DMS Seal Manufacturer Latest push rod seal for business for sale

Company Advantages
1. is taken into account in terms of design structure of push rod seal.
2. push rod seal we produced is characterized by its .
3. Our goods are greatly appreciated in other markets for its .
4. push rod seal adopts new environmentally-friendly material.
5. Our strict quality management system maintains the excellent performance and quality of our products.
6. The product quality is fine, has passed the international authentication.
7. The product is regularly reviewed for quality to ensure reliable quality.
8. Our experienced quality inspectors have carried out a comprehensive performance test on the performance and durability of the products according to international standards.
9. push rod seal is available for and international certificate as .
10. Dms Seals Technology Co.,limited's product structure is reasonable and its categories are complete.
11. Dms Seals Technology Co.,limited has taken advantage of various means to promote the competitiveness of its push rod seal.

1. Installation Recommendation

2. Application and properties

Applicable to a wide range of pressure work and sliding high speed occasions. Standard combined seal. Low friction, strong wear resistance.

3. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM





4. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3 - 1600mm	0 - 35MPa	-30℃ + 200℃	1.5m/s	general hydraulic oil, water glycol hydraulic oil, oil / water emulsion type hydraulic oil.

5. Installation Dimensions

Nominal Size of Packing, and Housing dimensions				Order No.
d	D	H	L +0.2
12 14 16	18 20 22	3.0 3.0 3.0	3.2 3.2 3.2	SPNO12*18*3.2 SPNO14*20*3.2 SPNO16*22*3.2
18 20 22	24 26 31	3.0 3.0 3.8	3.2 3.2 4	SPNO18*24*3.2 SPNO20*26*3.2 SPNO22*31*4
25 28 30	34 37 39	3.8 3.8 3.8	4 4 4	SPNO25*34*4 SPNO28*37*4 SPNO30*39*4
32 36 40	41 45 49	3.8 3.8 3.8	4 4 4	SPNO32*41*4 SPNO36*45*4 SPNO40*49*4
45 50 56	54 65 71	3.8 6.3 6.3	4 6.5 6.5	SPNO45*54*4 SPNO50*65*6.5 SPNO56*71*6.5
60 63 70	75 78 85	6.3 6.3 6.3	6.5 6.5 6.5	SPNO60*75*6.5 SPNO63*78*6.5 SPNO70*85*6.5
75 80 85	90 95 100	6.3 6.3 6.3	6.5 6.5 6.5	SPNO75*90*6.5 SPNO80*95*6.5 SPNO85*100*6.5
90 95 100	105 110 115	6.3 6.3 6.3	6.5 6.5 6.5	SPNO90*105*6.5 SPNO95*110*6.5 SPNO100*115*6.5
105 110 115	120 125 130	6.3 6.3 6.3	6.5 6.5 6.5	SPNO105*120*6.5 SPNO110*125*6.5 SPNO115*130*6.5
120 125 130	135 140 145	6.3 6.3 6.3	6.5 6.5 6.5	SPNO120*135*6.5 SPNO125*140*6.5 SPNO130*145*6.5
135 140 145	150 155 160	6.3 6.3 6.3	6.5 6.5 6.5	SPNO135*150*6.5 SPNO140*155*6.5 SPNO145*160*6.5
150 160 170	170 180 190	9.8 9.8 9.8	10 10 10	SPNO150*170*10 SPNO160*180*10 SPNO170*190*10

Company Features
1. Dms Seals Technology Co.,limited aims to be a world's leading manufacturer of push rod seal. The hydraulic rod seals is well crafted by the very professional Dms Seals Technology Co.,limited. Dms Seals Technology Co.,limited is a professional manufacturer of hydraulic rod seals . Since inception, Dms Seals Technology Co.,limited has begun to manufacture superiority O Ring Manufacturers . Dms Seals Technology Co.,limited has grown to a big manufacturing company that mainly produces o-ring seal .
2. The innovative technology endows the piston rod seal with extended service life. With abundant technical strength, DMS Seal Manufacturer is really competitive in hydraulic rod seals online industry. DMS Seal Manufacturer has advanced technology to be implemented in the production of rod seal catalogue . DMS Seal Manufacturer attaches great importance to the value of technical strength to the quality of pneumatic rod seals . In Dms Seals Technology Co.,limited, QC rigorously implements all the aspect of production phases from prototype to finished product.
3. Customer satisfaction is the business goal of Dms Seals Technology Co.,limited. Welcome to visit our factory! Dms Seals Technology Co.,limited will provide our customers with a comprehensive rod seals solution. Welcome to visit our factory! We have been engaged in push rod seal industry for many years and can guarantee high quality. Welcome to visit our factory!

DMS Seal Manufacturer Latest push rod seal for business for sale

push rod seal

Type:
