DMS Seals Bulk buy bearing seal manufacturers vendor for piston and hydraulic cylinder

Company Advantages
1. The research and development of DMS Seals bearing seal manufacturers is professionally done. It is created with a combination of ergonomics and different features of mobile phones.
2. Right fabric is adopted for DMS Seals . It is chosen by our experienced designers who know how a fabric will drape and feel.
3. DMS Seals is produced using state-of-art machines. It is scrutinized by on-line monitoring equipment which can detect its fabric strength and weaving fineness.
4. DMS Seals is produced complying with the requirements stipulated in the bathroom ware industry. It will be strictly scrutinized in terms of surface flaws, seaming quality, luster, temperature resistance capability, etc.
5. All aspects of the product, such as performance, durability, usability, etc., are carefully tested and tested before production and delivery.
6. This product meets some of the world’s most stringent quality standards, and more importantly, it meets customers' standards.
7. The product has obtained numerous certifications from international standards testing. It is tested to be of high performance and can be used for a long time.
8. bearing seal manufacturers enjoys high reputation among overseas customers and has created a good public image over the years.
9. The international market share of this product is increasing.
10. With its irreplaceable market demand, it will be recognized by customers for a long time.

1. Installation Recommendation

2. Installation Sizes

Rod Diameter	Outer Diameter	Groove Width	Install Chamfer	Radius	Radial Clearance                S max.
d f8	D H8	L+0.2	L1	R1	10MPa	20MPa	40MPa
50-69.9	d+15.0	7.5	5.0	0.4	0.5	0.4	0.3
70-149.9	d+20.0	10.1	6.0	0.4	0.7	0.5	0.4
200-244.9	d+25.0	12.5	8.5	0.4	0.8	0.6	0.5
245-519.9	d+30.0	15.0	10.0	0.8	0.9	0.7	0.6
520-769.9	d+35.0	17.5	13.0	1.2	1.0	0.8	0.7
770-1500	d+40.0	20.0	15.0	1.2	1.0	0.8	0.7

3. Application and properties

Applied for larger diameter piston rods and heavy-duty hydraulic rod sealing system in hard working conditions. High pressure resistance, excellent resistance to gap extrusion, wear-resisting.

4. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM



5. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3 - 1600mm	0 - 60MPa	-30℃ +100℃	5 m/s	hydraulic oil, flame retardant liquid, water, gas

6. Installation Dimensions

Rod Dia.	Outer Dia.	Groove Width	Order No.
d f8	D H8	L+0.2
50 60 70	65 75 85	7.5 7.5 7.5	GSJ-W50*65*7.5 GSJ-W60*75*7.5 GSJ-W70*85*7.5
75 80 100	95 100 120	10 10 10	GSJ-W75*95*10 GSJ-W80*100*10 GSJ-W100*120*10
110 115 120	130 135 140	10 10 10	GSJ-W110*130*10 GSJ-W115*135*10 GSJ-W120*140*10
130 140 145	150 160 165	10 10 10	GSJ-W130*150*10 GSJ-W140*160*10 GSJ-W145*165*10
150 160 170	170 180 190	10 10 10	GSJ-W150*170*10 GSJ-W160*180*10 GSJ-W170*190*10
175 180 200	195 200 220	10 10 10	GSJ-W175*195*10 GSJ-W180*200*10 GSJ-W200*220*10
230 240 250	255 265 275	12.5 12.5 12.5	GSJ-W230*255*12.5 GSJ-W240*265*12.5 GSJ-W250*275*12.5
260 265 270	285 290 295	12.5 12.5 12.5	GSJ-W260*285*12.5 GSJ-W265*290*12.5 GSJ-W270*295*12.5
280 290 300	305 315 325	12.5 12.5 12.5	GSJ-W280*305*12.5 GSJ-W290*315*12.5 GSJ-W300*325*12.5

Company Features
1. Dms Seals Technology Co.,limited is a large manufacturer for bearing seal manufacturers . DMS Seals has made achievements in the field of double mechanical seal centrifugal pump . DMS Seals has been on its way to create excellency in pu seals manufacturer market. Dms Seals Technology Co.,limited is known as a leading manufacturer for common seal manufacturers .
2. Dms Seals Technology Co.,limited always adheres to the scientific concept of development. Our industrial mechanical seals are very competitive in the industry for its high quality. Up until now, Dms Seals Technology Co.,limited has possessed an outstanding systematic ability to develop new lip seal vs mechanical seal products. DMS Seals establishes competent labs to manufacture piston seals . Dms Seals Technology Co.,limited has set up perfect quality guarantee system and sound management system.
3. We have a strong awareness of environmental sustainability. We will proactively promote sound environmental management and sustainable development, such as effective and professional waste management. We endeavor to play an active role in reducing the negative impact on the environment. During production, we encourage less energy consumption and less pollution relying on newly introduced high-efficient manufacturing machines. As a socially responsible business, we continuously improve and track environmental performance, and improve the understanding and guidance of the environment for all employees. We are committed to taking our environmental responsibility. We are focusing on production processes that have less impact on the environment, biodiversity, waste treatment, and distribution processes.
