DMS Seal Manufacturer Top o ring kit manufacturer Supply for sale
- We promise choosing Dms Seals is equal to choosing quality and efficient services.
1. Once the design of DMS Seal Manufacturer o ring kit manufacturer is created, it is taken to a team of pattern cutters who put together the first prototypes.
2. During the production of DMS Seal Manufacturer o ring kit manufacturer , it is strictly tested, including lifetime test, heat and power breakdown test, and mechanical damage test.
3. In manufacturing DMS Seal Manufacturer , state-of-the-art environmental technology is adopted. A unique combination of innovative technology is used for the purification of waste gas.
4. DMS Seal Manufacturer is designed with high technology. Adopting the brand new CAD lofting software which is especially for inflatable products, the design drawing comes out within minutes.
5. The product has good heat dissipation. is created to increase the contact surface area between solid and fluid, hence increasing the effectiveness of heat transfer.
6. The product is easy to move. The design of the heavy-duty multi-way roller enables easy movement through the ceiling track.
7. The product features electrical safety. Its electrical faults have been identified and potential hazards that would hurt human have been removed.
8. This product has a high gain performance. Its special surface coating enhances color reproduction and black level contrast with wide uniformity.
9. The product is features reliability and stability. Its electrical leakage risks have been already removed and it can work smoothly.
10. Since the product is able to maintain its original brightness throughout the lifespan over time, people can use it for a long time without replacing.
11. High temperature shortens the life of the component or even cause the device to fail, hence, using this product to dissipate the heat is significant to protect these components.
12. This unusual, modern, and classic collection expresses individual and exclusive table culture, making it especially suitable for gatherings and parties uses.
1. Installation Recommendation
2. Application and properties
Double acting seals, the sealing effect is achieved by the deformation of the section of the O-Rings, and the deformation is determined by the depth of the installation groove. Under pressure, the O-ring has a large surface tension like liquid, used for static sealing more. It is only recommended for better conditions in dynamic applications. System lubrication, pressure, temperature, sealing clearance, speed, medium and surface quality of metal parts determine the service life of O-Rings. It is not recommended if the lubrication is not sufficient during rotary motion.
3. Standard materials
NBR / FKM
4. Performance parameter
Static Seal | Dynamic Seal | |
Working Pressure | No support ring, up to 20MPa; With the support ring, up to 40MPa; With special support ring, up to 200MPa. | No support ring, up to 5MPa; With the support ring, higher pressure. |
Movement Speed | Maximum reciprocating speed up to 0.5m / s; maximum rotation speed up to 2.0m/s. | |
Temperature | NBR: -30℃ - 100℃; FKM: -20℃ - 220℃. | |
5. Wire Diameter Tolerance
Wire diameter of O-Ring (mm) | Tolerance (±mm) |
0-1.8 | 0.08 |
1.80-2.65 | 0.09 |
2.65-3.55 | 0.10 |
3.55-5.30 | 0.13 |
5.30-7.00 | 0.15 |
7.00-8.00 | 0.18 |
8.00-10.00 | 0.21 |
10.00-12.00 | 0.25 |
6. Inner diameter tolerance
Inner Diameter d1 mm | Tolerance ±mm | Inner Diameter d1 mm | Tolerance ±mm | Inner Diameter d1 mm | Tolerance ±mm |
0.70-2.50 2.50-4.50 4.50-6.30 | 0.13 0.14 0.15 | 43.70-45.00 46.00-46.20 46.20-47.50 | 0.42 0.43 0.44 | 95.00-97.50 97.50-100.00 100.00-103.00 | 0.83 0.84 0.87 |
6.30-8.50 8.50-10.00 10.00-11.20 | 0.16 0.17 0.18 | 47.50-48.70 48.70-50.00 50.00-51.50 | 0.45 0.46 0.47 | 103.00-106.00 106.00-109.00 109.00-112.00 | 0.89 0.91 0.93 |
11.20-14.00 14.00-16.00 16.00-18.00 | 0.19 0.20 0.21 | 51.50-53.00 53.00-54.50 54.50-56.00 | 0.48 0.50 0.51 | 112.00-115.00 115.00-118.00 118.00-122.00 | 0.95 0.97 1.00 |
18.00-20.00 20.00-21.20 21.20-23.60 | 0.22 0.23 0.24 | 56.00-58.00 58.00-60.00 60.00-61.50 | 0.52 0.54 0.55 | 122.00-125.00 125.00-128.00 128.00-132.00 | 1.03 1.05 1.08 |
23.60-25.00 25.00-26.50 26.50-28.00 | 0.25 0.26 0.28 | 61.50-63.00 63.00-65.00 65.00-67.00 | 0.56 0.58 0.59 | 132.00-136.00 136.00-140.00 140.00-145-00 | 1.10 1.13 1.17 |
28.00-30.00 30.00-31.50 31.50-33.50 | 0.29 0.31 0.32 | 67.00-69.00 69.00-71.00 71.00-73.00 | 0.61 0.63 0.64 | 145.00-150.00 150.00-155.00 155.00-160.00 | 1.20 1.24 1.27 |
33.50-34.50 34.50-35.50 35.50-36.50 | 0.33 0.34 0.35 | 73.00-75.00 75.00-77.50 77.50-80.00 | 0.66 0.67 0.69 | 160.00-165.00 165.00-170.00 170.00-175.00 | 1.31 1.34 1.38 |
36.50-37.50 37.50-38.70 38.70-40.00 | 0.36 0.37 0.38 | 80.00-82.50 82.50-85.00 85.00-87.50 | 0.71 0.73 0.75 | 175.00-180.00 180.00-185.00 185.00-190.00 | 1.41 1.44 1.48 |
40.00-41.20 41.20-42.50 42.50-43.70 | 0.39 0.40 0.41 | 87.50-90.00 90.00-92.50 92.50-95.00 | 0.77 0.79 0.81 | 190.00-195.00 195.00-200.00 200.00-206.00 | 1.51 1.55 1.59 |
206.00-212.00 212.00-218.00 224.00-230.00 | 1.63 1.71 1.75 | 325.00-335.00 335.00-345.00 345.00-355.00 | 2.43 2.49 2.56 | 500.00-515.00 515.00-530.00 530.00-545.00 | 3.54 3.63 3.72 |
230.00-236.00 236.00-243.00 243.00-250.00 | 1.79 1.83 1.88 | 355.00-365.00 365.00-375.00 375.00-387.00 | 2.62 2.68 2.76 | 545.00-560.00 560.00-580.00 580.00-600.00 | 3.81 3.93 4.05 |
250.00-258.00 258.00-265.00 265.00-272.00 | 1.93 1.98 2.02 | 387.00-400.00 400.00-412.00 412.00-425.00 | 2.84 2.91 2.99 | 600.00-615.00 615.00-630.00 630.00-650.00 | 4.13 4.22 4.34 |
272.00-280.00 280.00-290.00 290.00-300.00 | 2.08 2.14 2.21 | 425.00-437.00 437.00-450.00 450.00-462.00 | 3.07 3.15 3.22 | 650.00-670.00 | 4.46 |
300.00-307.00 307.00-315.00 315.00-325.00 | 2.25 2.30 2.37 | 462.00-475.00 475.00-485.00 485.00-500.00 | 3.30 3.37 3.45 |
Company Features
1. With the expanding of o ring kit manufacturer , DMS Seal Manufacturer has caught more and more attention of the customers. Dms Seals Technology Co.,limited has largest production base and professional management system. Dms Seals Technology Co.,limited is a 6.5 inch o ring production and management enterprise integrating industry and trade.
2. Dms Seals Technology Co.,limited is globally well-known for the technology strength. Dms Seals Technology Co.,limited has an obvious advantage in its technology for buy rubber o rings over other companies. Situated near the airport and main road, the factory is blessed with good geographical location. This advantage allows us to easily transport the raw materials, facilities, and products.
3. hydraulic o ring sizes is our eternal pursuit. Contact! Our spirit of pursuing excellent quality and best service makes our viton rubber o rings popular and win a high reputation among our customers. Contact! Relying on thousands of R&D teams, Dms Seals Technology Co.,limited is committed to . Contact! Dms Seals Technology Co.,limited promises 19mm o ring warranty for one year, long-term after-sale spare parts service. Contact! Dms Seals Technology Co.,limited is striving to become a world-class manufacturer of thin rubber o rings . Contact!
