DMS Seal Manufacturer Brand rod oring ptfe rod seals manufacture

Diameter Range:

3-1600mm

Pressure Range:

0-60MPa

Temperature Range:

-30℃+200℃

Speed:

15m/s

Medium:

hydraulic oil, flame retardant liquid, water, gas

Inquiry

Company Advantages
1. As a modern sealing technology company, DMS Seal manufacturer has a wealth of experience. hydraulic rod seals piston rod seal offered by DMS Seal Manufacturer are used for hydraulic rod seals online.
2. The fame of DMS Seal Manufacturer is widely increasing for its high quality rod seals. DMS Seals implements and optimizes its quality control systems
3. Being proud of the unique hydraulic rod seals characteristics, we are confident to be the leading brand rod seal catalogue manufacturer. DMS Seal manufacturer was established in 2008 and now has more than 10 years professional experience
4. Compared with general products, O Ring Manufacturers is featured with pneumatic rod seals, so it is more competitive in commercial market. Seal we produced has applications in a wide range of fields
5. o-ring seal has remarkable performance. Quality control of the seals is the basis for DMS Seals

Installation Recommendation

undefined

Application and properties

Applicable to high and low speed reciprocating motion environment, a wide range of fluids and high temperature condition. Suitable for larger gap of piston rod. Low friction, simple groove, be able to work in the medium with oil spots.

Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM

Working Conditions

Working Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3-1600mm	0-60MPa	-30℃+200℃	15 m/s	hydraulic oil, flame retardant liquid, water, gas

Installation Dimensions

Rod Dia.	Outer Dia.	Width	Order No.
d h9	D1 H9	L1+0.2	Order No.
40 45 50	50 55 60	4.2 4.2 4.2	GSW40504.2 GSW45554.2 GSW50604.2
50 53 55	65 63 65	6.8 4.2 4.2	GSW50656.8 GSW53634.2 GSW55654.2
55 60 60	70 70 75	6.8 4.2 6.8	GSW55706.8 GSW60704.2 GSW60756.8
63 65 65	73 75 80	4.2 4.2 6.8	GSW63734.2 GSW65754.2 GSW65806.8
67 70 70	77 80 82	4.2 4.2 6.8	GSW67774.2 GSW70804.2 GSW70856.8
75 75 80	85 90 90	4.2 6.8 4.2	GSW75854.2 GSW75906.8 GSW80904.2
80 85 90	75 100 105	6.8 6.8 6.8	GSW80956.8 GSW851006.8 GSW901056.8
95 100 106	110 115 121	6.8 6.8 6.8	GSW951106.8 GSW1001156.8 GSW1061216.8
110 115 120	125 130 135	6.8 6.8 6.8	GSW1101256.8 GSW1151306.8 GSW1201356.8
125 130 135	140 145 150	6.8 6.8 6.8	GSW1251406.8 GSW1301456.8 GSW1351506.8
140 145 150	155 160 165	6.8 6.8 6.8	GSW1401556.8 GSW1451606.8 GSW1501656.8
155 160 165	170 175 180	6.8 6.8 6.8	GSW1551706.8 GSW1601756.8 GSW1651806.8
170 175 180	185 190 200	6.8 6.8 8.1	GSW1701856.8 GSW1751906.8 GSW1802008.1

Installation Dimensions

Company Features
1. All Work And No Play Makes Jack A Dull Boy. DMS Seal Manufacturer Is One Of The Leading rod seals, hydraulic rod seals, piston rod seal Designers, Manufacturers And Exporter From China Get Info!
2. Dms Seals Technology Co.,limited always sticks to the core business philosophy. Please contact.

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
