DMS Seals hyd seal company for pressure work and sliding high speed occasions

Company Advantages
1. The advanced technology and sophisticated equipment give DMS Seals the fine workmanship. High-end talents and advanced technology have enabled DMS o-ring seal quality to reach the industry's leading level
2. It is really hard for me to find any damage and no more leakage generated by using this product when it is applied in the extreme environments - Said one of our customers. DMS Seals' production equipment and test equipment are on the leading level in the industry
3. Having been successfully explored an advanced craft guarantees the well operation of hyd seal . Seal we produced has applications in a wide range of fields
4. Relying on the advanced technology, hyd seal has a strong ability of . DMS Seals takes the lead in grasping the development trend of the industry

1. Installation Recommendation

2. Installation Sizes

Rod Diameter d e8	Groove Diameter D H9	Groove Width L D10	H
20-56	d+10	16	15
57-140	d+13	16	15
＞140	d+15	16	15

3. Application and properties

Suitable for tandem type internal sealing, and can be used as fluid sealing and dust sealing simultaneously. Excellent sealing effect can be achieved in case of no pressure. Easy installation, wear-resisting, anti extrusion, low friction, non stick slip phenomenon.

4. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / PU

5. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3 - 1600mm	0 - 25MPa	-30℃ + 100℃	1 m/s	hydraulic oil, flame retardant liquid, water, gas

6. Installation Dimensions

d e8	D1 H9	H	L D10	e	Order No.
50 55 56	60 65 66	15 15 15	16 16 16	6 6 6	MDI50*60*15 MDI55*65*15 MDI56*66*15
60 63 65	73 76 78	15 15 15	16 16 16	7 7 7	MDI60*73*15 MDI63*76*15 MDI65*78*15
70 72 75	83 85 88	15 15 15	16 16 16	7 7 7	MDI70*83*15 MDI72*85*15 MDI75*88*15
80 85 90	93 98 103	15 15 15	16 16 16	7 7 7	MDI80*93*15 MDI85*98*15 MDI90*103*15
95 100 105	108 113 118	15 15 15	16 16 16	7 7 10	MDI95*108*15 MDI100*113*15 MDI105*118*15
110 110 115	120 123 128	15 15 15	16 16 16	10 10 10	MDI110*120*15 MDI110*123*15 MDI115*128*15
120 125 130	133 138 143	15 15 15	16 16 16	10 10 10	MDI120*133*15 MDI125*138*15 MDI130*143*15
140 150 150	153 162 165	15 15 15	16 16 16	10 10 10	MDI140*153*15 MDI150*162*15 MDI150*165*15
160 165 170	175 180 185	15 15 15	16 16 16	10 10 10	MDI160*175*15 MDI165*180*15 MDI170*185*15
180 185 190	195 200 205	15 15 15	16 16 16	10 10 10	MDI180*195*15 MDI185*200*15 MDI190*205*15

Company Features
1. Dms Seals Technology Co.,limited has specialized in the production and sales of hyd seal . Dms Seals Technology Co.,limited enjoys solid financial and technological strength to make sure the quality of hydraulic ram seals online .
2. In order to be the leading air cylinder piston seals supplier, DMS Seals has introduced cutting-edge machines to ensure the quality.
3. Dms Seals Technology Co.,limited has greatly enhanced the R&D ability for wholesale oil seals production. The basic principle of DMS Seals is to insist on customer first. Welcome to visit our factory!
