	GSF30*22.5*3.2 GSF30*19*4.2 GSF32*24.5*3.2	21.89*2.62 26.70*1.78 23.47*2.62

Company Features
1. Dms Seals Technology Co.,limited is a highly creditable company in China as we have been focusing on the manufacture of high quality . Dms Seals Technology Co.,limited, a nation-renowned developer and manufacturer, is known for its strong R&D and manufacturing competence in this field. Dms Seals Technology Co.,limited is a highly qualified manufacturer in China with years of experience. We specialize in manufacturing . Dms Seals Technology Co.,limited enjoys more and more market share in recent years both domestic and overseas. We are praised as the top pioneer in manufacturing . Widely recognized as a strong competitor, Dms Seals Technology Co.,limited is always able to manufacture market-oriented .
2. The launch of promotes the sales of hydraulic cylinder seal design . As a backbone enterprise, Dms Seals Technology Co.,limited has always been focused on the improvement of technology. With innovation of the introduced technology, the quality of cylinder rod seal is greatly improved. Dms Seals Technology Co.,limited has many production sites around the globe. Being produced with advanced machine, the finest rod seal installation has gained wide recognition from customers.
3. We are committed to maintaining and developing robust corporate governance practices. We intend to ensure the delivery of high-quality products and services and maintain the highest standards of ethics. We are committed to achieving a balance between business development and the environment. We will seek a brand new approach to upgrade the production mode to achieve a non-pollutive and less energy consumption one. Our company takes pride in using low-impact manufacturing processes to create products that safeguard our food and water, lower dependence on energy, and enhance green initiatives. Innovation is essential, as we search out new ways and continuously identify opportunities to design, develop and advance creative, ethical solutions that are timely and effective.
