DMS Seals - Hydraulic Seals and Oil Ring Seals Manufacturer & Supplier
DMS Seal Manufacturer New oil seal hydraulic for light and medium hydraulic systems
- Dms Seals provides competitive solutions and services based on customer demand,
1. DMS Seal Manufacturer is developed in line with international safety standards for electrical equipment. It is guaranteed by these standards to run safely.
2. DMS Seal Manufacturer oil seal hydraulic is manufactured complying with the mandatory standards for the textile industry. Its raw materials and the agents are required to pass the ingredient test to guarantee no harmful substances are contained.
3. DMS Seal Manufacturer oil seal hydraulic will be inspected in terms of electrical safety regulations. It has to pass through safety tests including electrostatic discharge test, EMC test, electrical leakage test, etc.
4. All aspects of the product, such as performance, durability, usability, etc., are carefully tested and tested before production and delivery.
5. Our quality management system ensures that the product meets with the international quality standards.
6. Our professional technical team greatly optimizes the performance of our products.
7. By using this product, business owners can reduce or completely eliminate human intervention in a production process, which improves the overall efficiency.
8. This product has bright colors and appealing contents. It can effectively help packaged items to attract new customers.
9. This product will thus help to enhance people's work efficiency. Its automation makes many tasks easier and be finished faster.
Bore Diameter DN H9 | Groove Diameter | Groove Width | Radius | Radial Clearance S max. | O-Ring Cross-Section | ||||
Standard Application | Light Application | Heavy Duty Application | d1 h9 | L1+0.2 | R1 | 10MPa | 20MPa | 40MPa | d2 |
8-16.9 | 17-26.9 | -- | DN-4.9 | 2.2 | 0.4 | 0.30 | 0.20 | 0.15 | 1.78 |
17-26.9 | 27-59.9 | -- | DN-7.3 | 3.2 | 0.6 | 0.40 | 0.25 | 0.15 | 2.62 |
27-59.9 | 60-199.9 | 17-26.9 | DN-10.7 | 4.2 | 1.0 | 0.50 | 0.30 | 0.20 | 3.53 |
60-199.9 | 200-255.9 | 27-59.9 | DN-15.1 | 6.3 | 1.3 | 0.70 | 0.40 | 0.25 | 5.33 |
200-255.9 | 256-669.9 | 60-199.9 | DN-20.5 | 8.1 | 1.8 | 0.80 | 0.60 | 0.35 | 7.00 |
256-669.9 | 670-999.9 | 200-669.9 | DN-24.0 | 8.1 | 1.8 | 0.90 | 0.70 | 0.40 | 7.00 |
670-999.9 | -- | 256-669.9 | DN-28.0 | 9.5 | 2.5 | 1.00 | 0.80 | 0.60 | 8.40 |
-- | 1000-2000 | -- | DN-28.0 | 9.5 | 2.5 | 1.00 | 0.80 | 0.60 | 8.40 |
-- | -- | 670-999.9 | DN-38.0 | 13.8 | 3.0 | 1.20 | 0.90 | 0.60 | 12.00 |
1000-2700 | -- | -- | DN-38.0 | 13.8 | 3.0 | 1.20 | 0.90 | 0.60 | 12.00 |
Application and properties
Standard single acting sealing. Suitable for reciprocating environment, allowing larger extrusion clearances, has wide application. Dynamic and static sealing property are good, be able to work in dusty condition. Low friction, simple groove, strong adaptability to work conditions.
Standard materials
Sealing ring: filled PTFE
O-ring: NBR / FKM
Working Conditions | ||||
Diameter Range | Pressure Range | Temperature Range | Speed | Medium |
3-1600mm | 0-60MPa | -45℃ +200℃ | 15 m/s | hydraulic oil, flame retardant liquid, water and others |
Bore Dia. | Groove Dia. | Width | Order No. | O-ring Dimension |
D H9 | d1 h9 | L1+0.2 | ||
9 | 4.1 | 2.2 | GSD9*4.1*2.2 | 3.68*1.78 |
15 | 10.1 | 2.2 | GSD15*10.1*2.2 | 9.25*1.78 |
20 | 12.7 | 3.2 | GSD20*12.7*3.2 | 12.37*2.62 |
27 | 16.3 | 4.2 | GSD27*16.3*4.2 | 15.47*3.53 |
32 | 24.7 | 3.2 | GSD32*24.7*3.2 | 23.47*2.62 |
36 | 25.3 | 4.2 | GSD36*25.3*4.2 | 24*3.53 |
40 | 29.9 | 4.2 | GSD40*29.3*4.2 | 28.17*3.53 |
50 | 39.3 | 4.2 | GSD50*39.3*4.2 | 37.70*3.53 |
55 | 44.3 | 4.2 | GSD55*44.3*4.2 | 44.04*3.53 |
63 | 47.9 | 6.3 | GSD63*47.9*6.3 | 46.99*5.33 |
70 | 59.3 | 4.2 | GSD70*59.3*4.2 | 56.74*3.53 |
80 | 64.9 | 6.3 | GSD80*64.9*6.3 | 62.87*5.33 |
90 | 74.9 | 6.3 | GSD90*74.9*6.3 | 72.39*5.33 |
95 | 74.5 | 8.1 | GSD95*74.5*8.1 | 73*7.0 |
110 | 94.9 | 6.3 | GSD110*94.9*6.3 | 91.44*5.33 |
Company Features
1. Dms Seals Technology Co.,limited surpasses many other manufacturers who specialize in the R&D and production of . We are a well-known expert in this field. We are a long-time and reliable manufacturer of and a distributor of related products in China. Being the front-runner of oil seal hydraulic industry, Dms Seals Technology Co.,limited concentrates on the research, development, and manufacture products with the most competitive prices for many years.
2. Dms Seals Technology Co.,limited have several production lines to guarantee quality and on-time delivery. Our customers seldom complain about quality of hydraulic piston seals . Strong strength and advanced machine ensure DMS Seal Manufacturer to develop better and higher quality pneumatic seals catalogue . Precise manufacture of shaft wiper seal is critical to Dms Seals Technology Co.,limited's success.
3. We are committed to sustainable practices in all that we do. It dictates how we source materials, how we design and manufacture products, and how those products are shipped and delivered. Sustainability is our promise to the environment. Inquire online! We are committed to developing and operating our services in a sustainable manner. Our policy is to maximize the positive economic and social benefits received by the local environment. In addition to the improvements for piston rod seals hydraulic , we will continue to improve services. Inquire online! We always require employees to adhere to the principle of hard-working and efficient. We are determined to be a leader in this industry by helping clients create economic value. We promote collaborative efforts through business cooperation in protecting the environment. We will conduct environmental impact assessments for each other, making sure all of our practices are in line with the environmental legislations.
