DMS Seal Manufacturer hydraulic pump seals suppliers manufacturers for light and medium hydraulic systems

Company Advantages
1. DMS Seal Manufacturer is made by using the best grades of materials in our modern manufacturing facilities. DMS Seal manufacturer provides good quality and competitive price hydraulic seals
2. The product is widely accepted by our customers and it will become a hot product in the industry. DMS Seal manufacturer is a technology enterprise which specialized in the R&D and production of seals
3. The product has an aesthetic appealing. Its delicate carving, etching, embossed pattern, or wooden texture are manually done to enhance the decor elegance. High-end talents and advanced technology have enabled DMS o-ring seal quality to reach the industry's leading level
4. The product can provide clean water with good taste. The activated carbon in its filter element system can effectively absorb the disagreeable tastes, odors, and chlorine to improve the taste. The R&D teams have the ability to design and develop seals for various of complicated working condition of sealing system
5. The product has a reasonable energy storage equipment. It stores solar energy into its battery and provides electricity at night or on rainy days. The high pressure seals have strong wear resistance to hard conditions

1. Installation Recommendation

DBM/TPM is a double acting sealing and guiding element, Consisting of an elastomer, two back-up rings and two guide rings. Dynamic and static properties of the elastomer play a good sealing role, The back-up ring prevents the elastomer from being squeezed into the sealing gap, the function of the guide ring is to guide the piston in the cylinder and absorb the radial force. The sealing is mainly used for piston and hydraulic cylinder, such as bulldozers, excavators, loaders, hydraulic gates and agricultural machinery.

Guide ring: filled PTFE / PA

Back-up ring: TPU polymer

Elastomer: NBR

4. Working Conditions

Cylinder Dia.	Groove Size					Order No.
DN H9	d1	L1 +0.2	d2 h9	d3 h11	L2 +0.1
20 22 25	11 13 15	13.5 13.5 12	17 19 21	19 21 23	2.1 2.1 4	TPM20*11*13.5*2.1 TPM22*13*13.5*2.1 TPM25*15*12*4
25 25 25	15 15 16	12.5 16.4 13.5	22 21.45 22	24 23.5 24	4 6.35 2.1	TPM25*15*12.5*4 TPM25*15*16.4*6.35 TPM25*16*13.5*2.1
28 30 30	19 17 21	13.5 15.4 13.5	25 26.5 27	27 28.5 29	2.1 6.35 2.1	TPM28*19*13.5*2.1 TPM30*17*15.4*6.35 TPM30*21*13.5*2.1
32 32 35	22 22 25	15.5 16.4 15.5	28 28.5 31	31 30.5 34	2.6 6.35 2.6	TPM32*22*15.5*2.6 TPM32*22*16.4*6.35 TPM35*25*15.5*2.6
35 40 40	25 24 26	16.4 18.4 15.5	31.4 35.4 36	33.5 38.5 39	6.35 6.35 2.6	TPM35*25*16.4*6.35 TPM40*24*18.4*6.35 TPM40*26*15.5*2.6
40 40 40	30 30 30	12.5 12.5 16.4	36 37 35.4	38 39 38.5	4 4 6.35	TPM40*30*12.5*4 TPM40*30*12.5*4 TPM40*30*16.4*6.35
42 45 45	28 29 31	15.5 18.4 15.5	38 40.4 41	41 43.5 44	2.6 6.35 2.6	TPM42*28*15.5*2.6 TPM45*29*18.4*6.35 TPM45*31*15.5*2.6
45 50 50	35 34 34	16.4 18.4 20.5	40.4 45.4 46	43.5 48.5 49	6.35 6.35 3.1	TPM45*35*16.4*6.35 TPM50*34*18.4*6.35 TPM50*34*20.5*3.1
55 55 56	39 39 40	18.4 20.5 20.5	50.36 51 52	53.5 54 55	6.35 3.1 3.1	TPM55*39*18.4*6.35 TPM55*39*20.5*3.1 TPM56*40*20.5*3.1
60 60 63	44 44 47	18.4 20.5 18.4	55.4 56 58.4	58.5 59 61.5	6.35 3.1 6.35	TPM60*44*18.4*6.35 TPM60*44*20.5*3.1 TPM63*47*18.4*6.35
63 63 65	47 47 49	19.4 20.5 20.5	58.4 59 61	61.5 62 64	6.35 3.1 3.1	TPM63*47*19.4*6.35 TPM63*47*20.5*3.1 TPM65*49*20.5*3.1
65 70 70	50 50 54	18.4 22.4 20.5	60.4 64.2 66	63.5 68.3 69	6.35 6.35 3.1	TPM65*50*18.4*6.35 TPM70*50*22.4*6.35 TPM70*54*20.5*3.1



Company Features
1. While developing the scale of market, DMS Seal Manufacturer has been always expanding the range of exported hydraulic pump seals suppliers . We have employees that are well educated and trained. They have a keen sense of responsibility to improve the quality of process outputs by identifying and removing the causes of defects.
2. Our factory runs with a strict supply chain management system. This system guarantees the day-to-day flow of goods and raw materials, which in return helps the factory regulate and coordinate production plans.
3. We have employed a team of talented personnel. Their expert knowledge and commitment are the basis for the high quality which our customers rightfully expect from our company. The sustained development of DMS Seal Manufacturer can not be achieved without strong enterprise culture. Please contact us!
