DMS Seal Manufacturer High-quality metric bonded seals Suppliers for threaded pipe fittings and plug sealing

Company Advantages
1. DMS Seal Manufacturer metric bonded seals is standardizationally produced.
2. DMS Seal Manufacturer is manufactured using high-grade materials sourced from reliable vendors.
3. The whole production of DMS Seal Manufacturer is finished by our professional craftsmen
4. The production of DMS Seal Manufacturer is empowered with the use of advanced tools and machines.
5. DMS Seal Manufacturer is made of superior quality raw materials coming from reliable vendors.
6. The product is tested at various stages of development.
7. We focus on new innovative functions while creating this product.
8. This product has passed a series of international certifications.
9. Quality is key to DMS Seal Manufacturer, so quality control is strictly implemented.
10. metric bonded seals from Dms Seals Technology Co.,limited sells well in the international market.
11. The product has been of great use and will be used more and more in the global market.
12. The product has significant development advantages compared to other product.
13. The prospects of this product have been steadily increasing over these years.
14. This product has a wide market application in the industry by virtue of outstanding features.
15. With diverse features, this product suits the modern requirements of the market.

1. Applicability

The BS/A bonded seals (automatic core-positioning) are applicable to threaded pipe fittings and plug sealing in Metric System, the Britain System and BSP. The location processing of sealing groove is not specially required, so it is ideal fittings for fast and automatic installation. Its service temperature is -30℃~100℃, working pressure less than 39.2MPa.

2. Figure

2. GM500 Self-centering range metric dimensions

Metric Thread size	Inside Diameter	Outside Diameter	Metal thickness	Metal washer ID	ID between self centering
	C	A	E	B	F
PPM6	6,50	10,00	1,00	8,00	5,60
PPM8	8,5	14,00	1,00	10,40	6,40
PPM10	10,50	16,00	2,00	12,40	8,05
PPM12	12,50	18,00	1,50	14,10	9,73
PPM14	14,5	20,00	2,00	16,40	11,38
PPM16	16,5	22,00	2,00	18,40	13,41
PPM18	18,5	25,00	2,00	20,40	14,76
PPM20	20,5	28,00	2,00	22,50	16,76
PPM22	22,5	30,00	2,00	24,40	18,74
PPM24	24,5	32,00	2,00	26,40	20,11
PPM27	27,2	35,00	2,00	29,40	23,30
PPM30	30,7	38,00	2,00	32,40	25,70
PPM33	33,5	42,00	2,00	35,40	28,70
PPM36	36.7	46,00	2,00	38,70	31.1
PPM39	41.9	51,00	2,00	40,00	34.1
PPM42	42.7	53,00	2,00	45,70	38.7
PPM48	48.7	60,00	2,00	51,70	43.7
PPM52	52.9	66,00	2,00	56,40	46
PPM60	60.9	75,00	2,00	63,00	-

3. GM500 Self-centering range inch dimensions, BSP

BSP thread size	Inside Diameter	Outside Diameter	Metal thickness	Metal washer ID	ID between self centering
	C	A	E	B	F
1/8 BSP	10,37	15,88	2,00	11,84	8,26
1/4 BSP	13,74	20,57	2,00	15,21	11,18
3/8 BSP	17,28	23,80	2,00	18,75	14,76
1/2 BSP	21,54	28,58	2,50	23,01	18,24
3/4 BSP	27,05	34,93	2,50	28,53	23,83
1 BSP	33,89	42,80	3,20	36,88	29,92
1 1/4 BSP	42,93	52,38	3,20	45,93	38,45
1 1/2 BSP	48,44	58,60	3,20	51,39	44,45
2 BSP	60,58	73,03	3,20	63,63	56,26



Company Features
1. With years of metric bonded seals production experience, Dms Seals Technology Co.,limited has continued to innovate and creates products to make the brand stand out in the market. Since the establishment, Dms Seals Technology Co.,limited has been focusing on production. Our strong manufacturing strength is a powerful driving force for further development. Dms Seals Technology Co.,limited is the global market leader of . Dms Seals Technology Co.,limited has been an industry expert who designed and fabricated a diverse range of bonded seals catalogue for many years.
2. Dms Seals Technology Co.,limited has advanced production equipment and excellent manufacturing technology. Dms Seals Technology Co.,limited has an expert R&D team, a management team, and an application service team. Its ability to innovate can surely lead the bonded seals supplier industry. With the help of persistent research and development of our professional engineers, our self centering bonded seals is very competent in the scope of quality.
3. Promoting Dms Seals Technology Co.,limited's core competence based on . Welcome to visit our factory! DMS Seal Manufacturer earnestly implements the principle of bonded seals and adheres to the principle of . Welcome to visit our factory! Dms Seals Technology Co.,limited is born of love and has undergone decades of years of transformation and innovation in o ring seal supplier industry. Welcome to visit our factory! It is the idea of 'Quality first, then Productivity' that helps Dms Seals Technology Co.,limited win high reputation. Welcome to visit our factory! Dms Seals Technology Co.,limited keeps innovating to develop new kind of metric bonded seals . Welcome to visit our factory!
