DMS Seal Manufacturer buy o ring kit Supply in highly aggressive chemical processing

Company Advantages
1. DMS Seal Manufacturer is characterized by advanced technology with the great workmanship.
2. DMS Seal Manufacturer buy o ring kit is fabricated from optimum raw material supplied from top-grade vendors.
3. DMS Seal Manufacturer [拓展关键词 is produced with high quality materials that are carefully selected.
4. DMS Seal Manufacturer buy o ring kit is based on first-class, carefully selected and controlled raw materials.
5. The design of DMS Seal Manufacturer is obviously appealing and attracts more customers.
6. Our buy o ring kit is not only beautiful but also durable.
7. buy o ring kit is the best with peculiarities like .
8. With the advantage of , in these decades, a lot of costumers have made repeat purchases of buy o ring kit .
9. The value of buy o ring kit are recognized by most industry insider.
10. This product helps man to reduce his or her job. And because of this, the money that is required to pay is totally reduced.
11. This product has unique anti-bacterial qualities and is naturally hypoallergenic, therefore making it ideal for sensitive or allergy-prone skin.
12. The product is easy for people to control and only needs a little workforce. This will help lower operating costs.
13. This product is able to keep people's feet perfectly cushioned when they are walking and ensure the perfect grip - whatever the weather.
14. The product enables people to stay clean and breathable all the time, and allows people to wear it with the desired comfort.

1. Installation Recommendation

2. Application and properties

Double acting seals, the sealing effect is achieved by the deformation of the section of the O-Rings, and the deformation is determined by the depth of the installation groove. Under pressure, the O-ring has a large surface tension like liquid, used for static sealing more. It is only recommended for better conditions in dynamic applications. System lubrication, pressure, temperature, sealing clearance, speed, medium and surface quality of metal parts determine the service life of O-Rings. It is not recommended if the lubrication is not sufficient during rotary motion.

3. Standard materials

Silicone

4. Performance parameter

	Static Seal	Dynamic Seal
Working Pressure	No support ring, up to 20MPa; With the support ring, up to 40MPa; With special support ring, up to 200MPa.	No support ring, up to 5MPa; With the support ring, higher pressure.
Movement Speed	Maximum reciprocating speed up to 0.5m / s; maximum rotation speed up to 2.0m/s.
Temperature	NBR: -30℃ - 100℃;  FKM: -20℃ - 220℃.

5. Wire Diameter Tolerance

Wire diameter of O-Ring (mm)	Tolerance (±mm)
0-1.8	0.08
1.80-2.65	0.09
2.65-3.55	0.10
3.55-5.30	0.13
5.30-7.00	0.15
7.00-8.00	0.18
8.00-10.00	0.21
10.00-12.00	0.25



6. Inner diameter tolerance

Inner Diameter d1 mm	Tolerance ±mm	Inner Diameter d1 mm	Tolerance ±mm	Inner Diameter d1 mm	Tolerance ±mm
0.70-2.50 2.50-4.50 4.50-6.30	0.13 0.14 0.15	43.70-45.00 46.00-46.20 46.20-47.50	0.42 0.43 0.44	95.00-97.50 97.50-100.00 100.00-103.00	0.83 0.84 0.87
6.30-8.50 8.50-10.00 10.00-11.20	0.16 0.17 0.18	47.50-48.70 48.70-50.00 50.00-51.50	0.45 0.46 0.47	103.00-106.00 106.00-109.00 109.00-112.00	0.89 0.91 0.93
11.20-14.00 14.00-16.00 16.00-18.00	0.19 0.20 0.21	51.50-53.00 53.00-54.50 54.50-56.00	0.48 0.50 0.51	112.00-115.00 115.00-118.00 118.00-122.00	0.95 0.97 1.00
18.00-20.00 20.00-21.20 21.20-23.60	0.22 0.23 0.24	56.00-58.00 58.00-60.00 60.00-61.50	0.52 0.54 0.55	122.00-125.00 125.00-128.00 128.00-132.00	1.03 1.05 1.08
23.60-25.00 25.00-26.50 26.50-28.00	0.25 0.26 0.28	61.50-63.00 63.00-65.00 65.00-67.00	0.56 0.58 0.59	132.00-136.00 136.00-140.00 140.00-145-00	1.10 1.13 1.17
28.00-30.00 30.00-31.50 31.50-33.50	0.29 0.31 0.32	67.00-69.00 69.00-71.00 71.00-73.00	0.61 0.63 0.64	145.00-150.00 150.00-155.00 155.00-160.00	1.20 1.24 1.27
33.50-34.50 34.50-35.50 35.50-36.50	0.33 0.34 0.35	73.00-75.00 75.00-77.50 77.50-80.00	0.66 0.67 0.69	160.00-165.00 165.00-170.00 170.00-175.00	1.31 1.34 1.38
36.50-37.50 37.50-38.70 38.70-40.00	0.36 0.37 0.38	80.00-82.50 82.50-85.00 85.00-87.50	0.71 0.73 0.75	175.00-180.00 180.00-185.00 185.00-190.00	1.41 1.44 1.48
40.00-41.20 41.20-42.50 42.50-43.70	0.39 0.40 0.41	87.50-90.00 90.00-92.50 92.50-95.00	0.77 0.79 0.81	190.00-195.00 195.00-200.00 200.00-206.00	1.51 1.55 1.59
206.00-212.00 212.00-218.00 224.00-230.00	1.63 1.71 1.75	325.00-335.00 335.00-345.00 345.00-355.00	2.43 2.49 2.56	500.00-515.00 515.00-530.00 530.00-545.00	3.54 3.63 3.72
230.00-236.00 236.00-243.00 243.00-250.00	1.79 1.83 1.88	355.00-365.00 365.00-375.00 375.00-387.00	2.62 2.68 2.76	545.00-560.00 560.00-580.00 580.00-600.00	3.81 3.93 4.05
250.00-258.00 258.00-265.00 265.00-272.00	1.93 1.98 2.02	387.00-400.00 400.00-412.00 412.00-425.00	2.84 2.91 2.99	600.00-615.00 615.00-630.00 630.00-650.00	4.13 4.22 4.34
272.00-280.00 280.00-290.00 290.00-300.00	2.08 2.14 2.21	425.00-437.00 437.00-450.00 450.00-462.00	3.07 3.15 3.22	650.00-670.00	4.46
300.00-307.00 307.00-315.00 315.00-325.00	2.25 2.30 2.37	462.00-475.00 475.00-485.00 485.00-500.00	3.30 3.37 3.45

Company Features
1. DMS Seal Manufacturer is a high-tech company which integrates production, R&D, sales and service of buy o ring kit together. Dms Seals Technology Co.,limited always supplies nbr o ring manufacturers in high quality and competitive price. DMS Seal Manufacturer is famous for its high quality 35mm rubber o ring and considerate service.
2. We have a strong customer base overseas. We often invite them to meet our teams, see the product live, and invite them to engage in the product designs. These are the good ways that strengthen customers' trust towards us. The company's products are sold to the United States, Germany, Lebanon, Japan, Canada, etc. Besides, we have also successfully finished many domestic cooperations with well-known brands. Our production factory has a full set of advanced technical equipment and scientific quality management system. This enables us to provide reliable and high-quality products that are manufactured in line with regulations to clients.
3. We follow the tenet of "sincerity and customer-orientation". We encourage staff to hold a sincere and wholehearted attitude towards customers services. Earning and keeping trust is a priority. We promote open communication and respect for each other, creating a workplace where everyone can contribute, grow and be successful. We are committed to promoting our sustainable development. We are constantly improving our staff's environmental awareness and put it into our production activities.

DMS Seal Manufacturer buy o ring kit Supply in highly aggressive chemical processing
