DMS Seal Manufacturer seal rod seals ptfe hydraulic 1

DMS Seal Manufacturer seal rod seals ptfe hydraulic 2

DMS Seal Manufacturer seal rod seals ptfe hydraulic

Diameter Range:

6-1600mm

Pressure Range:

0-35MPa

Temperature Range:

-30℃ +200℃

Speed:

1.5 m/s

Medium:

general hydraulic oil, water glycol Hydraulic oil and water emulsion type hydraulic oil.

Inquiry

Company Advantages
1. All pictures of rod seals all under the natural light the real object take, did not do any technique processing. The high pressure seals have strong wear resistance to hard conditions
2. Through strict quality test, each hydraulic rod seals meets the standards of the industry before its shipping. As a modern sealing technology company, DMS Seal manufacturer has a wealth of experience
3. Our O Ring Manufacturers are high in demand due to their premium quality, hydraulic rod seals and affordable prices. DMS Seals manufacturer owns a team of professional R&D group and skilled technicians
4. DMS Seals implements and optimizes its quality control systems, We Provides Latest o-ring seal, piston rod seal To Satisfy Customers' Need With Support Of Advanced Technique.

Installation Recommendation

undefined

Application and properties

The standard combination seal is suitable for a wide range of pressure work and sliding high speed occasions. Low friction, strong wear resistance.

Standard materials

Sealing ring: filled PTFE

O-ring: NBR / FKM

Working Conditions

Working Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
6-1600mm	0-35MPa	-30℃ +200℃	1.5 m/s	general hydraulic oil, water glycol Hydraulic oil and water emulsion type hydraulic oil.

Installation Dimensions

Nominal Size of Packing, and Housing dimensions				Order No.
d	D	H	L +0.2	Order No.
18 20 22	27 29 31	4.3 4.3 4.3	4.5 4.5 4.5	SPN18274.3 SPN20294.3 SPN22314.3
27 31.5 47	36 40.5 60	4.3 4.3 7.3	4.5 4.5 7.5	SPN27364.3 SPN31.540.54.3 SPN47607.3
53 60 65	66 73 78	7.3 7.3 7.3	7.5 7.5 7.5	SPN53667.3 SPN60737.3 SPN65787.3
70 75 80	83 88 93	7.3 7.3 7.3	7.5 7.5 7.5	SPN70837.3 SPN75887.3 SPN80937.3
90 100 110	103.4 113.4 123.4	7.3 7.3 7.3	7.5 7.5 7.5	SPN90103.47.3 SPN100113.47.3 SPN110123.47.3
120 130 140	133.4 143.4 153.4	7.3 7.3 7.3	7.5 7.5 7.5	SPN120133.47.3 SPN130143.47.3 SPN140153.47.3

Company Features
1. We have carved a niche amongst the most trusted names in this business, engaged in offering a comprehensive range of rod seals. - Dms Seals Technology Co.,limited keeps its prosperity in technical level of hydraulic rod seals and technical strength for many years.
2. Dms Seals Technology Co.,limited’s unique combination of proprietary technology, state-of-the-art manufacturing, innovative design, know-how and engineering capability enables us to deliver superior O Ring Manufacturers solutions to customers regionally.
3. hydraulic rod seals is an important process in o-ring seal production for Dms Seals Technology Co.,limited. - Moreover, our offered carts can be availed by our clients' at feasible prices.

we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
