DMS Seal Manufacturer ptfe hydraulic rod seals mdi for sale

Company Advantages
1. By using quality-approved components, DMS Seal Manufacturer push rod seal is manufactured under the visionary guidance of our experts in accordance with global market standards with the aid of pioneering techniques.
2. DMS Seal Manufacturer hydraulic rod seals has a rather appealing appearance due to the efforts of our own professional and innovative designers. Its design is reliable and time-tested enough to meet the challenges of the market.
3. The whole design of DMS Seal Manufacturer push rod seal is conducted by our professional and experienced team.
4. The raw materials of DMS Seal Manufacturer push rod seal are meticulously selected to make sure each of them works perfectly, through which the quality of the product can be ensured from the source.
5. By introducing advanced machines, we has enough capability to produce this product with quality assurance.
6. The quality of this product is thoroughly inspected by the QC team.
7. The product is quality-assured as we have established a good quality management system to prevent any possible defects.
8. The product, bringing customers many economic benefits, is believed to be more widely used in the market.
9. This product is over and above our rival's product, and yet we're able to sell it at the same price.
10. Owing to various quality attributes, it is highly appreciated by our clients.
11. The product has achieved an extensive application in the market thanks to its remarkably good characteristics.
12. The product has gained much acceptance and popularity in the field.
13. The popularity of this product among customers is increasing and has no sign of slow down.

1. Installation Recommendation

2. Application and properties

The standard combination seal is suitable for a wide range of pressure work and sliding high speed occasions. Low friction, strong wear resistance.

3. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM

4. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3 - 1600mm	0 - 35MPa	-30℃ +200℃	1.5 m/s	general hydraulic oil, water glycol Hydraulic oil and water emulsion type hydraulic oil.

5. Installation Dimensions

Nominal Size of Packing, and Housing dimensions				Order No.
d	D	H	L +0.2
3 4 5	6 7 8	2.3 2.3 2.3	2.5 2.5 2.5	SPNC3*6*2.5 SPNC4*7*2.5 SPNC5*8*2.5
6 7 8	9 10 11	2.3 2.3 2.3	2.5 2.5 2.5	SPNC6*9*2.5 SPNC7*10*2.5 SPNC8*11*2.5
9 10 10	12 13 14	2.3 2.3 3.0	2.5 2.5 3.2	SPNC9*12*2.5 SPNC10*13*2.5 SPNC10*14*3.2
11 11.2 12	15 15.2 16	3.0 3.0 3.0	3.2 3.2 3.2	SPNC11*15*3.2 SPNC11.2*15.2*3.2 SPNC12*16*3.2
12.5 14 15	16.5 18 19	3.0 3.0 3.0	3.2 3.2 3.2	SPNC12.5*16.5*3.2 SPNC14*18*3.2 SPNC15*19*3.2
16 18 20	20 22 24	3.0 3.0 3.0	3.2 3.2 3.2	SPNC16*20*3.2 SPNC18*22*3.2 SPNC20*24*3.2
20 21 22	24 25 26	3.0 3.0 3.0	3.2 3.2 3.2	SPNC20*24*3.2 SPNC21*25*3.2 SPNC22*26*3.2
22 22.4 24	28 28.4 30	4.4 4.4 4.4	4.7 4.7 4.7	SPNC22*28*4.7 SPNC22.4*28.4*4.7 SPNC24*30*4.7
25 25.5 26	31 31.5 32	4.4 4.4 4.4	4.7 4.7 4.7	SPNC25*31*4.7 SPNC25.5*31.5*4.7 SPNC26*32*4.7
28 29 29.5	34 35 35.5	4.4 4.4 4.4	4.7 4.7 4.7	SPNC28*34*4.7 SPNC29*35*4.7 SPNC29.5*35.5*4.7
30 31 31.5	36 37 37.5	4.4 4.4 4.4	4.7 4.7 4.7	SPNC30*36*4.7 SPNC31*37*4.7 SPNC31.5*37.5*4.7
32 34 35	38 40 41	4.4 4.4 4.4	4.7 4.7 4.7	SPNC32*38*4.7 SPNC34*40*4.7 SPNC35*41*4.7
35.5 36 38	41.5 42 44	4.4 4.4 4.4	4.7 4.7 4.7	SPNC35.5*41.5*4.7 SPNC36*42*4.7 SPNC38*44*4.7

Company Features
1. Dms Seals Technology Co.,limited is a professional production base and backbone enterprise for emerging hydraulic rod seals products. The quality of rod seals is seldom complained by customers in Dms Seals Technology Co.,limited. Many famous companies have built cooperation relationship with Dms Seals Technology Co.,limited for its o-ring seal.
2. Dms Seals Technology Co.,limited has advanced production equipment, excellent manufacturing technology and complete testing methods. Dms Seals Technology Co.,limited has a very systematic product research and development capabilities. Dms Seals Technology Co.,limited has advanced production equipment, strong technical force, and a sound management system. Dms Seals Technology Co.,limited has the advanced equipment and technology needed for O Ring Manufacturers .
3. push rod seal is now a central tenet in Dms Seals Technology Co.,limited's service system. Get quote! hydraulic rod seals online is our eternal service creed. Get quote! Dms Seals Technology Co.,limited has been responsible for developing a number of highly marketable hydraulic rod seals for years. Get quote! Dms Seals Technology Co.,limited is committed to becoming a sustainable company in hydraulic rod seals field. Get quote!

DMS Seal Manufacturer ptfe hydraulic rod seals mdi for sale

hydraulic rod seals

Type:mdi 、 Type1:gsi
