DMS Seals hydraulic press seals supplier to high and low speed

Company Advantages
1. DMS Seals is designed and crafted using premium quality basic material.
2. During the process of production, every detail of DMS Seals is highly valued.
3. DMS Seals hydraulic press seals is designed using modern technology in conformity with the set industry standards.
4. DMS Seals has a variety of designs to meet with different customer needs.
5. hydraulic press seals featured better properties, as well as possessed features.
6. hydraulic press seals can be used in , and has an extensive application prospect.
7. is the main feature of hydraulic press seals produced by Dms Seals Technology Co.,limited.
8. This product will never be out of fashion. It is easily dressed up and matched with different styles of garments.
9. People can save themselves the trouble when it comes to clothes fading during washes. So it is worth the investment.
10. This product brings enough comfort to wear. It will not cause irritation and discomfort even for people with sensitive skin.
11. This product will be an ideal choice for people who would like to improve their foot health thanks to its proper fit and desired comfort.
12. Less time and effort are needed to maintain this product over the years, therefore one can save energy and costs.

1. Installation Recommendation

2. Application and properties

The standard combination seal is suitable for a wide range of pressure work and sliding high speed occasions. Low friction, strong wear resistance.



3. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM

4. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
6-1600mm	0-35MPa	-30℃ +200℃	1.5 m/s	general hydraulic oil, water glycol Hydraulic oil and water emulsion type hydraulic oil.



5. Installation Dimensions

Nominal Size of Packing, and Housing dimensions				Order No.
d	D	H	L +0.2
18 20 22	27 29 31	4.3 4.3 4.3	4.5 4.5 4.5	SPN18*27*4.3 SPN20*29*4.3 SPN22*31*4.3
27 31.5 47	36 40.5 60	4.3 4.3 7.3	4.5 4.5 7.5	SPN27*36*4.3 SPN31.5*40.5*4.3 SPN47*60*7.3
53 60 65	66 73 78	7.3 7.3 7.3	7.5 7.5 7.5	SPN53*66*7.3 SPN60*73*7.3 SPN65*78*7.3
70 75 80	83 88 93	7.3 7.3 7.3	7.5 7.5 7.5	SPN70*83*7.3 SPN75*88*7.3 SPN80*93*7.3
90 100 110	103.4 113.4 123.4	7.3 7.3 7.3	7.5 7.5 7.5	SPN90*103.4*7.3 SPN100*113.4*7.3 SPN110*123.4*7.3
120 130 140	133.4 143.4 153.4	7.3 7.3 7.3	7.5 7.5 7.5	SPN120*133.4*7.3 SPN130*143.4*7.3 SPN140*153.4*7.3

Company Features
1. Dms Seals Technology Co.,limited is an internationally active manufacturer of with headquarters in China. We have many years of experience in this industry. For many years, Dms Seals Technology Co.,limited has been engaged in the design and manufacture of hydraulic press seals . We are regarded as a reliable manufacturer and supplier in the industry. Years of experience and expertise have rendered Dms Seals Technology Co.,limited an expert in this field. We are well-known for the manufacturing ability.
2. Staff working in Dms Seals Technology Co.,limited are all well-trained. Our cylinder rod wiper is easily operated and need no additional tools. We have excellent manufacturing and innovation capabilities guaranteed by international advanced hydraulic oil seal sizes equipment. We have the capability of researching and developing state-of-the-art technologies of pneumatic seals .
3. An unwavering commitment to customer satisfaction has indeed changed our production methods and made us a better manufacturer. Inquire! We energetically promote environmental protection and sustainable development. We will use cost-effective and mature technological production facilities to reduce environmental negative influence. As a company bears social responsibility, we see it as our responsibility to handle resources and energy efficiently as well as to avoid environmental risks at all of our locations. We always believe that innovation is a breaking point that we should attach more importance to. Besides adopting international technologies, we need to keep us to be inspired by the latest market trends and potential purchasing trends.

DMS Seals hydraulic press seals supplier to high and low speed

hydraulic press seals

Type:
