Custom bearing for roller manufacturer as the guide sleeve
1. DMS Seals bearing for roller is manufactured with the help of our talented team of craftsmen. To reduce costs with high-efficiency work is the DMS's purpose
2. bearing for roller is produced by superior material and advanced technology. DMS Seal manufacturer is a technology enterprise which specialized in the R&D and production of seals
3. This product has many features. It has the outstanding characteristics of light weight, high wear resistance, impact resistance and ultra-thin. DMS Seals takes the lead in grasping the development trend of the industry
4. This product is breathable and soft. It uses ultra-thin threads in a tightly spun mesh that feels incredibly soft while staying breathable. Quality control of the seals is the basis for DMS Seals
Application and properties
Applicable to as the guide sleeve of piston rod, can support and guide the piston rod. Excellent vibration reducing performance, installation is simple and secure. The metal and plastic material pairing can prevent the "stagnation" and "seizure" phenomenon.
Standard materials
Filled PTFE / PA / POM
Working Conditions | ||||
Diameter Range | Pressure Range | Temperature Range | Speed | Medium |
3-1000mm | -55℃+225℃ | 3m/s | general hydraulic oil, emulsion, water | |
d | D | D1 | H | c | a | Order No. |
20 | 26 | 23 | 19 | 6 | 6.5 | DFI20*26*19 |
28 | 34 | 31 | 19 | 6 | 6.5 | DFI28*34*19 |
40 | 46 | 43 | 19 | 6 | 6.5 | DFI40*46*19 |
50 | 56 | 53 | 19 | 6 | 6.5 | DFI50*56*19 |
60 | 70 | 65 | 24 | 7 | 8.5 | DFI60*70*24 |
70 | 80 | 75 | 24 | 7 | 8.5 | DFI70*80*24 |
80 | 90 | 85 | 24 | 7 | 8.5 | DFI80*90*24 |
95 | 105 | 100 | 24 | 7 | 8.5 | DFI95*105*24 |
105 | 115 | 110 | 24 | 7 | 8.5 | DFI105*115*24 |
120 | 130 | 125 | 24 | 7 | 8.5 | DFI120*130*24 |
140 | 150 | 145 | 24 | 7 | 9.5 | DFI140*150*24 |
160 | 172 | 166 | 35 | 15 | 10 | DFI160*172*35 |
180 | 192 | 186 | 35 | 15 | 10 | DFI180*192*35 |
