DMS Seal Manufacturer Brand hydraulic ptfe bearing element bearing factory

Company Advantages
1. oil seal ring material provides bearing element with long service life. DMS Seals provides professional design and production of high-grade o-ring seals
2. DMS Seal Manufacturer believes that the quality is the soul of an enterprise. We can support OEM and ODM
3. The product is characterized by high performance and stable quality. To reduce costs with high-efficiency work is the DMS's purpose
4. The product has been exported to many countries and gains customers' recognition. DMS Seals manufacturer owns a team of professional R&D group and skilled technicians
5. With its foreseeable development prospects, this product is worth expanding over the market. The R&D teams have the ability to design and develop seals for various of complicated working condition of sealing system

1. Installation Recommendation

2. Application and properties

Applicable to the guiding of piston and piston rod of hydraulic cylinder and air cylinder, has the function of supporting and guiding. The guide strips with the thickness which equal to or greater than 2mm, double sided embossing could be provided, the embossing structure is conducive to the formation of lubrication micro-pit, improve micro lubrication, at the same time, it is helpful to embed tiny foreign objects and protect the sealing system.

3. Standard materials

Phenolic resin

4. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
Custom as Required	0-100 MPa	-60℃ +120℃	1 m/s	hydraulic oil, emulsion, and water

Piston:  L=C × ( D - W ) - k [ mm ] D = Piston Dia. [ mm ] W = Thickness [ mm ]

Rod:    L=C × ( d + W ) - k [ mm ] d = Rod Dia. [ mm ]  C = 3.14  k=0.8

5. Standard groove width and standard thickness

Standard groove width

Groove width L2

8.1

10

15

20

5.6

6.3

9.5

9.7

12.7

25

30

40

50

5

6

8

35

45

The products of various width could be provided.

Standard thickness of product

Thickness W

2

2.5

3

3.5

4

6

3.18

3.17

The products of various thickness could be provided.
