DMS Seals DMS Seals hydraulic sealing solutions wholesale for sale

Company Advantages
1. Fine materials: DMS Seals hydraulic sealing solutions is manufactured based on high quality raw materials which are supplied by our reliable partners. These partners are all well-selected by us.
2. Advanced technology and latest machine & equipment are used to ensure DMS Seals is manufactured based on the requirements of lean production.
3. Strong designer team: DMS Seals is designed by our design team who are powerful with professional design knowledge. They are also well-trained to put forward design concept and complete the design in a short time.
4. Our experienced team pays much more attention to the crafts design of .
5. The manufactured hydraulic sealing solutions has such merits of as to be used in area.
6. The benefits of hydraulic sealing solutions will be seen in .
7. Dms Seals Technology Co.,limited relys on the great power of its funds and technology to enable hydraulic sealing solutions R&D and manufacturing up to the international advanced standard.
8. hydraulic sealing solutions are tasteful and have long enjoyed great fame both at home and aboard.
9. In Dms Seals Technology Co.,limited, process requirements of producing hydraulic sealing solutions is very strict.

1. Installation Recommendation

2. Application and properties

Suitable for long stroke, a wide range of fluids and high temperature occasions. The application of heavy duty double acting piston sealing under high pressure conditions is excellent. Applicable to larger piston clearance , it has good leakage control, extrusion resistance and wear resistance in heavy duty and construction machinery cylinder piston sealing system. Good static sealing property, simple groove structure, larger extrusion clearances can be allowed, be able to work in dusty condition.

3. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM

Back-up ring: POM / PA

4. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
50 - 350mm	0 - 50MPa	-30℃ +100℃	1.5 m/s	hydraulic oil, flame retardant liquid, water and others

5. Installation Dimensions

Nominal Size of Packing, and Housing dimensions			L+0.2	Order No.
D1	dN	H
50 55 60	36 41 46	8.5 8.5 8.5	9 9 9	SPGW50*36*8.5 SPGW55*41*8.5 SPGW60*46*8.5
63 65 70	48 50 55	10.5 10.5 10.5	11 11 11	SPGW63*48*10.5 SPGW65*50*10.5 SPGW70*55*10.5
75 80 85	60 65 70	10.5 10.5 10.5	11 11 11	SPGW75*60*10.5 SPGW80*65*10.5 SPGW85*70*10.5
90 95 100	75 80 85	10.5 10.5 12	11 11 12.5	SPGW90*75*10.5 SPGW95*80*10.5 SPGW100*85*12
105 110 115	90 95 100	12 12 12	12.5 12.5 12.5	SPGW105*90*12 SPGW110*95*12 SPGW115*100*12
120 125 130	105 102 107	12 15.5 15.5	12.5 16 16	SPGW120*105*12 SPGW125*102*15.5 SPGW130*107*15.5
135 140 145	112 117 122	15.5 15.5 15.5	16 16 16	SPGW135*112*15.5 SPGW140*117*15.5 SPGW145*122*15.5
150 155 160	127 132 137	15.5 15.5 15.5	16 16 16	SPGW150*127*15.5 SPGW155*132*15.5 SPGW160*137*15.5
165 170 180	142 147 157	15.5 15.5 15.5	16 16 16	SPGW165*142*15.5 SPGW170*147*15.5 SPGW180*157*15.5
185 190 200	162 167 177	15.5 15.5 15.5	16 16 16	SPGW185*162*15.5 SPGW190*167*15.5 SPGW200*177*15.5
210 220 225	187 197 202	15.5 15.5 17	16 16 17.5	SPGW210*187*15.5 SPGW220*197*15.5 SPGW225*202*15.5
230 240 250	207 217 222	17 17 17	17.5 17.5 17.5	SPGW230*207*15.5 SPGW240*217*15.5 SPGW250*222*17
260 270 280	232 242 252	17 17 17	17.5 17.5 17.5	SPGW260*232*17 SPGW270*242*17 SPGW280*252*17
300 320 350	272 292 322	17 17 17	17.5 17.5 17.5	SPGW300*272*17 SPGW320*292*17 SPGW350*322*17

Company Features
1. DMS Seals is a mature enterprise which integrates developing, designing and manufacturing hydraulic sealing solutions . Through independent innovation and introducing advanced equipment, DMS Seals is able to produce high quality shaft seal design . Dms Seals Technology Co.,limited has always been a vanguard company in hydraulic rod seal installer market.
2. Dms Seals Technology Co.,limited is an international service team of rubber piston seal product. DMS Seals realized that the bottleneck of manufacturing piston lip seal needs to be broken by implementing new technology. Dms Seals Technology Co.,limited has strong technical force with numbers of professional senior engineers and intermediate technicians. The quality of wholesale oil seals has gained more and better comments from customers. Putting large amount of investment into the technical force facilitates the popularity and fame of both hydraulic oil seal manufacturers and DMS Seals.
3. The company incorporates social responsibility into its overall business developing strategy. To execute this strategy, we are trying hard to end or relief the poverty of local areas by driving local economic growth. Please contact us! We incorporate customers service into our running principle. We spare no effort to cater to our customers. We offer VIP treatments for our best customers or specific customers. For example, we are willing to manufacture products or sourced materials that are not our primary business. We unswervingly uphold the service concept of 'Customer First'. We will work hard to improve customer interactions by practicing active listening and following up their orders after a problem is solved. Under this method, customers will feel heard and concerned. We are striving hard to develop more efficient and environmental-friendly products by increasing investment in R&D. At the same time, we work together with the local communities to minimize the impact on the environment.
