DMS Seals - Hydraulic Seals and Oil Ring Seals Manufacturer & Supplier
DMS Seal Manufacturer o ring seal manufacturer with a diisocyanate or a polymeric isocyanate for sale
- Dms Seals receives wide recognition from customers and enjoys a good reputation in the industry based on sincere service, professional skills, and innovative service methods.
1. The design of DMS Seal Manufacturer o ring seal kit is completed by utilizing the versatility of the 3D system which gives our designers greater expressive autonomy, allowing them to reproduce highly complex and imaginative designs easily.
2. The materials of DMS Seal Manufacturer o ring seal manufacturer are supplied based on the commitment to the environment - a family of eco-friendly materials designed to manufacture the sustainable product.
3. DMS Seal Manufacturer o ring seal kit adopts the optimized freezing technology that is developed by our R&D team. This technology has helped reduce the harmful impacts of chemical refrigerants on the environment.
4. A number of international advanced production equipment is introduced to ensure its quality.
5. The product has been approved by creditable quality certificates.
6. The product undergoes in-house quality assurance procedures.
7. Customers all praise its good finish quality. They said they have used it for several years and there is no paint flaking off or erosion problems.
8. The product is lightweight and very easy to put on and take off. It is very suitable for everyday wear.
9. The product helps people create a favorable first impression on a job interview or can even help them out when meeting with potential clients.
1. Installation Recommendation
2. Application and properties
Double acting seals, the sealing effect is achieved by the deformation of the section of the O-Rings, and the deformation is determined by the depth of the installation groove. Under pressure, the O-ring has a large surface tension like liquid, used for static sealing more. It is only recommended for better conditions in dynamic applications. System lubrication, pressure, temperature, sealing clearance, speed, medium and surface quality of metal parts determine the service life of O-Rings. It is not recommended if the lubrication is not sufficient during rotary motion.
3. Standard materials
NBR / FKM
4. Performance parameter
Static Seal | Dynamic Seal | |
Working Pressure | No support ring, up to 20MPa; With the support ring, up to 40MPa; With special support ring, up to 200MPa. | No support ring, up to 5MPa; With the support ring, higher pressure. |
Movement Speed | Maximum reciprocating speed up to 0.5m / s; maximum rotation speed up to 2.0m/s. | |
Temperature | NBR: -30℃ - 100℃; FKM: -20℃ - 220℃. | |
5. Wire Diameter Tolerance
Wire diameter of O-Ring (mm) | Tolerance (±mm) |
0-1.8 | 0.08 |
1.80-2.65 | 0.09 |
2.65-3.55 | 0.10 |
3.55-5.30 | 0.13 |
5.30-7.00 | 0.15 |
7.00-8.00 | 0.18 |
8.00-10.00 | 0.21 |
10.00-12.00 | 0.25 |
6. Inner diameter tolerance
Inner Diameter d1 mm | Tolerance ±mm | Inner Diameter d1 mm | Tolerance ±mm | Inner Diameter d1 mm | Tolerance ±mm |
0.70-2.50 2.50-4.50 4.50-6.30 | 0.13 0.14 0.15 | 43.70-45.00 46.00-46.20 46.20-47.50 | 0.42 0.43 0.44 | 95.00-97.50 97.50-100.00 100.00-103.00 | 0.83 0.84 0.87 |
6.30-8.50 8.50-10.00 10.00-11.20 | 0.16 0.17 0.18 | 47.50-48.70 48.70-50.00 50.00-51.50 | 0.45 0.46 0.47 | 103.00-106.00 106.00-109.00 109.00-112.00 | 0.89 0.91 0.93 |
11.20-14.00 14.00-16.00 16.00-18.00 | 0.19 0.20 0.21 | 51.50-53.00 53.00-54.50 54.50-56.00 | 0.48 0.50 0.51 | 112.00-115.00 115.00-118.00 118.00-122.00 | 0.95 0.97 1.00 |
18.00-20.00 20.00-21.20 21.20-23.60 | 0.22 0.23 0.24 | 56.00-58.00 58.00-60.00 60.00-61.50 | 0.52 0.54 0.55 | 122.00-125.00 125.00-128.00 128.00-132.00 | 1.03 1.05 1.08 |
23.60-25.00 25.00-26.50 26.50-28.00 | 0.25 0.26 0.28 | 61.50-63.00 63.00-65.00 65.00-67.00 | 0.56 0.58 0.59 | 132.00-136.00 136.00-140.00 140.00-145-00 | 1.10 1.13 1.17 |
28.00-30.00 30.00-31.50 31.50-33.50 | 0.29 0.31 0.32 | 67.00-69.00 69.00-71.00 71.00-73.00 | 0.61 0.63 0.64 | 145.00-150.00 150.00-155.00 155.00-160.00 | 1.20 1.24 1.27 |
33.50-34.50 34.50-35.50 35.50-36.50 | 0.33 0.34 0.35 | 73.00-75.00 75.00-77.50 77.50-80.00 | 0.66 0.67 0.69 | 160.00-165.00 165.00-170.00 170.00-175.00 | 1.31 1.34 1.38 |
36.50-37.50 37.50-38.70 38.70-40.00 | 0.36 0.37 0.38 | 80.00-82.50 82.50-85.00 85.00-87.50 | 0.71 0.73 0.75 | 175.00-180.00 180.00-185.00 185.00-190.00 | 1.41 1.44 1.48 |
40.00-41.20 41.20-42.50 42.50-43.70 | 0.39 0.40 0.41 | 87.50-90.00 90.00-92.50 92.50-95.00 | 0.77 0.79 0.81 | 190.00-195.00 195.00-200.00 200.00-206.00 | 1.51 1.55 1.59 |
206.00-212.00 212.00-218.00 224.00-230.00 | 1.63 1.71 1.75 | 325.00-335.00 335.00-345.00 345.00-355.00 | 2.43 2.49 2.56 | 500.00-515.00 515.00-530.00 530.00-545.00 | 3.54 3.63 3.72 |
230.00-236.00 236.00-243.00 243.00-250.00 | 1.79 1.83 1.88 | 355.00-365.00 365.00-375.00 375.00-387.00 | 2.62 2.68 2.76 | 545.00-560.00 560.00-580.00 580.00-600.00 | 3.81 3.93 4.05 |
250.00-258.00 258.00-265.00 265.00-272.00 | 1.93 1.98 2.02 | 387.00-400.00 400.00-412.00 412.00-425.00 | 2.84 2.91 2.99 | 600.00-615.00 615.00-630.00 630.00-650.00 | 4.13 4.22 4.34 |
272.00-280.00 280.00-290.00 290.00-300.00 | 2.08 2.14 2.21 | 425.00-437.00 437.00-450.00 450.00-462.00 | 3.07 3.15 3.22 | 650.00-670.00 | 4.46 |
300.00-307.00 307.00-315.00 315.00-325.00 | 2.25 2.30 2.37 | 462.00-475.00 475.00-485.00 485.00-500.00 | 3.30 3.37 3.45 |
Company Features
1. Dms Seals Technology Co.,limited is a highly reliable supplier and manufacturer of o ring seal manufacturer . With a unique vision, Dms Seals Technology Co.,limited is a leader in providing high quality O Ring Manufacturer and services. Dms Seals Technology Co.,limited has been fully engaged in the R&D and production of o ring kit manufacturer over the years.
2. Dms Seals Technology Co.,limited pursues excellence in the production process. Through the competitively progressive technology, our o-ring seal is of finest quality in the market. Integrating finest technology and excellent staff together, DMS Seal Manufacturer has been always offering o ring seal manufacturer with high quality. Dms Seals Technology Co.,limited has a complete production line with advanced machine.
3. We adhere to the plan of reducing, reusing, and recycling throughout the production process. Besides, we make efficient use of natural resources and energy in all operations. We aim to develop and maintain long-term relationships with our business partners based on openness, honesty, and trust. We seek to understand their business needs and aim to provide mutual support to ensure that sustainable business partnerships are established. We have a clear mission. We are dedicated to helping our clients achieve their missions by blending people, process, and technology into successful and sustainable business solutions. Here are a few of the ways we act sustainably: we use resources responsibly, reduce waste, and lay a foundation of good corporate governance. Inquire now!
DMS Seal Manufacturer o ring seal manufacturer with a diisocyanate or a polymeric isocyanate for sale
o ring seal manufacturer
Type:
Professional O Ring Suppliers & O Ring Manufacturers
