DMS Seal Manufacturer high quality rod seal catalogue with nbr or fkm o ring for sale

Company Advantages
1. [17] has good quality. It is guaranteed by examining the plastics and additives, glass, coating and frame material inspection procedures.
2. DMS Seal Manufacturer rod seal catalogue is finely designed. Its design is finished by considering many factors such as frame construction, control system design, mechanism design, and operating temperatures.
3. There are two kinds of screen color widely used for DMS Seal Manufacturer rod seal catalogue . One is the traditional white that has been in use for decades, and the other is a light to medium gray.
4. The product has the advantage of stable mechanical properties. Having been treated under extremely cold temperatures, its mechanical components are tensile enough to withstand extreme industrial conditions.
5. The product is distinguished by earthquake resistance. Made of heavy-duty materials and designed with strong construction, it can resist any form of sharp vibrations.
6. The product is not likely to accumulate too much heat. Its powerful cooling system is designed to maintain the proper temperature of mechanical parts, allowing it to have good heat dissipation.
7. The product has won customers from all over the world.
8. The product shows strong competitiveness in the industry.
9. This product is favored and trusted by customers.

1. Installation Recommendation

2. Installation Sizes

d e8	D H9	L D10	H
22-39	d+7.2	4.0	3.5
40-79	d+10.0	5.0	4.5
80-100	d+13.8	7.5	7.0
＞100-250	d+20.0	10.0	9.5
＞250-600	d+30.0	15.0	14.5
＞600	d+40.0	20.0	19.5

3. Application and properties

L-Ring support and guide to ensure a tight sealing environment. Easy installation, wear resistance, anti extrusion, low friction, non stick slip phenomenon.



4. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM

L-Ring: POM / PA

5. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3 - 1600mm	0 - 45MPa	-30℃ +100℃	1 m/s	hydraulic oil, flame retardant liquid, water, gas

6. Installation Dimensions

d e8	D1 H9	H	L D10	e	Order No.
22 25 28	29.2 32.2 35.2	3.5 3.5 3.5	4 4 4	6 6 6	RDI22*29.2*3.5 RDI25*32.2*3.5 RDI28*35.2*3.5
30 32 35	37.2 39.2 42.2	3.5 3.5 3.5	4 4 4	6 6 6	RDI30*37.2*3.5 RDI32*39.2*3.5 RDI35*42.2*3.5
36 40 42	43.2 50 52	3.5 4.5 4.5	4 5 5	6 6 6	RDI36*43.2*3.5 RDI40*50*4.5 RDI42*52*4.5
45 50 55	55 60 65	4.5 4.5 4.5	5 5 5	6 6 6	RDI45*55*4.5 RDI50*60*4.5 RDI55*65*4.5
56 60 63	66 70 73	4.5 4.5 4.5	5 5 7.5	6 7 7	RDI56*66*4.5 RDI60*70*4.5 RDI63*73*4.5
65 70 72	75 80 82	4.5 4.5 4.5	7.5 7.5 7.5	7 7 7	RDI65*75*4.5 RDI70*80*4.5 RDI72*82*4.5
75 80 85	85 93.8 98.8	4.5 7.0 7.0	7.5 7.5 7.5	7 7 7	RDI75*85*4.5 RDI80*93.8*7.0 RDI85*98.8*7.0
90 95 100	103.8 108.8 113.8	7.0 7.0 7.0	7.5 7.5 7.5	7 7 7	RDI90*103.8*7.0 RDI95*108.8*7.0 RDI100*113.8*7.0
105 110 115	125 130 135	9.5 9.5 9.5	10 10 10	10 10 10	RDI105*125*9.5 RDI110*130*9.5 RDI115*135*9.5
120 125 130	140 145 150	9.5 9.5 9.5	10 10 10	10 10 10	RDI120*140*9.5 RDI125*145*9.5 RDI130*150*9.5

Company Features
1. Since its beginning, Dms Seals Technology Co.,limited has been offering high-quality rod seals . Dms Seals Technology Co.,limited is among the very professional o-ring seal producers in China. As an internationally competitive producer, Dms Seals Technology Co.,limited has been largely engaged in O Ring Manufacturers . Dms Seals Technology Co.,limited has been focusing on the production of high-quality hydraulic rod seals since inception. Dms Seals Technology Co.,limited is China's leading rod seals manufacturer.
2. Dms Seals Technology Co.,limited has a first-class technical team responsible for rod seals product development. Dms Seals Technology Co.,limited fully makes use of its high technology to the production of rod seals . The strong technical force and scientific management of Dms Seals Technology Co.,limited have continuously refurbished the products and thus won the market. Dms Seals Technology Co.,limited has professional R&D team and management team, and currently has several national patents. Dms Seals Technology Co.,limited has imported machines and exquisite techniques.
3. Dms Seals Technology Co.,limited has always pursued excellence and professionalism in the rod seals field. Check now! We believe that our success is built on the trust we earned from clients. We work shoulder-to-shoulder with our clients to solve complex challenges in ways that minimize business risk and maximize opportunity. Check now! In order to meet market demand, Dms Seals Technology Co.,limited will adhere to the long-term improvement of rod seals . Check now!
