DMS Seals Custom hydraulic cylinder seal compression tool Suppliers for light and medium hydraulic systems
1. During the design stage of DMS Seals , static electricity protection is considered. It has passed through the electrostatic precipitation process. Our products mainly include rod seals, piston seals, scraper seals, rotary seals, rubber seal products and spring seals
2. Dms Seals Technology Co.,limited can accept trial order for testing quality first. To reduce costs with high-efficiency work is the DMS's purpose
3. With company philosophy of 'Quality comes first.', the product is guaranteed to meet the highest quality standards. DMS Seals manufacturer owns a team of professional R&D group and skilled technicians
Application and properties
Suitable for seals of pistons and plungers, tandem seals for a variety of liquid applications are internal seals. Before installation, the sealing lip is protruded outwards, and the cylinder liner is pressed tightly after installation to provide elasticity for the wear ring, excellent sealing results can be achieved even in the absence of pressure. It can separate the liquid on both sides of the sealing ring, so it is also suitable for the sealing of the oil chamber, and the invasion of other liquids can be prevented. High wear resistance, low friction, no crawling phenomenon.
Standard materials
Sealing ring: filled PTFE
Elastomer: NBR / PU
Working Conditions | ||||
Diameter Range | Pressure Range | Temperature Range | Speed | Medium |
3-1600mm | 0-25MPa | -30℃+100℃ | 1 m/s | hydraulic oil, flame retardant liquid, water and others |
D H8 | d h9 | H | L+0.2 | e | Order No. |
40 | 30 | 15 | 16 | 7 | DDMA40*30*16 |
56 | 46 | 15 | 16 | 7 | DDMA56*46*16 |
70 | 60 | 15 | 16 | 7 | DDMA70*60*16 |
85 | 75 | 15 | 16 | 7 | DDMA85*75*16 |
100 | 90 | 15 | 16 | 7 | DDMA100*90*16 |
120 | 110 | 15 | 16 | 7 | DDMA120*110*16 |
135 | 123 | 15 | 16 | 10 | DDMA135*123*16 |
150 | 138 | 15 | 16 | 10 | DDMA150*138*16 |
170 | 158 | 15 | 16 | 10 | DDMA170*158*16 |
200 | 188 | 15 | 16 | 10 | DDMA200*188*16 |
225 | 213 | 15 | 16 | 10 | DDMA225*213*16 |
Company Features
1. With professional technical standards and passionate talents, DMS Seals is committed to producing high quality hydraulic cylinder seal compression tool .
2. DMS Seals will always pursue high quality hydraulic cylinder piston seals . Call!
