DMS Seal Manufacturer Wholesale rod end seals Suppliers for reciprocating piston rod or piston single acting seal

Company Advantages
1. No other similar rod end seals has been able to equal its .
2. With concept, rod end seals is designed, which is of .
3. We update the design of rod end seals frequently, making it .
4. DMS Seal Manufacturer assures that the basic materials that we use in the production process are of premium quality.
5. rod end seals is designed to combine the best features of and .
6. It attracts users' attention with its easy-to-use performance.
7. Our rod end seals has the best performance/price ratio.
8. It is recognized for strong durability and relatively long service life.
9. rod end seals , by adopting , is conducive to showing the uniqueness of this product.
10. Dms Seals Technology Co.,limited focuses on the rod end seals field, adheres to stable operations, continuous innovation and open cooperation.
11. By establishing normal management rules, DMS Seal Manufacturer can strictly guarantee the quality of rod end seals .
12. If you have great interest in our rod end seals , Dms Seals Technology Co.,limited can send free samples for testing quality.
13. is one of the conditions for improving the rod end seals quality.
14. Our R&D team are all professional in the rod end seals industry.

1. Application and properties

Suitable for reciprocating piston rod or piston single acting seal, the working pressure has a wide range of adaptability, and the pressure capacity can be enhanced by increasing the tail length size or increasing the check ring.

Small friction coefficient, The contact pressure between the mating surface and the mating surface is low, and the friction between the work face and the mating surface is the smallest in all seal types. with or without lubrication can work, wear resistance, long service life.

The working medium of the sealing sleeve has wide adaptability, and the other chemicals are not reacted except soluble alkali metal, high temperature fluorine gas and three fluoride chloride.

The working temperature range is wide, and can be used for -200 ℃ to +250 ℃.

It can be used for very high speed, very low speed, micro-stroke and other special conditions.

Suitable for aviation, military and industrial sealing groove size, The standard installation groove is the same size as the standard O ring, and the size is small. It can be designed as non standard parts to meet the sealing requirements of any size groove. The groove is open or semi open.

It can be used in rotary sealing. It can adapt to large eccentricity and beating.

2. Standard materials

Sealing sleeve: PTFE

Spring: Stainless steel 304, 316

3. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range ℃	Speed	Medium
3 - 1600mm	0 - 20MPa	-200 ~ +250	5 m/s	High and low temperature oil and water and other fluids.

4. Installation Sizes

Back pressure surfaceR1=0.1 ~ 0.2, tank bottom R2=0.3 ~ 0.5, Import lengthC=(0.7 ~ 1.0)L.

Rod Diameter	Groove Width	Groove Diameter	Radial Clearance
d	L	D	e
2 ~ 10	2.5	d+3.0	0.05
10 ~ 22	3.2	d+4.0	0.065
22 ~ 52	4.7	d+6.0	0.075
48 ~ 150	7.5	d+10.0	0.09
150 ~ 400	11.0	d+15.0	0.10

5. Matters needing attention

Ⅰ, The installation groove must be open or semi open, and it is recommended to be open.

Ⅱ, If the seal is for the rotating shaft, it is recommended that the surface hardness of the shaft should be no less than HRC40.

Ⅲ，Considering the adaptability of the working medium, the adaptability of the jacket and spring should be taken into account.

Ⅳ, It is better to install an anti fouling ring or a antifouling guide ring in the notch direction in front of the seal.



Company Features
1. After years of stable development, Dms Seals Technology Co.,limited has become one of leading rod end seals manufacturers. Dms Seals Technology Co.,limited is a manufacturer of production and wholesale of spring loaded double lip seal . Dms Seals Technology Co.,limited is a high-tech enterprise with strong R&D strength and modern operation and management concept. Dms Seals Technology Co.,limited's growing range of oil seal manufacturer offer a great alternative to customers. As one of the most competitive enterprise, DMS Seal Manufacturer is famous for its mechanical seal arrangement and excellent service.
2. Almost all technician talent for the industry of conical spring mechanical seal work in our Dms Seals Technology Co.,limited. With the unique technology and stable quality, our spring loaded oil seal win a wider and wider market gradually. Dms Seals Technology Co.,limited has successfully got several patents for technology. All our technician in Dms Seals Technology Co.,limited are well trained to help customers solve problems for stationary mechanical seal .
3. The DMS Seal Manufacturer plant is in accordance with the requirements of IS09001 quality system. Our business touches the lives of millions of people and we understand that we can have a bigger impact by working collaboratively with partners. We amplify what we do internally and working collaboratively with our clients to support their corporate responsibility agendas. Call! Dms Seals Technology Co.,limited will provide the best service while expending as few resources as possible. Call! Through developing and implementing key programs, we aim to minimize the impact of our operations on the environment by understanding and mitigating against our material impacts.
