DMS Seal Manufacturer buna n O Ring Manufacturer online for static sealing

Company Advantages
1. O Ring Manufacturer is made from eco-friendly materials to minimize pollution and use of resources in materials and production and disposal.
2. DMS Seal Manufacturer O Ring Manufacturer with unique design delivers preferable attractions.
3. DMS Seal Manufacturer O Ring Manufacturer is exquisitely designed from a group of innovative designers.
4. The offered DMS Seal Manufacturer rod wiper seals is produced using advanced production technology that is adopted in the whole process.
5. O Ring Manufacturer is unusual in design and appropriate in size.
6. The product has a smooth and sleek surface with intricate details. The clay used usually features fineness and excellent plasticity for making sophisticated patterns.
7. This product has no electrical safety problem. A built-in protection system on the board helps avoid electric leakage.
8. The product has enough hardness. It is able to resist deformation, which is determined by a standard test where the surface resistance to indentation is measured.
9. This product can replace human beings to complete dangerous tasks, which greatly relieves the pressure and labor of workers in the long run.
10. It allows the shoe to breathe, avoiding producing a proliferation of bacteria and fungi and bad odor. By choosing this material the wearer will get rid of smelly feet.
11. With the desired comfort and durability, this product is perfectly suitable for wearing every day and can be worn again and again.
12. The product matches perfectly with walls painted in rich, light, or dark colors. Anyway, because of its delicate design, it works harmoniously with space style.
13. This product is marked by esteemed quality and aesthetic presence. People can rest assured that it can be used for a long period while not losing its beauty over the years.

1. Installation Recommendation

2. Application and properties

Double acting seals, the sealing effect is achieved by the deformation of the section of the O-Rings, and the deformation is determined by the depth of the installation groove. Under pressure, the O-ring has a large surface tension like liquid, used for static sealing more. It is only recommended for better conditions in dynamic applications. System lubrication, pressure, temperature, sealing clearance, speed, medium and surface quality of metal parts determine the service life of O-Rings. It is not recommended if the lubrication is not sufficient during rotary motion.

3. Standard materials

NBR / FKM

4. Performance parameter

	Static Seal	Dynamic Seal
Working Pressure	No support ring, up to 20MPa; With the support ring, up to 40MPa; With special support ring, up to 200MPa.	No support ring, up to 5MPa; With the support ring, higher pressure.
Movement Speed	Maximum reciprocating speed up to 0.5m / s; maximum rotation speed up to 2.0m/s.
Temperature	NBR: -30℃ - 100℃;  FKM: -20℃ - 220℃.

5. Wire Diameter Tolerance

Wire diameter of O-Ring (mm)	Tolerance (±mm)
0-1.8	0.08
1.80-2.65	0.09
2.65-3.55	0.10
3.55-5.30	0.13
5.30-7.00	0.15
7.00-8.00	0.18
8.00-10.00	0.21
10.00-12.00	0.25



6. Inner diameter tolerance

Inner Diameter d1 mm	Tolerance ±mm	Inner Diameter d1 mm	Tolerance ±mm	Inner Diameter d1 mm	Tolerance ±mm
0.70-2.50 2.50-4.50 4.50-6.30	0.13 0.14 0.15	43.70-45.00 46.00-46.20 46.20-47.50	0.42 0.43 0.44	95.00-97.50 97.50-100.00 100.00-103.00	0.83 0.84 0.87
6.30-8.50 8.50-10.00 10.00-11.20	0.16 0.17 0.18	47.50-48.70 48.70-50.00 50.00-51.50	0.45 0.46 0.47	103.00-106.00 106.00-109.00 109.00-112.00	0.89 0.91 0.93
11.20-14.00 14.00-16.00 16.00-18.00	0.19 0.20 0.21	51.50-53.00 53.00-54.50 54.50-56.00	0.48 0.50 0.51	112.00-115.00 115.00-118.00 118.00-122.00	0.95 0.97 1.00
18.00-20.00 20.00-21.20 21.20-23.60	0.22 0.23 0.24	56.00-58.00 58.00-60.00 60.00-61.50	0.52 0.54 0.55	122.00-125.00 125.00-128.00 128.00-132.00	1.03 1.05 1.08
23.60-25.00 25.00-26.50 26.50-28.00	0.25 0.26 0.28	61.50-63.00 63.00-65.00 65.00-67.00	0.56 0.58 0.59	132.00-136.00 136.00-140.00 140.00-145-00	1.10 1.13 1.17
28.00-30.00 30.00-31.50 31.50-33.50	0.29 0.31 0.32	67.00-69.00 69.00-71.00 71.00-73.00	0.61 0.63 0.64	145.00-150.00 150.00-155.00 155.00-160.00	1.20 1.24 1.27
33.50-34.50 34.50-35.50 35.50-36.50	0.33 0.34 0.35	73.00-75.00 75.00-77.50 77.50-80.00	0.66 0.67 0.69	160.00-165.00 165.00-170.00 170.00-175.00	1.31 1.34 1.38
36.50-37.50 37.50-38.70 38.70-40.00	0.36 0.37 0.38	80.00-82.50 82.50-85.00 85.00-87.50	0.71 0.73 0.75	175.00-180.00 180.00-185.00 185.00-190.00	1.41 1.44 1.48
40.00-41.20 41.20-42.50 42.50-43.70	0.39 0.40 0.41	87.50-90.00 90.00-92.50 92.50-95.00	0.77 0.79 0.81	190.00-195.00 195.00-200.00 200.00-206.00	1.51 1.55 1.59
206.00-212.00 212.00-218.00 224.00-230.00	1.63 1.71 1.75	325.00-335.00 335.00-345.00 345.00-355.00	2.43 2.49 2.56	500.00-515.00 515.00-530.00 530.00-545.00	3.54 3.63 3.72
230.00-236.00 236.00-243.00 243.00-250.00	1.79 1.83 1.88	355.00-365.00 365.00-375.00 375.00-387.00	2.62 2.68 2.76	545.00-560.00 560.00-580.00 580.00-600.00	3.81 3.93 4.05
250.00-258.00 258.00-265.00 265.00-272.00	1.93 1.98 2.02	387.00-400.00 400.00-412.00 412.00-425.00	2.84 2.91 2.99	600.00-615.00 615.00-630.00 630.00-650.00	4.13 4.22 4.34
272.00-280.00 280.00-290.00 290.00-300.00	2.08 2.14 2.21	425.00-437.00 437.00-450.00 450.00-462.00	3.07 3.15 3.22	650.00-670.00	4.46
300.00-307.00 307.00-315.00 315.00-325.00	2.25 2.30 2.37	462.00-475.00 475.00-485.00 485.00-500.00	3.30 3.37 3.45

Company Features
1. Dms Seals Technology Co.,limited is thought of an expert in producing rod wiper seals . We also provide a series of related product portfolio. Dms Seals Technology Co.,limited, a specialist manufacturer and producer of o ring seal supplier, has gained recognization in the domestic markets. Dms Seals Technology Co.,limited ranks in the top as a reputable and listed as the most highly-regarded enterprise specialing in manufacturing hydraulic wiper seals . Dms Seals Technology Co.,limited is appraised as a leading company in manufacturing wiper seal design . We are an excellent innovative company in China.
2. We have set up a project management team. They work with clients at all stages of their business and they can help our clients transform ideas into competitively priced products. We have a professional marketing team. Our team has extensive experience in expanding our products in both developed and low-cost regions around the world. The factory has newly introduced advanced production facilities according to the market demands. These facilities have been approved by authoritative quality testing institutions. This offers a guarantee for our production and product quality. We are backed by a team of development engineers. Drawing from years of experience, they work hard to develop innovative products and constantly upgrade the form of products.
3. We have a robust social responsibility program. We regard it as an opportunity to demonstrate good corporate citizenship. Looking at the whole social and environmental sphere help the company from outsized risk. Get quote! We always adhere to the customer-oriented concept. We will offer customer-oriented services and spare no efforts to offer customers quality products that are professionally manufactured. We take a responsible approach in every aspect of our operations. We are committed to managing and reducing production waste as possible. Our company is customer-centric. Everything we do starts with active listening and working with our customers. By understanding their challenges and aspirations, we proactively identify solutions to meet their current and future needs. Get quote!

DMS Seal Manufacturer buna n O Ring Manufacturer online for static sealing

O Ring Manufacturer

Type:
