DMS Seal Manufacturer polyurethane polypropylene o rings company for static sealing

Company Advantages
1. DMS Seal Manufacturer polypropylene o rings is of scientific design. It is designed by adopting the principles of foot structure and the relationship between its and the person, the thing, the environment, and the dress.
2. The design of DMS Seal Manufacturer polypropylene o rings is completed by a dedicated technical team of CAD/CAM designers and structural engineers who try to design a long-lasting tent.
3. Each ingredient of DMS Seal Manufacturer is rigorously evaluated for safety by adopting the latest science regulations. Only those ingredients that meet exceedingly standards in the beauty makeup industry would be used.
4. The product is featured by strong durability and long-lasting performance.
5. The strict internal quality control system enables polypropylene o rings to reach the international leading level.
6. polypropylene o rings has many functions, such as .
7. The product has always found use in various different fields.
8. This product has considerable practical and commercial value.
9. The product enjoys high reputation in the market and has a great market application prospect.
10. With so many advantages, the product is considered to have a wide range of market applications.

1. Installation Recommendation

2. Application and properties

Double acting seals, the sealing effect is achieved by the deformation of the section of the O-Rings, and the deformation is determined by the depth of the installation groove. Under pressure, the O-ring has a large surface tension like liquid, used for static sealing more. It is only recommended for better conditions in dynamic applications. System lubrication, pressure, temperature, sealing clearance, speed, medium and surface quality of metal parts determine the service life of O-Rings. It is not recommended if the lubrication is not sufficient during rotary motion.

3. Standard materials

NBR / FKM

4. Performance parameter

	Static Seal	Dynamic Seal
Working Pressure	No support ring, up to 20MPa; With the support ring, up to 40MPa; With special support ring, up to 200MPa.	No support ring, up to 5MPa; With the support ring, higher pressure.
Movement Speed	Maximum reciprocating speed up to 0.5m / s; maximum rotation speed up to 2.0m/s.
Temperature	NBR: -30℃ - 100℃;  FKM: -20℃ - 220℃.

5. Wire Diameter Tolerance

Wire diameter of O-Ring (mm)	Tolerance (±mm)
0-1.8	0.08
1.80-2.65	0.09
2.65-3.55	0.10
3.55-5.30	0.13
5.30-7.00	0.15
7.00-8.00	0.18
8.00-10.00	0.21
10.00-12.00	0.25



6. Inner diameter tolerance

Inner Diameter d1 mm	Tolerance ±mm	Inner Diameter d1 mm	Tolerance ±mm	Inner Diameter d1 mm	Tolerance ±mm
0.70-2.50 2.50-4.50 4.50-6.30	0.13 0.14 0.15	43.70-45.00 46.00-46.20 46.20-47.50	0.42 0.43 0.44	95.00-97.50 97.50-100.00 100.00-103.00	0.83 0.84 0.87
6.30-8.50 8.50-10.00 10.00-11.20	0.16 0.17 0.18	47.50-48.70 48.70-50.00 50.00-51.50	0.45 0.46 0.47	103.00-106.00 106.00-109.00 109.00-112.00	0.89 0.91 0.93
11.20-14.00 14.00-16.00 16.00-18.00	0.19 0.20 0.21	51.50-53.00 53.00-54.50 54.50-56.00	0.48 0.50 0.51	112.00-115.00 115.00-118.00 118.00-122.00	0.95 0.97 1.00
18.00-20.00 20.00-21.20 21.20-23.60	0.22 0.23 0.24	56.00-58.00 58.00-60.00 60.00-61.50	0.52 0.54 0.55	122.00-125.00 125.00-128.00 128.00-132.00	1.03 1.05 1.08
23.60-25.00 25.00-26.50 26.50-28.00	0.25 0.26 0.28	61.50-63.00 63.00-65.00 65.00-67.00	0.56 0.58 0.59	132.00-136.00 136.00-140.00 140.00-145-00	1.10 1.13 1.17
28.00-30.00 30.00-31.50 31.50-33.50	0.29 0.31 0.32	67.00-69.00 69.00-71.00 71.00-73.00	0.61 0.63 0.64	145.00-150.00 150.00-155.00 155.00-160.00	1.20 1.24 1.27
33.50-34.50 34.50-35.50 35.50-36.50	0.33 0.34 0.35	73.00-75.00 75.00-77.50 77.50-80.00	0.66 0.67 0.69	160.00-165.00 165.00-170.00 170.00-175.00	1.31 1.34 1.38
36.50-37.50 37.50-38.70 38.70-40.00	0.36 0.37 0.38	80.00-82.50 82.50-85.00 85.00-87.50	0.71 0.73 0.75	175.00-180.00 180.00-185.00 185.00-190.00	1.41 1.44 1.48
40.00-41.20 41.20-42.50 42.50-43.70	0.39 0.40 0.41	87.50-90.00 90.00-92.50 92.50-95.00	0.77 0.79 0.81	190.00-195.00 195.00-200.00 200.00-206.00	1.51 1.55 1.59
206.00-212.00 212.00-218.00 224.00-230.00	1.63 1.71 1.75	325.00-335.00 335.00-345.00 345.00-355.00	2.43 2.49 2.56	500.00-515.00 515.00-530.00 530.00-545.00	3.54 3.63 3.72
230.00-236.00 236.00-243.00 243.00-250.00	1.79 1.83 1.88	355.00-365.00 365.00-375.00 375.00-387.00	2.62 2.68 2.76	545.00-560.00 560.00-580.00 580.00-600.00	3.81 3.93 4.05
250.00-258.00 258.00-265.00 265.00-272.00	1.93 1.98 2.02	387.00-400.00 400.00-412.00 412.00-425.00	2.84 2.91 2.99	600.00-615.00 615.00-630.00 630.00-650.00	4.13 4.22 4.34
272.00-280.00 280.00-290.00 290.00-300.00	2.08 2.14 2.21	425.00-437.00 437.00-450.00 450.00-462.00	3.07 3.15 3.22	650.00-670.00	4.46
300.00-307.00 307.00-315.00 315.00-325.00	2.25 2.30 2.37	462.00-475.00 475.00-485.00 485.00-500.00	3.30 3.37 3.45

Company Features
1. Dms Seals Technology Co.,limited has been intensive in polypropylene o rings field for decades. Dms Seals Technology Co.,limited is at the forefront of neoprene o rings suppliers industry. Dms Seals Technology Co.,limited is invested by lots of money and equipped with many talents. With years of accumulation in the industry of ring suppliers , o ring seal kit has become a highly competitive enterprise.
2. Dms Seals Technology Co.,limited has reached the highest degree of national technology. Dms Seals Technology Co.,limited has advanced and competitive clear silicone o rings suppliers crafts and techniques. Our factory is equipped with the most advanced technology and facilities for production, packaging and quality control. This enables us to provides the best products for our customers. Our constant focus on automation of production facilities makes our business stronger. In the manufacturing process, our facilities ensure that every step - from design to production to assembly - follows the highest standards of quality. We have a well-cultivated team of talents. They are trained with industry expertise and attend the professional seminar, aiming to improve the quality of their work.
3. We will continue to provide service with the tenet of . Call! Our aim is to be one of most advanced companies in brown viton o ring industry in the world. Call! The culture of ring o x3 in DMS Seal Manufacturer has attracted more and more customers. Call!

DMS Seal Manufacturer polyurethane polypropylene o rings company for static sealing

polypropylene o rings

Type:
