DMS Seals hydraulic cylinder shaft seals vendor for sale

Company Advantages
1. Under computer control, DMS Seals is processed through a series of heavy duty mixing systems to add more ingredients at a designated time and/or temperature.
2. DMS Seals is created throughout a series of production processes which include raw material extraction, raw material process, and quality inspections.
3. The cell assembly and case formation of DMS Seals is strictly carried out on highly automated equipment by our professional workers.
4. This product is notable for its dimensional stability. Its dimensions will be not easy to change when it is torn frequently.
5. This product is known for its load-bearing capacity. Made of materials that feature high rigidity, it is not likely to be out of shape.
6. This product allows for easy gait. Its lightweight feature and ergonomic design greatly help enhance walking stability.
7. This product retains its original appearance over time. The dust and other residues are not prone to build upon its surface.
8. This product features abrasion resistance. Its fabrics are tough enough to withstand surface wear, rubbing, chafing, and other frictional actions.
9. More and more people are attracted by the great economic benefits of the product, which sees its great market potential.
10. The product, with great commercial value, meets the demanding requirements of global customers.
11. This product has been widely used in the market and has a broad market prospect.

1. Installation Recommendation

2. Application and properties

Applicable to a wide range of pressure work and sliding high speed occasions. Standard combined seal. Low friction, strong wear resistance.

3. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM





4. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3 - 1600mm	0 - 35MPa	-30℃ + 200℃	1.5m/s	general hydraulic oil, water glycol hydraulic oil, oil / water emulsion type hydraulic oil.

5. Installation Dimensions

Nominal Size of Packing, and Housing dimensions				Order No.
d	D	H	L +0.2
12 14 16	18 20 22	3.0 3.0 3.0	3.2 3.2 3.2	SPNO12*18*3.2 SPNO14*20*3.2 SPNO16*22*3.2
18 20 22	24 26 31	3.0 3.0 3.8	3.2 3.2 4	SPNO18*24*3.2 SPNO20*26*3.2 SPNO22*31*4
25 28 30	34 37 39	3.8 3.8 3.8	4 4 4	SPNO25*34*4 SPNO28*37*4 SPNO30*39*4
32 36 40	41 45 49	3.8 3.8 3.8	4 4 4	SPNO32*41*4 SPNO36*45*4 SPNO40*49*4
45 50 56	54 65 71	3.8 6.3 6.3	4 6.5 6.5	SPNO45*54*4 SPNO50*65*6.5 SPNO56*71*6.5
60 63 70	75 78 85	6.3 6.3 6.3	6.5 6.5 6.5	SPNO60*75*6.5 SPNO63*78*6.5 SPNO70*85*6.5
75 80 85	90 95 100	6.3 6.3 6.3	6.5 6.5 6.5	SPNO75*90*6.5 SPNO80*95*6.5 SPNO85*100*6.5
90 95 100	105 110 115	6.3 6.3 6.3	6.5 6.5 6.5	SPNO90*105*6.5 SPNO95*110*6.5 SPNO100*115*6.5
105 110 115	120 125 130	6.3 6.3 6.3	6.5 6.5 6.5	SPNO105*120*6.5 SPNO110*125*6.5 SPNO115*130*6.5
120 125 130	135 140 145	6.3 6.3 6.3	6.5 6.5 6.5	SPNO120*135*6.5 SPNO125*140*6.5 SPNO130*145*6.5
135 140 145	150 155 160	6.3 6.3 6.3	6.5 6.5 6.5	SPNO135*150*6.5 SPNO140*155*6.5 SPNO145*160*6.5
150 160 170	170 180 190	9.8 9.8 9.8	10 10 10	SPNO150*170*10 SPNO160*180*10 SPNO170*190*10

Company Features
1. Dms Seals Technology Co.,limited is famous around the world for its high quality of hydraulic cylinder shaft seals . Dms Seals Technology Co.,limited has been leading the domestic field of seals for hydraulic pumps products. Dms Seals Technology Co.,limited has always been a vanguard company in hydraulic cylinder piston rings market. Dms Seals Technology Co.,limited is one of the largest pure R&D centers in the Chinese hydraulic pump oil seal industry.
2. We constantly invest in our production facilities and upgrade them each year. The purposes of these facilities are to improve operational efficiency for our orders and raise productivity. We are blessed with an excellent R&D team. They excel at taking advantage of their industry know-how to provide product development and innovation and customization service more efficiently. Our manufacturing center consists of production lines, assembly lines, and quality inspection lines. These lines are all controlled by the QC team to comply with regulations of the quality management system. We are equipped with a professional customer service team. Their expertise and professionalism ensure the highest efficiency and level in the process they serve our clients. We have set up a team of experts in production. They demonstrate their strong expertise in product design, manufacturing, overall production flow, and packaging.
3. Currently, our business goal is to offer more professional and real-time customer service. We are going to expand our customer service team, and implement a policy that customers are guaranteed to receive feedback from our staff before the end of the business day. The company has a good social conscience. By employing locals workers and treating them fairly and ethically, we always strive to enhance workers welfare and happiness. Get info! We are committed to the highest standards of excellence across all aspects of our business. We look for opportunities to exceed expectations and strive with determination to win and be the best at what we do.

DMS Seals hydraulic cylinder shaft seals vendor for sale

hydraulic cylinder shaft seals

Type:
