Bulk door seal suppliers cost for larger piston clearance

Company Advantages
1. The design of DMS Seals door seal suppliers adopts 3D design technology. This is done by using a special program, such as Matrix 3D Jewelry Design Software. The R&D teams have the ability to design and develop seals for various of complicated working condition of sealing system
2. With so many advantages, the product has high commercial value. Our products mainly include rod seals, piston seals, scraper seals, rotary seals, rubber seal products and spring seals
3. door seal suppliers receives many positive feedback from customers for its . High-end talents and advanced technology have enabled DMS o-ring seal quality to reach the industry's leading level

1. Installation Recommendation

2. Application and properties

The standard combination seal is suitable for a wide range of pressure work and sliding high speed occasions. Low friction, strong wear resistance.



3. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM

4. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
6-1600mm	0-35MPa	-30℃ +200℃	1.5 m/s	general hydraulic oil, water glycol Hydraulic oil and water emulsion type hydraulic oil.



5. Installation Dimensions

Nominal Size of Packing, and Housing dimensions				Order No.
d	D	H	L +0.2
18 20 22	27 29 31	4.3 4.3 4.3	4.5 4.5 4.5	SPN18*27*4.3 SPN20*29*4.3 SPN22*31*4.3
27 31.5 47	36 40.5 60	4.3 4.3 7.3	4.5 4.5 7.5	SPN27*36*4.3 SPN31.5*40.5*4.3 SPN47*60*7.3
53 60 65	66 73 78	7.3 7.3 7.3	7.5 7.5 7.5	SPN53*66*7.3 SPN60*73*7.3 SPN65*78*7.3
70 75 80	83 88 93	7.3 7.3 7.3	7.5 7.5 7.5	SPN70*83*7.3 SPN75*88*7.3 SPN80*93*7.3
90 100 110	103.4 113.4 123.4	7.3 7.3 7.3	7.5 7.5 7.5	SPN90*103.4*7.3 SPN100*113.4*7.3 SPN110*123.4*7.3
120 130 140	133.4 143.4 153.4	7.3 7.3 7.3	7.5 7.5 7.5	SPN120*133.4*7.3 SPN130*143.4*7.3 SPN140*153.4*7.3

Company Features
1. Dms Seals Technology Co.,limited is one of the most outstanding door seal suppliers manufacturers.
2. Our factory has a well-established production management system. This system requires a thorough inspection of raw materials, random checking on samples, workmanship checking, and audit of the production lines (labor, method, environment, etc.). This strict management system has helped improve and upgrade the production structure.
3. Our ideal is to be the world's top supplier in this industry. We will put more investment in improving our R&D capabilities, and grow stronger relying on distinctive products we produce.
