DMS Seal Manufacturer hydraulic cylinder seals and wipers with nbr or fkm o ring for pneumatic equipment 1

DMS Seal Manufacturer hydraulic cylinder seals and wipers with nbr or fkm o ring for pneumatic equipment 2

DMS Seal Manufacturer hydraulic cylinder seals and wipers with nbr or fkm o ring for pneumatic equipment

Diameter Range:

3-1600mm

Pressure Range:

0-35MPa

Temperature Range:

-30℃+200℃

Speed:

1.5m/s

Medium:

hydraulic oil, flame retardant liquid, water and others.

Inquiry

Product Comparison

Closely following the market trend, Dms Seals uses advanced production equipment and manufacturing technology to produce Oil Seal Manufacturer. The product receives favors from the majority of customers for the high quality and favorable price.Supported by advanced technology, Dms Seals has a great breakthrough in the comprehensive competitiveness of Oil Seal Manufacturer, as shown in the following aspects.

Company Advantages
1. The design of is very innovative following the latest design trends in the industry.
2. The production of DMS Seal Manufacturer hydraulic cylinder seals and wipers uses well-selected materials to meet different needs.
3. DMS Seal Manufacturer is made of selected materials that are of high quality.
4. The offered DMS Seal Manufacturer is produced using advanced production technology that is adopted in the whole process.
5. Our quality controllers are responsible for continuous small changes to keep production within the specified parameters and to ensure product quality.
6. The product is strictly checked by the quality inspection department. From the raw material to the shipment process, the defective product is not allowed to enter the market.
7. Our professional quality control team and authoritative third parties have conducted a serious and rigorous review of product quality.
8. Strengthening the service quality will be conducive to the development of DMS Seal Manufacturer.
9. Dms Seals Technology Co.,limited upholds the most professional and most responsible service concept.
10. The quality of hydraulic cylinder seals and wipers is assured by our strict quality control system.
11. Dms Seals Technology Co.,limited's consistent purpose is to be ready to render excellent service to customers.
12. Dms Seals Technology Co.,limited strictly takes control of quality from material purchase to package.

Installation Recommendation

undefined

Application and properties

Suitable for light and medium hydraulic systems, also be used for pneumatic equipment. Low friction, no crawling phenomenon.

Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM

Working Conditions

Working Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3-1600mm	0-35MPa	-30℃+200℃	1.5 m/s	hydraulic oil, flame retardant liquid, water and others.

Installation Dimensions

Nominal Size of Packing, and Housing dimensions			L +0.2	Order No.
d	D	H	L +0.2	Order No.
28 28.4 30	22 22.4 24	4.4 4.4 4.4	4.7 4.7 4.7	SPGC28224.7 SPGC28.422.44.7 SPGC30244.7
31 31.5 34	25 25.5 28	4.4 4.4 4.4	4.7 4.7 4.7	SPGC31254.7 SPGC31.525.54.7 SPGC34284.7
35 35.5 36	29 29.5 30	4.4 4.4 4.4	4.7 4.7 4.7	SPGC35294.7 SPGC35.529.54.7 SPGC36304.7
37 37.5 38	31 31.5 32	4.4 4.4 4.4	4.7 4.7 4.7	SPGC37314.7 SPGC37.531.54.7 SPGC38324.7
40 41 41.5	34 35 35.5	4.4 4.4 4.4	4.7 4.7 4.7	SPGC40344.7 SPGC41354.7 SPGC41.535.54.7
42 44 45	36 38 39	4.4 4.4 4.4	4.7 4.7 4.7	SPGC42364.7 SPGC44384.7 SPGC45394.7
46 47 48	40 41 42	4.4 4.4 4.4	4.7 4.7 4.7	SPGC46404.7 SPGC47414.7 SPGC48424.7
50 51 52	44 45 46	4.4 4.4 4.4	4.7 4.7 4.7	SPGC50444.7 SPGC51454.7 SPGC52464.7
54 55 56	48 49 50	4.4 4.4 4.4	4.7 4.7 4.7	SPGC54484.7 SPGC55494.7 SPGC56504.7
58 60 62	48 50 52	4.4 4.4 4.4	4.7 4.7 4.7	SPGC58484.7 SPGC60504.7 SPGC62524.7
63 65 66	53 55 56	4.4 4.4 4.4	4.7 4.7 4.7	SPGC63534.7 SPGC65554.7 SPGC66564.7
68 70 72	58 60 62	7.0 7.0 7.0	7.5 7.5 7.5	SPGC68587.5 SPGC70607.5 SPGC72627.5

Installation Dimensions

Company Features
1. With years of efforts, Dms Seals Technology Co.,limited strategically intends to be a crucial hydraulic cylinder seals and wipers manufacturer and service supplier. Dms Seals Technology Co.,limited surpasses other companies regarding the manufacturing of pneumatic cylinder rod seal of high quality. Dms Seals Technology Co.,limited is a well-respected company that produces a full range piston lip seal .
2. Dms Seals Technology Co.,limited has internationally leading product development capabilities. DMS Seal Manufacturer enjoys good reputation for its highly advanced technology. DMS Seal Manufacturer has successfully developed the technology for the production of hydraulic cylinder piston seal leakage .
3. Looking ahead, the company will continue to strive for superior performance with innovative, unique, and superior products and services. Ask! We strive to optimize and control our water consumption, reduce the risk of polluting supply sources and ensure good quality water for our manufacturing through monitoring and recycling systems. With the goal of "forever exceeding customer expectations", we will continue to refine unique products and continue to lead the world with unremitting efforts and innovative ideas. Ask! Customer satisfaction is our corporate philosophy and the cornerstone of all our activities by determining the direction of our pursuit and values. Ask! Our firm bears societal obligation. We try to minimize waste production by means of a dozen waste reduction initiatives. A number of our manufacturing lines have attained 0 waste creation.

DMS Seal Manufacturer hydraulic cylinder seals and wipers with nbr or fkm o ring for pneumatic equipment

hydraulic cylinder seals and wipers

Type:

DMS Seal Manufacturer hydraulic cylinder seals and wipers with nbr or fkm o ring for pneumatic equipment 7

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
