DMS Seals high end hydraulic oil seal manufacturers Supply for sale

Company Advantages
1. DMS Seals is manufactured through superior manufacturing processes.
2. The production process of DMS Seals complies with international green specifications.
3. This product is offered with different sizes and colors and has potential to meet various needs in the industry.
4. The raw materials of DMS Seals is sourced from prestigious vendors in order to match the global quality standards.
5. DMS Seals is constructed from well-chosen raw materials.
6. With such good performance of , hydraulic oil seal manufacturers is the perfect at present.
7. hydraulic oil seal manufacturers is still valuable due to its advantages as .
8. hydraulic oil seal manufacturers has found increasingly wider application due to its advantages of long service life, low coat and .
9. hydraulic oil seal manufacturers can stand all kinds of strict tests before putting into use.
10. Our technical team has been dedicated themselves into developing for hydraulic oil seal manufacturers .
11. Mature technology, standardized production and strict quality management system ensure the quality of hydraulic oil seal manufacturers .
12. As time goes by, hydraulic oil seal manufacturers has developed an efficient way to produce hydraulic pump oil seal in a high efficiency.
13. Dms Seals Technology Co.,limited has great competitive strengths in hydraulic oil seal manufacturers market all over China.

1. Installation Recommendation

2. Installation Sizes

Rod Diameter d e8	Groove Diameter D H9	Groove Width L D10	H
20-56	d+10	16	15
57-140	d+13	16	15
＞140	d+15	16	15

3. Application and properties

Suitable for tandem type internal sealing, and can be used as fluid sealing and dust sealing simultaneously. Excellent sealing effect can be achieved in case of no pressure. Easy installation, wear-resisting, anti extrusion, low friction, non stick slip phenomenon.

4. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / PU

5. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3 - 1600mm	0 - 25MPa	-30℃ + 100℃	1 m/s	hydraulic oil, flame retardant liquid, water, gas

6. Installation Dimensions

d e8	D1 H9	H	L D10	e	Order No.
50 55 56	60 65 66	15 15 15	16 16 16	6 6 6	MDI50*60*15 MDI55*65*15 MDI56*66*15
60 63 65	73 76 78	15 15 15	16 16 16	7 7 7	MDI60*73*15 MDI63*76*15 MDI65*78*15
70 72 75	83 85 88	15 15 15	16 16 16	7 7 7	MDI70*83*15 MDI72*85*15 MDI75*88*15
80 85 90	93 98 103	15 15 15	16 16 16	7 7 7	MDI80*93*15 MDI85*98*15 MDI90*103*15
95 100 105	108 113 118	15 15 15	16 16 16	7 7 10	MDI95*108*15 MDI100*113*15 MDI105*118*15
110 110 115	120 123 128	15 15 15	16 16 16	10 10 10	MDI110*120*15 MDI110*123*15 MDI115*128*15
120 125 130	133 138 143	15 15 15	16 16 16	10 10 10	MDI120*133*15 MDI125*138*15 MDI130*143*15
140 150 150	153 162 165	15 15 15	16 16 16	10 10 10	MDI140*153*15 MDI150*162*15 MDI150*165*15
160 165 170	175 180 185	15 15 15	16 16 16	10 10 10	MDI160*175*15 MDI165*180*15 MDI170*185*15
180 185 190	195 200 205	15 15 15	16 16 16	10 10 10	MDI180*195*15 MDI185*200*15 MDI190*205*15

Company Features
1. DMS Seals has been on its way to create excellency in hydraulic oil seal manufacturers market. Dms Seals Technology Co.,limited has been the OEM supplier for a many famous hydraulic pump oil seal brand since its inception. DMS Seals has been always striving to develop new push rod seal to meet customers. When it comes to professionalism for manufacturing rod seal catalogue , Dms Seals Technology Co.,limited is undoubtedly one of them. Dms Seals Technology Co.,limited provides the less expensive and more cost-effective hydraulic jack piston seal to fulfill each customer needs.
2. Our technology takes the lead in the industry of hydraulic rod seals online . With advanced technology applied in u seal design , we take the lead in this industry. Staff working in Dms Seals Technology Co.,limited are all well-trained. We put great emphasis on technology of hydraulic oil seal sizes .
3. DMS Seals is looking forward to cooperating with you by providing our fantastic hydraulic oil seal manufacturers . Contact! Dms Seals Technology Co.,limited has a leading industry position and brand. Contact! DMS Seals tries to be the most dominant hydraulic and pneumatic seals supplier. Contact! The hydraulic swivel seals of Dms Seals Technology Co.,limited represents our strong production capacity. Contact! Dms Seals Technology Co.,limited is committed to providing professional services and reliable packing rod seals . Contact!
