Bulk m8 dowty washer company for threaded pipe fittings and plug sealing

Company Advantages
1. The designs of DMS Seals vary with the changes in the market.
2. m8 dowty washer is excellent in outlook as you can see by pictures.
3. DMS Seals is elaborately designed to deliver better user experience.
4. The design of makes DMS Seals more comprehensive in the m8 dowty washer manufacturing industry.
5. DMS Seals conveys a unique innovative product concept.
6. With accuracy and safety, the product is qualified to use.
7. m8 dowty washer developed by Dms Seals Technology Co.,limited has a long-lasting excellent performance.
8. This product features easy usage and best performance.
9. Based on the rigorous inspection of the entire process, the quality is 100% guaranteed.
10. Some customers say when they use it to serve food, their guests love so much of its detailed beauty and translucent glaze over embossed patterns.
11. Most of the property developers praised that this product is outstanding and satisfying because it can ensure the strength and durability of the building projects that are constructed.
12. People who are sensitive to metals will find that they will have no problem with this product as it is non-irritant.
13. The product is very useful in the kitchen. People will find it will not crack or fracture under extreme temperature changes.
14. The product requires only simple and worry-free maintenance. Hence, people can benefit from it to save effort and maintenance time.

1. Applicability of the Bonded Seal Washer

The BS/A bonded seals (automatic core-positioning) are applicable to threaded pipe fittings and plug sealing in Metric System, the Britain System and BSP. The location processing of sealing groove is not specially required, so it is ideal fittings for fast and automatic installation. Its service temperature is -30℃~100℃, working pressure less than 39.2MPa.

2. Figure

2. GM500 Self-centering range metric dimensions

Metric Thread size	Inside Diameter	Outside Diameter	Metal thickness	Metal washer ID	ID between self centering
	C	A	E	B	F
PPM6	6,50	10,00	1,00	8,00	5,60
PPM8	8,5	14,00	1,00	10,40	6,40
PPM10	10,50	16,00	2,00	12,40	8,05
PPM12	12,50	18,00	1,50	14,10	9,73
PPM14	14,5	20,00	2,00	16,40	11,38
PPM16	16,5	22,00	2,00	18,40	13,41
PPM18	18,5	25,00	2,00	20,40	14,76
PPM20	20,5	28,00	2,00	22,50	16,76
PPM22	22,5	30,00	2,00	24,40	18,74
PPM24	24,5	32,00	2,00	26,40	20,11
PPM27	27,2	35,00	2,00	29,40	23,30
PPM30	30,7	38,00	2,00	32,40	25,70
PPM33	33,5	42,00	2,00	35,40	28,70
PPM36	36.7	46,00	2,00	38,70	31.1
PPM39	41.9	51,00	2,00	40,00	34.1
PPM42	42.7	53,00	2,00	45,70	38.7
PPM48	48.7	60,00	2,00	51,70	43.7
PPM52	52.9	66,00	2,00	56,40	46
PPM60	60.9	75,00	2,00	63,00	-

3. GM500 Self-centering range inch dimensions, BSP

BSP thread size	Inside Diameter	Outside Diameter	Metal thickness	Metal washer ID	ID between self centering
	C	A	E	B	F
1/8 BSP	10,37	15,88	2,00	11,84	8,26
1/4 BSP	13,74	20,57	2,00	15,21	11,18
3/8 BSP	17,28	23,80	2,00	18,75	14,76
1/2 BSP	21,54	28,58	2,50	23,01	18,24
3/4 BSP	27,05	34,93	2,50	28,53	23,83
1 BSP	33,89	42,80	3,20	36,88	29,92
1 1/4 BSP	42,93	52,38	3,20	45,93	38,45
1 1/2 BSP	48,44	58,60	3,20	51,39	44,45
2 BSP	60,58	73,03	3,20	63,63	56,26



Best quality bonded seal wholesale, welcome to contact the leading bonded seal rings and bonded washers suppliers.

Company Features
1. Dms Seals Technology Co.,limited was established many years ago. Today, we are considered one of the best suppliers of m8 dowty washer in China. With years of devotion to this industry, Dms Seals Technology Co.,limited has become an expert of dowty washers near me and transcended most competitors in the market. Dms Seals Technology Co.,limited has a wealth of experience in designing and manufacturing stainless steel dowty washers and we enjoy a good reputation in the industry. Dms Seals Technology Co.,limited is one of the leading manufacturers in China being able to offer m16 dowty washer with award-winning design and quality.
2. We have enabled our products to be exported to numerous regions, such as Europe, America, Australia, Asia, and Africa. We are their trustworthy partners because we have been providing them with customized products that targeted at their markets. So far, we have exported products to most parts of Asia and America. And we have got lots of appreciation from those customers based on our long-term stable cooperation. We sell products all over the world. Our export destinations include the United States, Canada, Central and South America, the United Kingdom, Spain, Africa, Russia, Australia, and Southeast Asia. We have won the trust and support of customers around the world. We have brought together a large pool of talents. They comprise a high-quality management team. Over the years, they have overcome difficulties and challenges in achieving our business transformation based on their expertise and market insight.
3. With strong ambitions, DMS Seals always work hard to provide both the best dowty bonded seal washer and the most professional service. Call! Constant improvement for m8 dowty washer will continue. Call! Doing the best to provide dowty washer sizes with highest quality is the aim of DMS Seals. Call! The sustained development of DMS Seals can not be achieved without strong enterprise culture. Call!
