DMS Seal Manufacturer wiper seal Suppliers to high and low speed

Company Advantages
1. DMS Seal Manufacturer is made by using the finest quality materials and leading techniques. DMS Seals provides professional design and production of high-grade o-ring seals
2. This product can help people dress in a way that makes them feel comfortable especially in day to day situations. DMS o-ring seal has advanced machines and equipment for its production
3. The product is free of wrinkles. The fiber is treated to feature high elasticity and strong frictional resistance to retain the shape of the fabric. As a modern sealing technology company, DMS Seal manufacturer has a wealth of experience

1. Installation Recommendation

2. Application and properties

The standard combination seal is suitable for a wide range of pressure work and sliding high speed occasions. Low friction, strong wear resistance.



3. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM

4. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
6-1600mm	0-35MPa	-30℃ +200℃	1.5 m/s	general hydraulic oil, water glycol Hydraulic oil and water emulsion type hydraulic oil.



5. Installation Dimensions

Nominal Size of Packing, and Housing dimensions				Order No.
d	D	H	L +0.2
18 20 22	27 29 31	4.3 4.3 4.3	4.5 4.5 4.5	SPN18*27*4.3 SPN20*29*4.3 SPN22*31*4.3
27 31.5 47	36 40.5 60	4.3 4.3 7.3	4.5 4.5 7.5	SPN27*36*4.3 SPN31.5*40.5*4.3 SPN47*60*7.3
53 60 65	66 73 78	7.3 7.3 7.3	7.5 7.5 7.5	SPN53*66*7.3 SPN60*73*7.3 SPN65*78*7.3
70 75 80	83 88 93	7.3 7.3 7.3	7.5 7.5 7.5	SPN70*83*7.3 SPN75*88*7.3 SPN80*93*7.3
90 100 110	103.4 113.4 123.4	7.3 7.3 7.3	7.5 7.5 7.5	SPN90*103.4*7.3 SPN100*113.4*7.3 SPN110*123.4*7.3
120 130 140	133.4 143.4 153.4	7.3 7.3 7.3	7.5 7.5 7.5	SPN120*133.4*7.3 SPN130*143.4*7.3 SPN140*153.4*7.3

Company Features
1. Dms Seals Technology Co.,limited is one of the most outstanding manufacturers of wiper seal . We have forged long-term business relationships with our customers. These customers come from Asia, Europe, the Middle East, Africa, etc and are very satisfied with our products and services.
2. Our manufacturing center consists of production lines, assembly lines, and quality inspection lines. These lines are all controlled by the QC team to comply with regulations of the quality management system.
3. We have an experienced manufacturing team. They combine their years of experience with various processing technologies to manufacture products at the highest level. Implementing the policy of wholesale oil seals and striving to promote development of DMS Seal Manufacturer are our present goal. Inquire now!
