DMS Seal Manufacturer Latest neoprene rubber o rings company in highly aggressive chemical processing

Company Advantages
1. DMS Seal Manufacturer has gone through a range of performance pertinent tests. They primarily involve fatigue resistance testing, structural bearing capacity, adhesion, and moisture resistance.
2. The design of DMS Seal Manufacturer is carried out based on some fundamental factors. They are comfort, breathability, safety, color matching, and appearance.
3. A number of tests for DMS Seal Manufacturer neoprene rubber o rings have been conducted. These tests include tensile strength testing, flexing testing, density testing, and compression testing.
4. The product has excellent heat resistance capacity. It is able to withstand the high temperature during the barbeque without shape deformation or bend.
5. The product is less likely to cause any side effects. The clinically tested ingredients contain no harmful substances to affect the function of the body.
6. The product is able to withstand strong wind power. Adopting the bar tensioning system, it has a more stable structure.
7. The product is skin-friendly. The fibers have a smooth feel and a natural wicking action that keeps moisture away from the skin.
8. This product features a fast and accurate reaction to the writing or drawing. Its high level of pressure sensitivity makes the lines flow smoother.
9. Powered fully by solar energy, the product is especially popular in places where electricity is not convenient and expensive to afford.
10. Ensuring that the image projected on it is flat and clearly visible from multiple angles, it is one of the best portable project screens on the list.
11. The product offers the right solution for the home user who is looking for user-friendly and excellent swimming pool cleaning performance product.
12. This smart product helps shift electricity demand away from peak periods. It cuts the burden on the city's electricity supply system.

1. Installation Recommendation

2. Application and properties

Double acting seals, the sealing effect is achieved by the deformation of the section of the O-Rings, and the deformation is determined by the depth of the installation groove. Under pressure, the O-ring has a large surface tension like liquid, used for static sealing more. It is only recommended for better conditions in dynamic applications. System lubrication, pressure, temperature, sealing clearance, speed, medium and surface quality of metal parts determine the service life of O-Rings. It is not recommended if the lubrication is not sufficient during rotary motion.

3. Standard materials

Silicone

4. Performance parameter

	Static Seal	Dynamic Seal
Working Pressure	No support ring, up to 20MPa; With the support ring, up to 40MPa; With special support ring, up to 200MPa.	No support ring, up to 5MPa; With the support ring, higher pressure.
Movement Speed	Maximum reciprocating speed up to 0.5m / s; maximum rotation speed up to 2.0m/s.
Temperature	NBR: -30℃ - 100℃;  FKM: -20℃ - 220℃.

5. Wire Diameter Tolerance

Wire diameter of O-Ring (mm)	Tolerance (±mm)
0-1.8	0.08
1.80-2.65	0.09
2.65-3.55	0.10
3.55-5.30	0.13
5.30-7.00	0.15
7.00-8.00	0.18
8.00-10.00	0.21
10.00-12.00	0.25



6. Inner diameter tolerance

Inner Diameter d1 mm	Tolerance ±mm	Inner Diameter d1 mm	Tolerance ±mm	Inner Diameter d1 mm	Tolerance ±mm
0.70-2.50 2.50-4.50 4.50-6.30	0.13 0.14 0.15	43.70-45.00 46.00-46.20 46.20-47.50	0.42 0.43 0.44	95.00-97.50 97.50-100.00 100.00-103.00	0.83 0.84 0.87
6.30-8.50 8.50-10.00 10.00-11.20	0.16 0.17 0.18	47.50-48.70 48.70-50.00 50.00-51.50	0.45 0.46 0.47	103.00-106.00 106.00-109.00 109.00-112.00	0.89 0.91 0.93
11.20-14.00 14.00-16.00 16.00-18.00	0.19 0.20 0.21	51.50-53.00 53.00-54.50 54.50-56.00	0.48 0.50 0.51	112.00-115.00 115.00-118.00 118.00-122.00	0.95 0.97 1.00
18.00-20.00 20.00-21.20 21.20-23.60	0.22 0.23 0.24	56.00-58.00 58.00-60.00 60.00-61.50	0.52 0.54 0.55	122.00-125.00 125.00-128.00 128.00-132.00	1.03 1.05 1.08
23.60-25.00 25.00-26.50 26.50-28.00	0.25 0.26 0.28	61.50-63.00 63.00-65.00 65.00-67.00	0.56 0.58 0.59	132.00-136.00 136.00-140.00 140.00-145-00	1.10 1.13 1.17
28.00-30.00 30.00-31.50 31.50-33.50	0.29 0.31 0.32	67.00-69.00 69.00-71.00 71.00-73.00	0.61 0.63 0.64	145.00-150.00 150.00-155.00 155.00-160.00	1.20 1.24 1.27
33.50-34.50 34.50-35.50 35.50-36.50	0.33 0.34 0.35	73.00-75.00 75.00-77.50 77.50-80.00	0.66 0.67 0.69	160.00-165.00 165.00-170.00 170.00-175.00	1.31 1.34 1.38
36.50-37.50 37.50-38.70 38.70-40.00	0.36 0.37 0.38	80.00-82.50 82.50-85.00 85.00-87.50	0.71 0.73 0.75	175.00-180.00 180.00-185.00 185.00-190.00	1.41 1.44 1.48
40.00-41.20 41.20-42.50 42.50-43.70	0.39 0.40 0.41	87.50-90.00 90.00-92.50 92.50-95.00	0.77 0.79 0.81	190.00-195.00 195.00-200.00 200.00-206.00	1.51 1.55 1.59
206.00-212.00 212.00-218.00 224.00-230.00	1.63 1.71 1.75	325.00-335.00 335.00-345.00 345.00-355.00	2.43 2.49 2.56	500.00-515.00 515.00-530.00 530.00-545.00	3.54 3.63 3.72
230.00-236.00 236.00-243.00 243.00-250.00	1.79 1.83 1.88	355.00-365.00 365.00-375.00 375.00-387.00	2.62 2.68 2.76	545.00-560.00 560.00-580.00 580.00-600.00	3.81 3.93 4.05
250.00-258.00 258.00-265.00 265.00-272.00	1.93 1.98 2.02	387.00-400.00 400.00-412.00 412.00-425.00	2.84 2.91 2.99	600.00-615.00 615.00-630.00 630.00-650.00	4.13 4.22 4.34
272.00-280.00 280.00-290.00 290.00-300.00	2.08 2.14 2.21	425.00-437.00 437.00-450.00 450.00-462.00	3.07 3.15 3.22	650.00-670.00	4.46
300.00-307.00 307.00-315.00 315.00-325.00	2.25 2.30 2.37	462.00-475.00 475.00-485.00 485.00-500.00	3.30 3.37 3.45

Company Features
1. Dms Seals Technology Co.,limited has been concentrated on the production of neoprene rubber o rings . Over the years, we've been fortunate to earn reputation from customers around the world. Dms Seals Technology Co.,limited has earned a good reputation for the manufacture of in China. We have been regarded as a reliable manufacturer. For so many years, Dms Seals Technology Co.,limited is regarded as a reliable and trustworthy manufacturer for our clients and suppliers.
2. Our technology takes the lead in the industry of square o ring sizes . we have successfully developed a variety of cheap o rings series. With the unique technology and stable quality, our 4.5 inch o ring win a wider and wider market gradually. Our rubber o rings perth is easily operated and need no additional tools.
3. We will do our best to meet the needs of our customers on . Check it! Winning more overseas market share is what we pursue now. Under the technological support, we will strive hard to win over customers by quality and service. Our company has recognized the importance of practicing sound environmental policies to create a healthy living condition for future generations. We also encourage our employees to embrace our company's value and work together to make it true. Check it!
