DMS Seal Manufacturer ptfe link seal manufacturers wholesale for piston and hydraulic cylinder

Company Advantages
1. DMS Seal Manufacturer is manufactured in an exquisite manner. Especially the circuit fabrication, including the main electric circuit, control circuit, and signal circuit, is done under cutting-edge technologies.
2. DMS Seal Manufacturer link seal manufacturers is designed considering many important factors that are related to human health. These factors include tip-over hazards, formaldehyde safety, lead safety, strong odors, and Chemicals damage.
3. DMS Seal Manufacturer has been tested by the in-house testing department. For example, the non-destructive testing processes such as pressure, vacuum and leak testing have been strictly performed.
4. DMS Seal Manufacturer has a scientific design. It is based on environmental/climatic factors such as light, temperature, wind, sound, touch or passenger/user demand.
5. DMS Seal Manufacturer link seal manufacturers avoids being exposed to a variety of chemicals during processing. And it is processed and sanitized thoroughly for the elimination of impurities like dirt, dust, and oil.
6. This product can be easily adapted to changes. Its flexible joints ensure that the whole construction is allowed to expand and contract with seasonal movement.
7. The door plank of the product is not prone to deform. The base materials and the surface of the door plank are finely treated to resist moisture which may cause deformation and corrosion.
8. The product is safe and harmless. The materials ingredient testing has proved that it does not contain any harmful substances such as organic tin and formaldehyde.
9. The product is hygienic. It is manufactured under advanced technology for odor and bacteria management, which can prevent mold, algae, and biofilm.
10. The price of this product is quite competitive and is widely available in the market.
11. This product is suitable for a wide range of applications.
12. With years of continuous development, the product has gained support and trust of customers and is more extensively applied in the market.

1. Installation Recommendation

2. Application and properties

Suitable for long stroke, a wide range of fluids and high temperature occasions. The application of heavy duty double acting piston sealing under high pressure conditions is excellent. Applicable to larger piston clearance , it has good leakage control, extrusion resistance and wear resistance in heavy duty and construction machinery cylinder piston sealing system. Good static sealing property, simple groove structure, larger extrusion clearances can be allowed, be able to work in dusty condition.

3. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM

Back-up ring: POM / PA

4. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
50 - 350mm	0 - 50MPa	-30℃ +100℃	1.5 m/s	hydraulic oil, flame retardant liquid, water and others

5. Installation Dimensions

Nominal Size of Packing, and Housing dimensions			L+0.2	Order No.
D1	dN	H
50 55 60	36 41 46	8.5 8.5 8.5	9 9 9	SPGW50*36*8.5 SPGW55*41*8.5 SPGW60*46*8.5
63 65 70	48 50 55	10.5 10.5 10.5	11 11 11	SPGW63*48*10.5 SPGW65*50*10.5 SPGW70*55*10.5
75 80 85	60 65 70	10.5 10.5 10.5	11 11 11	SPGW75*60*10.5 SPGW80*65*10.5 SPGW85*70*10.5
90 95 100	75 80 85	10.5 10.5 12	11 11 12.5	SPGW90*75*10.5 SPGW95*80*10.5 SPGW100*85*12
105 110 115	90 95 100	12 12 12	12.5 12.5 12.5	SPGW105*90*12 SPGW110*95*12 SPGW115*100*12
120 125 130	105 102 107	12 15.5 15.5	12.5 16 16	SPGW120*105*12 SPGW125*102*15.5 SPGW130*107*15.5
135 140 145	112 117 122	15.5 15.5 15.5	16 16 16	SPGW135*112*15.5 SPGW140*117*15.5 SPGW145*122*15.5
150 155 160	127 132 137	15.5 15.5 15.5	16 16 16	SPGW150*127*15.5 SPGW155*132*15.5 SPGW160*137*15.5
165 170 180	142 147 157	15.5 15.5 15.5	16 16 16	SPGW165*142*15.5 SPGW170*147*15.5 SPGW180*157*15.5
185 190 200	162 167 177	15.5 15.5 15.5	16 16 16	SPGW185*162*15.5 SPGW190*167*15.5 SPGW200*177*15.5
210 220 225	187 197 202	15.5 15.5 17	16 16 17.5	SPGW210*187*15.5 SPGW220*197*15.5 SPGW225*202*15.5
230 240 250	207 217 222	17 17 17	17.5 17.5 17.5	SPGW230*207*15.5 SPGW240*217*15.5 SPGW250*222*17
260 270 280	232 242 252	17 17 17	17.5 17.5 17.5	SPGW260*232*17 SPGW270*242*17 SPGW280*252*17
300 320 350	272 292 322	17 17 17	17.5 17.5 17.5	SPGW300*272*17 SPGW320*292*17 SPGW350*322*17

Company Features
1. Dms Seals Technology Co.,limited remains committed to the manufacture of link seal manufacturers for many years. Dms Seals Technology Co.,limited has been engaged in production of oil seal manufacturers china since the day of its establishment. Relying on its own advantages in technology innovation and experienced team, Dms Seals Technology Co.,limited supplies high quality viton oil seal manufacturers . Dms Seals Technology Co.,limited mainly deals with axle seal manufacturers with high quality and competitive price.
2. Our skilled R&D professionals promote our growth in business. They are able to provide different products specially developed for various global markets. We have imported new production facilities. They have streamlined and speeded our manufacturing process, making us possible to provide better and faster service and an expanded line of products. We have a strict quality control management system. This system requires all of the incoming materials and parts to be evaluated and tested to meet high-quality standards.
3. DMS Seal Manufacturer has successfully built itself into a brand that represents "High Quality" in both products and services. We do things efficiently and responsibly in terms of the environment, people and the economy. The three dimensions are critical throughout our value chain, from procurement to end product. We inspire progress by unleashing the potential in people and technologies to advance the quality of life. By making environments comfortable, sustainable and efficient, we enable our customers to achieve real progress and create a positive impact in their world. Get more info!
