Carbon Fiber with PTFE Cylinder Rotary Piston Seals GNS 1

Carbon Fiber with PTFE Cylinder Rotary Piston Seals GNS 2

Carbon Fiber with PTFE Cylinder Rotary Piston Seals GNS 3

Carbon Fiber with PTFE Cylinder Rotary Piston Seals GNS

Diameter Range:

3-1600mm

Pressure Range:

0-30MPa

Temperature Range:

-30℃ +200℃

Speed:

1m/s

Medium:

hydraulicoil,flameretardantliquid,waterandothers

Inquiry

Write a Review

Product Description

GNS is composed of a filled PTFE wear ring and an O-ring rubber seal. O-rings provide radial preload to compensate for wear on the wear rings. It has a two-way sealing effect and can withstand pressure in one or two directions. Suitable for hole sealing of shafts, rods, bearings, rotary joints, swivel seats, etc.

Advantages:

1.Available for internal or external sealing

2.High corrosion resistance and dimensional stability

3.Small frictional resistance, quick start, no crawling phenomenon, to ensure the stability of movement

4.less wear

5.Simple groove design, small groove size

Product Parameters

NO.	SIZE	NO.	SIZE
1	GNS2015.12.2	33	GNS1251144.2
2	GNS2217.12.2	34	GNS1301194.2
3	GNS2520.12.2	35	GNS135119.56.3
4	GNS2823.12.2	36	GNS140124.56.3
5	GNS3025.12.2	37	GNS150134.56.3
6	GNS3227.12.2	38	GNS160144.56.3
7	GNS3530.12.2	39	GNS170154.56.3
8	GNS3631.12.2	40	GNS175159.56.3
9	GNS3833.12.2	41	GNS180164.56.3
10	GNS4032.53.2	42	GNS190174.56.3
11	GNS4234.53.2	43	GNS200184.56.3
12	GNS4537.53.2	44	GNS210194.56.3
13	GNS4840.53.2	45	GNS220204.56.3
14	GNS5042.53.2	46	GNS230214.56.3
15	GNS5244.53.2	47	GNS240224.56.3
16	GNS5345.53.2	48	GNS250234.56.3
17	GNS5547.53.2	49	GNS280264.56.3
18	GNS6052.53.2	50	GNS300284.56.3
19	GNS6355.53.2	51	GNS310294.56.3
20	GNS6557.53.2	52	GNS320304.56.3
21	GNS7062.53.2	53	GNS3503298.1
22	GNS7567.53.2	54	GNS3603398.1
23	GNS80694.2	55	GNS4003798.1
24	GNS85744.2	56	GNS4203998.1
25	GNS90794.2	57	GNS4504298.1
26	GNS95844.2	58	GNS4804598.1
27	GNS100894.2	59	GNS5004798.1
28	GNS102914.2	60	GNS5104898.1
29	GNS105944.2	61	GNS5204998.1
30	GNS110994.2	62	GNS5505298.1
31	GNS1151044.2	63	GNS6005798.1
32	GNS1201094.2	64	GNS6506298.1
