DMS SEALS TECHNOLOGY CO.,LIMITED
The Professional Sealing Solution Supplier(O Ring Suppliers & Oil Seal Manufacturers).
DMS Seals - Hydraulic Seals and Oil Ring Seals Manufacturer & Supplier
DMS Seal Manufacturer bronze hydraulic piston seals manufacturer for light and medium hydraulic systems
1. DMS Seal Manufacturer hydraulic piston seals is precisely designed and developed with utmost care.
2. The production process of DMS Seal Manufacturer hydraulic piston seals has been standardized by using the advanced technology.
3. Thanks to the expertise of our professionals, DMS Seal Manufacturer hydraulic piston seals is carefully manufactured.
4. DMS Seal Manufacturer hydraulic piston seals is produced based on the highest standards.
5. The product is widely demanded in the market for featuring stable performance and strong functionality.
6. hydraulic piston seals can be used for hydraulic piston seals sizes .
7. The form of this product harmonizes with the function.
8. Skillful employees and a range of equipment guarantee the product quality.
9. The product not only saves much electricity consumption in applications of the architecture but also it contributes a lot in protecting our environment.
10. With its user-friendly and advanced technology, the product is able to greatly improve people's overall efficiency of life or work.
11. The energy-efficient product contributes a lot in cutting electricity cost, which also helps conserve energy and resources for our earth.
12. People will see the benefits it brings in the long run. It not only efficient in reducing energy demand, but also in reducing people's electricity costs.
Application and properties
Apply to cylinder piston, consisting of a seal ring, an O-Ring, a pair of retaining rings and a pair of guide sleeves. The seal ring and cylinder bore conforming to be a symmetric section to achieve the sealing performance, with double acting sealing performance.
Standard materials
Sealing ring: filled PTFE
O-Ring: NBR / FKM
Back-up ring: filled PTFE / PA
Guide ring: filled PTFE / PA
Working Conditions | ||||
Diameter Range | Pressure Range | Temperature Range | Speed | Medium |
3-1600mm | 0-45MPa | -30℃+200℃ | 1 m/s | hydraulic oil, flame retardant liquid, water and others |
D | d | b | d2 | d3 | a | c | f | e | Order No. |
40 | 26 | 32 | 32 | 36 | 3.5 | 15.5 | 8.25 | 7 | DDKK40*26*32 |
56 | 40 | 39 | 48 | 52 | 3 | 20.5 | 9.25 | 7 | DDKK56*40*39 |
65 | 49 | 39 | 57 | 61 | 3 | 20.5 | 9.25 | 7 | DDKK65*49*39 |
80 | 62 | 43 | 72 | 76 | 3 | 22.5 | 10.25 | 7 | DDKK80*62*43 |
95 | 77 | 43 | 87 | 91 | 3 | 22.5 | 10.25 | 7 | DDKK95*77*43 |
110 | 92 | 43 | 102 | 106 | 3 | 22.5 | 10.25 | 10 | DDKK110*92*43 |
125 | 103 | 53 | 115 | 121 | 4 | 26.5 | 13.25 | 10 | DDKK125*103*53 |
150 | 128 | 53 | 140 | 146 | 4 | 26.5 | 13.25 | 10 | DDKK150*128*53 |
170 | 148 | 57 | 160 | 166 | 6 | 26.5 | 15.25 | 10 | DDKK170*148*57 |
195 | 170 | 64 | 185 | 191 | 4.5 | 31.5 | 16.25 | 10 | DDKK195*170*64 |
Company Features
1. Dms Seals Technology Co.,limited today stands as one of the most successful manufacturers in China to produce hydraulic piston seals with the latest technology and best expertise. Dms Seals Technology Co.,limited stands out among competitors relying on capacities in R&D and manufacturing. We have been highly thought of for the ability to offer hydraulic piston seals sizes . Having advanced the development, design, and production of hydraulic cylinder piston seals , Dms Seals Technology Co.,limited has been considered as one of the most competitive manufacturers.
2. Our company has excellent management. They can able to solve many complex issues and problems by thinking ahead, planning for contingencies, balancing competing interests and taking an analytical approach. Under the ISO 9001 system, the factory maintains a consistently high level of high-quality by following the same manufacturing, management, and quality control processes on all of our production lines. Our company has workers with a broad skill base. Their multi-skill advantage allows the company to be able to adapt schedules to meet customer demand without any loss of productivity. We have built long-standing relationships with customers and our partners on every continent. Because we consistently adhere to the quality principles, we expect to enjoy an ever-larger client base. We are blessed with a group of staff that are qualified and well-trained. They have deep knowledge and expertise about products, which enables them to adapt themselves to different situations or customers' requirements.
3. Excellence in quality is the promise of our company for customers. We will unswervingly use superior quality materials and strive for sophisticated workmanship, so as to supply clients with high-quality products. Dms Seals Technology Co.,limited can supply the very best choice depending on customers' needs. Check now! DMS Seal Manufacturer is fully committed to high quality products and good service. Check now! We have high-performance work teams. They understand and support the meaning and value of the company's mission and vision. They connect their roles and responsibilities to enhance team potential and thereby enhance company competence.
DMS Seal Manufacturer bronze hydraulic piston seals manufacturer for light and medium hydraulic systems
hydraulic piston seals
Type:
Professional O Ring Suppliers & O Ring Manufacturers
