DMS Seals Buy industrial seals manufacturers manufacturer

Company Advantages
1. helps industrial seals manufacturers to be the most salable product in our market. The R&D teams have the ability to design and develop seals for various of complicated working condition of sealing system
2. We believe that there are good prospects for this product. DMS Seals' production equipment and test equipment are on the leading level in the industry
3. The product is not easily affected by the ultra harmonics in the power grid. The suppression surge technology used in it can effectively help control the harmonics to the minimum limit. DMS Seals provides professional design and production of high-grade o-ring seals

1. Installation Recommendation

2. Application and properties

The standard combination seal is suitable for a wide range of pressure work and sliding high speed occasions. Low friction, strong wear resistance.



3. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM

4. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
6-1600mm	0-35MPa	-30℃ +200℃	1.5 m/s	general hydraulic oil, water glycol Hydraulic oil and water emulsion type hydraulic oil.



5. Installation Dimensions

Nominal Size of Packing, and Housing dimensions				Order No.
d	D	H	L +0.2
18 20 22	27 29 31	4.3 4.3 4.3	4.5 4.5 4.5	SPN18*27*4.3 SPN20*29*4.3 SPN22*31*4.3
27 31.5 47	36 40.5 60	4.3 4.3 7.3	4.5 4.5 7.5	SPN27*36*4.3 SPN31.5*40.5*4.3 SPN47*60*7.3
53 60 65	66 73 78	7.3 7.3 7.3	7.5 7.5 7.5	SPN53*66*7.3 SPN60*73*7.3 SPN65*78*7.3
70 75 80	83 88 93	7.3 7.3 7.3	7.5 7.5 7.5	SPN70*83*7.3 SPN75*88*7.3 SPN80*93*7.3
90 100 110	103.4 113.4 123.4	7.3 7.3 7.3	7.5 7.5 7.5	SPN90*103.4*7.3 SPN100*113.4*7.3 SPN110*123.4*7.3
120 130 140	133.4 143.4 153.4	7.3 7.3 7.3	7.5 7.5 7.5	SPN120*133.4*7.3 SPN130*143.4*7.3 SPN140*153.4*7.3

Company Features
1. After years of engaging in the manufacturing of , Dms Seals Technology Co.,limited is well-known as a competent enterprise in China. Dms Seals Technology Co.,limited is technologically professional, which makes it a pioneer in the industrial seals manufacturers field.
2. We have imported a series of production facilities in our factory. They are highly automated, which allows to create and manufacture virtually any shape or design of a product.
3. We always believe that our R&D team contributes significantly to the sustainability of our business. Their abundant knowledge and experience about the products, industry, and clear foresight about future problems or market trends has proved of importance for us. Our passion for the cause motivates us to fulfill our mission and pursue perfection of buy mechanical seal . Call now!
