DMS Seal Manufacturer nitrile hydraulic wiper seals for sale

Company Advantages
1. DMS Seal Manufacturer hydraulic wiper seals is designed and manufactured using high-quality material and the latest techniques in compliance with industry standards.
2. The material of DMS Seal Manufacturer hydraulic wiper seals is controlled to be just right.
3. DMS Seal Manufacturer hydraulic wiper seals is accomplished with the help of our sophisticated workers.
4. DMS Seal Manufacturer O Ring Manufacturer is quite attractive with its design.
5. The product is durable enough. It is made of high-hardness materials and treated under high temperature, thus it is not vulnerable to damage.
6. The product features an efficient retractable mechanism. The top and bottom rail of each panel incorporate an extruded aluminum mechanical seal to withstand the retracted or extended mode.
7. The product features high heat resistance, which allows it to stand up the test in a flame environment for sterilizing.
8. The product provides a sound seal system. The vertical seal of each panel is made of thick and tongue-type extruded aluminum laminated with a rubber seal.
9. This product would benefit business owners a lot. It allows the production projects to be finished in a short time, which reduces the waste of time.
10. This product can help people finish tasks that are too heavy or difficult. It significantly reduces the work burden for people.
11. By using this product, business owners will less likely to witness workplace accidents and workman’s compensation claims.
12. The product can significantly liberate people from heavy-duty and monotonous work, allowing people to spend time focusing on other important tasks.
13. Thanks to its easy operation and maintenance during its service life, this product can greatly help reduce operation costs.

1. Installation Recommendation

2. Application and properties

Double acting seals, the sealing effect is achieved by the deformation of the section of the O-Rings, and the deformation is determined by the depth of the installation groove. Under pressure, the O-ring has a large surface tension like liquid, used for static sealing more. It is only recommended for better conditions in dynamic applications. System lubrication, pressure, temperature, sealing clearance, speed, medium and surface quality of metal parts determine the service life of O-Rings. It is not recommended if the lubrication is not sufficient during rotary motion.

3. Standard materials

Silicone

4. Performance parameter

	Static Seal	Dynamic Seal
Working Pressure	No support ring, up to 20MPa; With the support ring, up to 40MPa; With special support ring, up to 200MPa.	No support ring, up to 5MPa; With the support ring, higher pressure.
Movement Speed	Maximum reciprocating speed up to 0.5m / s; maximum rotation speed up to 2.0m/s.
Temperature	NBR: -30℃ - 100℃;  FKM: -20℃ - 220℃.

5. Wire Diameter Tolerance

Wire diameter of O-Ring (mm)	Tolerance (±mm)
0-1.8	0.08
1.80-2.65	0.09
2.65-3.55	0.10
3.55-5.30	0.13
5.30-7.00	0.15
7.00-8.00	0.18
8.00-10.00	0.21
10.00-12.00	0.25



6. Inner diameter tolerance

Inner Diameter d1 mm	Tolerance ±mm	Inner Diameter d1 mm	Tolerance ±mm	Inner Diameter d1 mm	Tolerance ±mm
0.70-2.50 2.50-4.50 4.50-6.30	0.13 0.14 0.15	43.70-45.00 46.00-46.20 46.20-47.50	0.42 0.43 0.44	95.00-97.50 97.50-100.00 100.00-103.00	0.83 0.84 0.87
6.30-8.50 8.50-10.00 10.00-11.20	0.16 0.17 0.18	47.50-48.70 48.70-50.00 50.00-51.50	0.45 0.46 0.47	103.00-106.00 106.00-109.00 109.00-112.00	0.89 0.91 0.93
11.20-14.00 14.00-16.00 16.00-18.00	0.19 0.20 0.21	51.50-53.00 53.00-54.50 54.50-56.00	0.48 0.50 0.51	112.00-115.00 115.00-118.00 118.00-122.00	0.95 0.97 1.00
18.00-20.00 20.00-21.20 21.20-23.60	0.22 0.23 0.24	56.00-58.00 58.00-60.00 60.00-61.50	0.52 0.54 0.55	122.00-125.00 125.00-128.00 128.00-132.00	1.03 1.05 1.08
23.60-25.00 25.00-26.50 26.50-28.00	0.25 0.26 0.28	61.50-63.00 63.00-65.00 65.00-67.00	0.56 0.58 0.59	132.00-136.00 136.00-140.00 140.00-145-00	1.10 1.13 1.17
28.00-30.00 30.00-31.50 31.50-33.50	0.29 0.31 0.32	67.00-69.00 69.00-71.00 71.00-73.00	0.61 0.63 0.64	145.00-150.00 150.00-155.00 155.00-160.00	1.20 1.24 1.27
33.50-34.50 34.50-35.50 35.50-36.50	0.33 0.34 0.35	73.00-75.00 75.00-77.50 77.50-80.00	0.66 0.67 0.69	160.00-165.00 165.00-170.00 170.00-175.00	1.31 1.34 1.38
36.50-37.50 37.50-38.70 38.70-40.00	0.36 0.37 0.38	80.00-82.50 82.50-85.00 85.00-87.50	0.71 0.73 0.75	175.00-180.00 180.00-185.00 185.00-190.00	1.41 1.44 1.48
40.00-41.20 41.20-42.50 42.50-43.70	0.39 0.40 0.41	87.50-90.00 90.00-92.50 92.50-95.00	0.77 0.79 0.81	190.00-195.00 195.00-200.00 200.00-206.00	1.51 1.55 1.59
206.00-212.00 212.00-218.00 224.00-230.00	1.63 1.71 1.75	325.00-335.00 335.00-345.00 345.00-355.00	2.43 2.49 2.56	500.00-515.00 515.00-530.00 530.00-545.00	3.54 3.63 3.72
230.00-236.00 236.00-243.00 243.00-250.00	1.79 1.83 1.88	355.00-365.00 365.00-375.00 375.00-387.00	2.62 2.68 2.76	545.00-560.00 560.00-580.00 580.00-600.00	3.81 3.93 4.05
250.00-258.00 258.00-265.00 265.00-272.00	1.93 1.98 2.02	387.00-400.00 400.00-412.00 412.00-425.00	2.84 2.91 2.99	600.00-615.00 615.00-630.00 630.00-650.00	4.13 4.22 4.34
272.00-280.00 280.00-290.00 290.00-300.00	2.08 2.14 2.21	425.00-437.00 437.00-450.00 450.00-462.00	3.07 3.15 3.22	650.00-670.00	4.46
300.00-307.00 307.00-315.00 315.00-325.00	2.25 2.30 2.37	462.00-475.00 475.00-485.00 485.00-500.00	3.30 3.37 3.45

Company Features
1. Dms Seals Technology Co.,limited is a high tech company that is specialize in O Ring Manufacturer . As an internationally competitive company, Dms Seals Technology Co.,limited has a large factory to produce o ring seal manufacturer . Dms Seals Technology Co.,limited has established a massive factory to manufacture high quality o-ring seal . Dms Seals Technology Co.,limited is adept at manufacturing premium o ring kit manufacturer for many years.
2. O Ring Manufacturer is assembled by our highly skilled professionals. Dms Seals Technology Co.,limited has introduced large O Ring Manufacturer production machines to guarantee delivery time and produce different hydraulic wiper seals . With strong technical force, Dms Seals Technology Co.,limited has a complete range of specifications of O Ring Manufacturer .
3. The attention of DMS Seal Manufacturer brand would be to maintain optimizing our own service. Ask online! Dms Seals Technology Co.,limited is always creative in providing solutions for customers' gaining benefits. Ask online! DMS Seal Manufacturer may make a welcome contribution to customers' business growth. Ask online!
