DMS Seal Manufacturer Brand piston oring ptfe piston seals

Diameter Range:

3-1600mm

Pressure Range:

0-45MPa

Temperature Range:

-30℃+100℃

Speed:

1m/s

Medium:

hydraulic oil, flame retardant liquid, water and others

Inquiry

Product Details

Adhering to the concept of 'details and quality make achievement', Dms Seals works hard on the following details to make the Oil Seal Manufacturer more advantageous.Dms Seals adopts advanced technology, quality materials and scientific management to improve the stability and reliability and ensure the longevity of O-ring Seal.Dms Seals carries out strict quality monitoring and cost control on each production link of Oil Seal Manufacturer, from raw material purchase, production and processing and finished product delivery to packaging and transportation. This effectively ensures the product has better quality and more favorable price than other products in the industry.

Company Advantages
1. DMS Seal Manufacturer pneumatic piston seals is made using sophisticated technology and high-grade materials. Our products mainly include rod seals, piston seals, scraper seals, rotary seals, rubber seal products and spring seals
2. The product is able to meet the high quality requirements of many varieties of production. DMS Seal manufacturer provides good quality and competitive price hydraulic seals
3. Every product produced by DMS Seal Manufacturer meets the requirements of quality assurance of national standard. The high pressure seals have strong wear resistance to hard conditions
4. Dms Seals Technology Co.,limited ensures efficient quality service for the clients. DMS Seal manufacturer is a technology enterprise which specialized in the R&D and production of seals
5. Dms Seals Technology Co.,limited's members have accepted professional train to improve their proficiency in customer service. DMS O Ring Manufacturers strictly follows the ISO9001 international quality certification system for production management

Installation Recommendation

undefined

Application and properties

Apply to the hydraulic cylinder of piston sealing, generally used in conjunction with the guide sleeve. The seal ring and piston conforming to be a symmetric section to achieve the sealing performance. The Non-standard Y-ring has the function of sealing and provides the elastic force to the sealing ring and compensates for the abrasion. Very high pressure stability under pressure and harsh conditions, high wear resistance, low friction, no crawling phenomenon.

Standard materials

Sealing ring: filled PTFE

Y-Ring: NBR / PU

Working Conditions

Working Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3-1600mm	0-45MPa	-30℃+100℃	1m/s	hydraulic oil, flame retardant liquid, water and others

Installation Dimensions

D H8	d h9	H	L+0.2	e	Order No.
40 43 44	32 35 36	7 7 7	7.5 7.5 7.5	6 6 6	DDA40327.5 DDA43357.5 DDA44367.5
45 48 50	37 40 42	7 7 7	7.5 7.5 7.5	6 6 6	DDA45377.5 DDA48407.5 DDA50427.5
55 60 63	45 45 53	7 12 8	7.5 13 8.5	6 6 6	DDA55457.5 DDA604513 DDA63538.5
63 65 65	48 50 50	12 12 12	13 8.5 13	6 6 6	DDA634813 DDA65508.5 DDA655013
70 75 78	55 60 63	12 12 12	13 13 13	6 6 6	DDA705513 DDA756013 DDA786313
80 85 87	65 70 72	12 12 12	13 13 13	6 6 6	DDA806513 DDA857013 DDA877213
90 95 100	75 80 85	12 12 12	13 13 13	7 7 7	DDA907513 DDA958013 DDA1008513
105 110 115	90 95 100	12 12 12	13 13 13	7 7 7	DDA1059013 DDA1109513 DDA11510013
120 125 130	105 110 115	12 12 12	13 13 13	7 7 7	DDA12010513 DDA12511013 DDA13011513
140 145 150	120 125 130	12 12 12	13 13 13	7 10 10	DDA14012013 DDA14512513 DDA15013013
160 160 170	140 140 150	12 16 16	13 17 17	10 10 10	DDA16014013 DDA16014017 DDA17015017
180 185 190	160 165 170	16 16 16	17 17 17	10 10 10	DDA18016017 DDA18516517 DDA19017017
200 210 220	180 190 200	16 16 16	17 17 17	10 10 10	DDA20018017 DDA21019017 DDA22020017

Installation Dimensions

Company Features
1. After several years of arduous pioneering, Dms Seals Technology Co.,limited has established a good management system and market network.
2. With the outstanding technical strength, Dms Seals Technology Co.,limited is trusted by customers.
3. Dms Seals Technology Co.,limited is confident that your need will be best satisfied. Get more info!

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
