DMS Seal Manufacturer wholesale hydraulic seals for pneumatic equipment

Company Advantages
1. DMS Seal Manufacturer is provided owing to our valuable experience and industrial expertise.
2. DMS Seal Manufacturer is professionally designed by experienced experts following a strict design process.
3. DMS Seal Manufacturer is delicately treated to ensure the perfection of every detail.
4. The appearance of DMS Seal Manufacturer looks very attractive.
5. By reason of the design of wholesale hydraulic seals , our products are more appealing in the industry.
6. Using as its row material, wholesale hydraulic seals 's characteristics improves significantly.
7. The new features of area of would make it highly marketable.
8. reflects the high quality of wholesale hydraulic seals .
9. The product is an excellent tool to take the stress out of everyday fatigue. It improves overall production efficiency and simplifies operation tasks.
10. The speed at which this product is built is significantly higher than any other construction method, which is why it presents the best and most efficient solution for making a building quickly.
11. The use of this product would contribute to a reduction in labor costs. Its high automation level allows a company to retain fewer operators, thereby saving on overhead.

1. Installation Recommendation

2. Installation Sizes

Bore Diameter                         DN H9			Groove Diameter	Groove Width	Radius	Radial Clearance                S max.			O-Ring Cross-Section
Standard Application	Light Application	Heavy Duty Application	d1 h9	L1+0.2	R1	10MPa	20MPa	40MPa	d2
8-14.9	15-39.9	-	DN-4.9	2.2	0.4	0.3	0.20	0.15	1.78
15-39.9	40-79.9	-	DN-7.5	3.2	0.6	0.4	0.25	0.15	2.62
40-79.9	80-132.9	15-39.9	DN-11.0	4.2	1.0	0.4	0.25	0.20	3.53
80-132.9	133-329.9	40-79.9	DN-15.5	6.3	1.3	0.5	0.30	0.20	5.33
133-329.9	330-699.9	80-132.9	DN-21.0	8.1	1.8	0.6	0.35	0.25	7.00
330-669.9	670-99.9	133-329.9	DN-24.5	8.1	1.8	0.6	0.35	0.25	7.00
670-999.9	≥1000	330-669.9	DN-28.0	9.5	2.5	0.7	0.50	0.30	8.40
≥1000	≥1000	≥1000	DN-38.0	13.8	3.0	1.0	0.70	0.60	12.00

3. Application and properties

Standard double acting seal. Suitable for reciprocating motion, allowing larger extrusion clearances, has wide application. Dynamic and static sealing property are excellent, be able to work in dusty condition. Low friction, simple groove, strong adaptability to work conditions.

4. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM

5. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3 - 1600mm	0 - 60MPa	-45℃ +200℃	15 m/s	hydraulic oil, flame retardant liquid, water and others

6. Installation Dimensions

Bore Dia.	Groove Dia.	Groove Width	Order No.	O-Ring Dimensions
DN H9	d1 h9	L1+0.2
8 10 12	3.1 5.1 7.1	2.2 2.2 2.2	GSF8*3.1*2.2 GSF10*5.1*2.2 GSF12*7.1*2.2	2.90*1.78 4.80*1.8 6.70*1.8
14 15 15	9.1 10.1 7.5	2.2 2.2 3.2	GSF14*9.1*2.2 GSF15*10.1*2.2 GSF15*7.5*3.2	8.75*1.8 7.59*2.62 8.75*1.8
16 16 18	11.1 8.5 13.1	2.2 3.2 2.2	GSF16*11.1*2.2 GSF16*8.5*3.2 GSF18*13.1*2.2	10.82*1.78 7.59*2.62 12.42*1.78
18 20 20	10.5 15.1 12.5	3.2 2.2 3.2	GSF18*10.5*3.2 GSF20*15.1*2.2 GSF20*12.5*3.2	9.19*2.62 14.00*1.78 12.37*2.62
24 24 25	19.1 16.5 17.5	2.2 3.2 3.2	GSF24*19.1*2.2 GSF24*16.5*3.2 GSF25*17.5*3.2	18.77*1.78 15.54*2.62 17.12*2.62
25 28 28	14 20.5 17	4.2 3.2 4.2	GSF25*14*4.2 GSF28*20.5*3.2 GSF28*17*4.2	13.87*3.53 20.29*2.62 15.47*3.53
30 30 32	22.5 19 24.5	3.2 4.2 3.2	GSF30*22.5*3.2 GSF30*19*4.2 GSF32*24.5*3.2	21.89*2.62 26.70*1.78 23.47*2.62

Company Features
1. DMS Seal Manufacturer brand is a notable wholesale hydraulic seals exporter. DMS Seal Manufacturer has gained a high reputation and won wide recognition from more customers. DMS Seal Manufacturer boasts its high technology and professional techniques. Dms Seals Technology Co.,limited is one of the most respected hydraulic u seal providers.
2. With the expected increasing markets overseas, the company has made a new record of numerous clients' demands throughout the world. The company predicts that the demands will continue to increase in the coming years. We focus on establishing strong business relationships based on customer satisfaction and commitment to providing quality products and services. This has given us a valuable reputation with organizations worldwide. The technology we have mastered enables us to make progress in the industry, even reaching the international advanced level. Dms Seals Technology Co.,limited has successfully optimized hydraulic cylinder seal compression tool product development.
3. We have incorporated sustainability practices into our business strategy. One of our moves is to set and achieve a significant decrease in our greenhouse gas emissions. Our goal is to create value – for our customers and consumers, for our teams, as well as for the wider society and communities in which we operate. We have a clear long-term strategy. We want to become more customer-focused, more innovative, and more agile in our internal processes and customer-facing activities. We are promoting environmental management to help protect the global environment. During our operation, we will thoroughly check and make sure all activities in compliance with product environmental regulations and similar items. Our commitment to going to green production promotes us to take corresponding approaches. For example, we will strive to use cleaner and some renewable energy to offset the environmental impact caused during production.
