DMS Seal Manufacturer cup seals for hydraulic cylinders Suppliers for pneumatic equipment

Company Advantages
1. The shoe materials of DMS Seal Manufacturer cup seals for hydraulic cylinders are sourced from suppliers who have a good relationship with us and who often help us make or find new or unique materials. DMS Seal manufacturer was established in 2008 and now has more than 10 years professional experience
2. The key to develop cup seals for hydraulic cylinders for Dms Seals Technology Co.,limited is that to satisfy customer needs, have creativity, and are highly marketable. Seal we produced has applications in a wide range of fields
3. The product is lightweight yet sturdy enough. The materials used in it are fiberglass and a dedicated system of lock supports it and keeps its components firmly in position as fitted. DMS Seals provides professional design and production of high-grade o-ring seals
4. The product has the advantage of chemical resistance. It can withstand the impacts of chemicals such as acids, salts, and alkalis. High-end talents and advanced technology have enabled DMS o-ring seal quality to reach the industry's leading level

1. Installation Recommendation

2. Application and properties

Suitable for long stroke, a wide range of fluids and high temperature occasions. The application of heavy duty double acting piston sealing under high pressure conditions is excellent. Applicable to larger piston clearance , it has good leakage control, extrusion resistance and wear resistance in heavy duty and construction machinery cylinder piston sealing system. Good static sealing property, simple groove structure, larger extrusion clearances can be allowed, be able to work in dusty condition.

3. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM

Back-up ring: POM / PA

4. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
50 - 350mm	0 - 50MPa	-30℃ +100℃	1.5 m/s	hydraulic oil, flame retardant liquid, water and others

5. Installation Dimensions

Nominal Size of Packing, and Housing dimensions			L+0.2	Order No.
D1	dN	H
50 55 60	36 41 46	8.5 8.5 8.5	9 9 9	SPGW50*36*8.5 SPGW55*41*8.5 SPGW60*46*8.5
63 65 70	48 50 55	10.5 10.5 10.5	11 11 11	SPGW63*48*10.5 SPGW65*50*10.5 SPGW70*55*10.5
75 80 85	60 65 70	10.5 10.5 10.5	11 11 11	SPGW75*60*10.5 SPGW80*65*10.5 SPGW85*70*10.5
90 95 100	75 80 85	10.5 10.5 12	11 11 12.5	SPGW90*75*10.5 SPGW95*80*10.5 SPGW100*85*12
105 110 115	90 95 100	12 12 12	12.5 12.5 12.5	SPGW105*90*12 SPGW110*95*12 SPGW115*100*12
120 125 130	105 102 107	12 15.5 15.5	12.5 16 16	SPGW120*105*12 SPGW125*102*15.5 SPGW130*107*15.5
135 140 145	112 117 122	15.5 15.5 15.5	16 16 16	SPGW135*112*15.5 SPGW140*117*15.5 SPGW145*122*15.5
150 155 160	127 132 137	15.5 15.5 15.5	16 16 16	SPGW150*127*15.5 SPGW155*132*15.5 SPGW160*137*15.5
165 170 180	142 147 157	15.5 15.5 15.5	16 16 16	SPGW165*142*15.5 SPGW170*147*15.5 SPGW180*157*15.5
185 190 200	162 167 177	15.5 15.5 15.5	16 16 16	SPGW185*162*15.5 SPGW190*167*15.5 SPGW200*177*15.5
210 220 225	187 197 202	15.5 15.5 17	16 16 17.5	SPGW210*187*15.5 SPGW220*197*15.5 SPGW225*202*15.5
230 240 250	207 217 222	17 17 17	17.5 17.5 17.5	SPGW230*207*15.5 SPGW240*217*15.5 SPGW250*222*17
260 270 280	232 242 252	17 17 17	17.5 17.5 17.5	SPGW260*232*17 SPGW270*242*17 SPGW280*252*17
300 320 350	272 292 322	17 17 17	17.5 17.5 17.5	SPGW300*272*17 SPGW320*292*17 SPGW350*322*17

Company Features
1. Dms Seals Technology Co.,limited has outstanding talents and technology advantages. The existing factory covers a large scale, with a fully automated penetration rate reaching over 50%. With such a large space, every production lines are arranged reasonably to coordinate the production.
2. Our factory has a number of advanced and sophisticated product testing instruments which are approved by authoritative institutions. This has brought to increased product quality and safety guarantee.
3. We have a highly efficient quality check team. They take meticulous steps to inspect all our products to meet the highest standards per our customer specifications. Dms Seals Technology Co.,limited ensures you to get the greatest and constant quality guarantee of cup seals for hydraulic cylinders . Call now!
