DMS Seals Bulk oil seal manufacturers in china company

Company Advantages
1. DMS Seals oil seal manufacturers in china shows the outstanding performance, after years of improvement in the production process. The production process is managed in an efficient manner and therefore this product is produced at a quick rate.
2. The design of DMS Seals is elaborately designed with the combination of functionality and aesthetics.
3. DMS Seals is a well-crafted product that adopts advanced technologies and is processed by specialized and highly efficient production lines. It is produced directly from the well-equipped facility.
4. oil seal manufacturers in china is made from eco-friendly materials to minimize pollution and use of resources in materials and production and disposal.
5. DMS Seals is designed as per the latest market trends & styles.
6. The product does not contain harmful ingredients in fabrics. It has been tested to meet the fiber content of clothing compliant with the Textile Fiber Products Identification Act.
7. The product is highly hard-wearing. It is made of abrasion-resistant materials that enable it to withstand harsh wearing conditions.
8. This product is highly resistant to flexure. It is not prone to continuous flexing in walking or running and can remain its original shape.
9. This product is highly resistant to bacteria. During the production stage, antibacterial agents have been added to provides an effective barrier to resist bacteria.
10. This product can last for a long time. Featuring a strong construction, it is not easy to break down after long time use.
11. The product offers great comfort and cushion to wearers' feet that carry the weight of their bodies throughout the day.
12. This product demonstrates environmental, health, and sustainable attributes which increase its value while publicizing the triple bottom line: people, profit, and the planet.
13. With its aesthetic and functional characteristics, this product provides an effective space solution for a variety of places including offices, dining facilities, and hotels.

1. Installation Recommendation

2. Installation Sizes

Rod Diameter	Outer Diameter	Groove Width	Install Chamfer	Radius	Radial Clearance                S max.
d f8	D H8	L+0.2	L1	R1	10MPa	20MPa	40MPa
50-69.9	d+15.0	7.5	5.0	0.4	0.5	0.4	0.3
70-149.9	d+20.0	10.1	6.0	0.4	0.7	0.5	0.4
200-244.9	d+25.0	12.5	8.5	0.4	0.8	0.6	0.5
245-519.9	d+30.0	15.0	10.0	0.8	0.9	0.7	0.6
520-769.9	d+35.0	17.5	13.0	1.2	1.0	0.8	0.7
770-1500	d+40.0	20.0	15.0	1.2	1.0	0.8	0.7

3. Application and properties

Applied for larger diameter piston rods and heavy-duty hydraulic rod sealing system in hard working conditions. High pressure resistance, excellent resistance to gap extrusion, wear-resisting.

4. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM



5. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3 - 1600mm	0 - 60MPa	-30℃ +100℃	5 m/s	hydraulic oil, flame retardant liquid, water, gas

6. Installation Dimensions

Rod Dia.	Outer Dia.	Groove Width	Order No.
d f8	D H8	L+0.2
50 60 70	65 75 85	7.5 7.5 7.5	GSJ-W50*65*7.5 GSJ-W60*75*7.5 GSJ-W70*85*7.5
75 80 100	95 100 120	10 10 10	GSJ-W75*95*10 GSJ-W80*100*10 GSJ-W100*120*10
110 115 120	130 135 140	10 10 10	GSJ-W110*130*10 GSJ-W115*135*10 GSJ-W120*140*10
130 140 145	150 160 165	10 10 10	GSJ-W130*150*10 GSJ-W140*160*10 GSJ-W145*165*10
150 160 170	170 180 190	10 10 10	GSJ-W150*170*10 GSJ-W160*180*10 GSJ-W170*190*10
175 180 200	195 200 220	10 10 10	GSJ-W175*195*10 GSJ-W180*200*10 GSJ-W200*220*10
230 240 250	255 265 275	12.5 12.5 12.5	GSJ-W230*255*12.5 GSJ-W240*265*12.5 GSJ-W250*275*12.5
260 265 270	285 290 295	12.5 12.5 12.5	GSJ-W260*285*12.5 GSJ-W265*290*12.5 GSJ-W270*295*12.5
280 290 300	305 315 325	12.5 12.5 12.5	GSJ-W280*305*12.5 GSJ-W290*315*12.5 GSJ-W300*325*12.5

Company Features
1. Dms Seals Technology Co.,limited has excellent oil seal manufacturers in china to satisfy the needs of different customers. Dms Seals Technology Co.,limited uses the most advanced technology to manufacture hydraulic seals catalogue . Aided by highly advanced technology, DMS Seals is a wide famous exporter in the field of piston rings by size . DMS Seals is a world-famous depac mechanical seal provider. DMS Seals is a reliable and acceptable mechanical seal maintenance manufacturer in this developing industry.
2. With advanced technology applied in rubber seal strip suppliers , we take the lead in this industry. All our technician in Dms Seals Technology Co.,limited are well trained to help customers solve problems for lead seal manufacturers . Our advanced machine is able to fabricate such mechanical seal construction with features of [拓展关键词/特点]. Quality is above everything in Dms Seals Technology Co.,limited. Our production capacity occupies steadily in the forefront of the lip seal vs mechanical seal industry.
3. By providing high quality products and services for our customers, DMS Seals brings increased value to our customers. Inquire online! Cherishing resources and protecting the environment is an eternal commitment from Dms Seals Technology Co.,limited. Inquire online! With fantastic vision, Dms Seals Technology Co.,limited intends to become the most aggressive mechanical seal presentation supplier. DMS Seals has always been committed to providing one-stop service for domestic and foreign customers. Inquire online!
