DMS Seal Manufacturer Suppliers for pressure work and sliding high speed occasions

Company Advantages
1. DMS Seal Manufacturer is manufactured by utilizing superior quality raw materials in accordance with market standards.
2. The materials DMS Seal Manufacturer uses are selected from reliable suppliers.
3. DMS Seal Manufacturer is designed by the professional and innovative design team.
4. DMS Seal Manufacturer is produced in fast and accurate flexibility of production methods.
5. DMS Seal Manufacturer is available in various innovative and useful design styles.
6. The international quality certifications shows the good quality of this product.
7. The product not only has passed the domestic quality standards but also has been approved by many international certificates.
8. With our design team's continuous efforts, , has been given an aesthetically-pleasing appearance design.
9. The product is very breathable to wear, without absorbing the smelly sweat. It makes people stay cool for a whole day.
10. This product demonstrates a comfort wearing experience due to it being able to manage an optimum heat and moisture balance.
11. This product provides an effective space solution for a variety of environments including offices, dining facilities, and hotels.
12. This product will help reduce the impact forces on the body’s joints and feet during weight-bearing activity, reducing the possibility of injury.
13. This product is able to suit any personal style, space or function. It will matter the most when designing a space.

1. Installation Recommendation

2. Application and properties

The standard combination seal is suitable for a wide range of pressure work and sliding high speed occasions. Low friction, strong wear resistance.

3. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM

4. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3 - 1600mm	0 - 35MPa	-30℃ +200℃	1.5 m/s	general hydraulic oil, water glycol Hydraulic oil and water emulsion type hydraulic oil.

5. Installation Dimensions

Nominal Size of Packing, and Housing dimensions				Order No.
d	D	H	L +0.2
3 4 5	6 7 8	2.3 2.3 2.3	2.5 2.5 2.5	SPNC3*6*2.5 SPNC4*7*2.5 SPNC5*8*2.5
6 7 8	9 10 11	2.3 2.3 2.3	2.5 2.5 2.5	SPNC6*9*2.5 SPNC7*10*2.5 SPNC8*11*2.5
9 10 10	12 13 14	2.3 2.3 3.0	2.5 2.5 3.2	SPNC9*12*2.5 SPNC10*13*2.5 SPNC10*14*3.2
11 11.2 12	15 15.2 16	3.0 3.0 3.0	3.2 3.2 3.2	SPNC11*15*3.2 SPNC11.2*15.2*3.2 SPNC12*16*3.2
12.5 14 15	16.5 18 19	3.0 3.0 3.0	3.2 3.2 3.2	SPNC12.5*16.5*3.2 SPNC14*18*3.2 SPNC15*19*3.2
16 18 20	20 22 24	3.0 3.0 3.0	3.2 3.2 3.2	SPNC16*20*3.2 SPNC18*22*3.2 SPNC20*24*3.2
20 21 22	24 25 26	3.0 3.0 3.0	3.2 3.2 3.2	SPNC20*24*3.2 SPNC21*25*3.2 SPNC22*26*3.2
22 22.4 24	28 28.4 30	4.4 4.4 4.4	4.7 4.7 4.7	SPNC22*28*4.7 SPNC22.4*28.4*4.7 SPNC24*30*4.7
25 25.5 26	31 31.5 32	4.4 4.4 4.4	4.7 4.7 4.7	SPNC25*31*4.7 SPNC25.5*31.5*4.7 SPNC26*32*4.7
28 29 29.5	34 35 35.5	4.4 4.4 4.4	4.7 4.7 4.7	SPNC28*34*4.7 SPNC29*35*4.7 SPNC29.5*35.5*4.7
30 31 31.5	36 37 37.5	4.4 4.4 4.4	4.7 4.7 4.7	SPNC30*36*4.7 SPNC31*37*4.7 SPNC31.5*37.5*4.7
32 34 35	38 40 41	4.4 4.4 4.4	4.7 4.7 4.7	SPNC32*38*4.7 SPNC34*40*4.7 SPNC35*41*4.7
35.5 36 38	41.5 42 44	4.4 4.4 4.4	4.7 4.7 4.7	SPNC35.5*41.5*4.7 SPNC36*42*4.7 SPNC38*44*4.7

Company Features
1. Dms Seals Technology Co.,limited is a customer-oriented company which has been focused on high quality for many years. Rod Seals are produced from DMS Seal Manufacturer and is well accepted at global market. From the outset, Dms Seals Technology Co.,limited was an export-oriented company specialized in hydraulic pump seals suppliers . Dms Seals Technology Co.,limited is a reliable and responsible manufacturer for its hydraulic rod seals . High quality of u seal design helps Dms Seals Technology Co.,limited occupy big global market.
2. DMS Seal Manufacturer develops core competitiveness by improving technological innovation. Dms Seals Technology Co.,limited applies high-tech participation in the production of forklift hydraulic cylinder seals . DMS Seal Manufacturer uses imported technology to help optimize pneumatic rod seals .
3. Ensuring the best customer experience is the best way for DMS Seal Manufacturer to keep forward in cylinder oil seal industry. Get an offer! Dms Seals Technology Co.,limited responds to customer needs, inspiring new product and service ideas. Get an offer! Comparing to other factors, quality and after-sale service come first for Dms Seals Technology Co.,limited. Get an offer! Based on comparative advantages, DMS Seal Manufacturer will vigorously develop a circular economy and continuously improve the service. Get an offer!
