Product Details
Dms Seals's Oil Seal Manufacturer is of excellent quality, which is reflected in the details.Dms Seals provides diversified choices for customers. Oil Seal Manufacturer is available in a wide range of types and styles, in good quality and in reasonable price.
Product Comparison
Dms Seals's
O-ring Seal is commonly praised in the market due to good materials, fine workmanship, reliable quality, and favorable price.After being improved greatly, Dms Seals's O-ring Seal is more advantageous in the following aspects.
Company Advantages1. DMS Seals hydraulic rod wipers is of flexible design. It can be designed with different kinds of materials, battery shells, and functions to fit its using environments.
2. DMS Seals is designed by professional designers. Especially the controller of the product has achieved the battery charge and discharge management making use of solar energy.
3. Strict quality control is conducted in the production of DMS Seals . The purity of the cells, the sawing, polishing, and coating of the body are all scrutinized before the product is shipped.
4. DMS Seals hydraulic rod wipers is manufactured with high quality. The contacting performance of electric cables, the stability of the connector, and the contact of the inner conductor are all carefully considered before manufacturing.
5. The quality control DMS Seals is conducted starting from the sourcing of raw fibers to the final stages of the textile production such as dye and coloration.
6. One of the most understanding functions for hydraulic rod wipers is .
7. It meets all performance requirements in its industry.
8. hydraulic rod wipers offers a stunning blend of features and performance.
9. This product is thoroughly inspected by our skilled QC team to rule out every possibility of defect.
10. A series of tests are conducted to improve qualification ratio.
11. In Dms Seals Technology Co.,limited customers can send us your outside cartons design for our customization.
12. All defected hydraulic rod wipers will be picked up and not allowed to deliver to our customers.
13. Large factory and enough well-trained workers can add up to completely guarantee on-time delivery for hydraulic rod wipers .
14. The result shows: our hydraulic rod wipers has met the requirements of the standard, the process has advantages of .
15. Dms Seals Technology Co.,limited can totally ensure quality of hydraulic rod wipers , and if there is any problem, customers can replace for free.
Installation Recommendation
![undefined undefined]()
Application and properties
Suitable for seals of pistons and plungers, tandem seals for a variety of liquid applications are internal seals. Before installation, the sealing lip is protruded outwards, and the cylinder liner is pressed tightly after installation to provide elasticity for the wear ring, excellent sealing results can be achieved even in the absence of pressure. It can separate the liquid on both sides of the sealing ring, so it is also suitable for the sealing of the oil chamber, and the invasion of other liquids can be prevented. High wear resistance, low friction, no crawling phenomenon.
Sealing ring: filled PTFE
Elastomer: NBR / PU
Working Conditions
Working Conditions |
Diameter Range | Pressure Range | Temperature Range | Speed | Medium |
3-1600mm | 0-25MPa | -30℃+100℃ | 1 m/s | hydraulic oil, flame retardant liquid, water and others |
Installation Dimensions
D H8 | d h9 | H | L+0.2 | e | Order No. |
40 45 50 | 30 35 40 | 15 15 15 | 16 16 16 | 7 7 7 | DDMA40*30*16 DDMA45*35*16 DDMA50*40*16 |
56 63 65 | 46 53 55 | 15 15 15 | 16 16 16 | 7 7 7 | DDMA56*46*16 DDMA63*53*16 DDMA65*55*16 |
70 75 80 | 60 65 70 | 15 15 15 | 16 16 16 | 7 7 7 | DDMA70*60*16 DDMA75*65*16 DDMA80*70*16 |
85 90 95 | 75 80 85 | 15 15 15 | 16 16 16 | 7 7 7 | DDMA85*75*16 DDMA90*80*16 DDMA95*85*16 |
100 105 115 | 90 95 105 | 15 15 15 | 16 16 16 | 7 7 7 | DDMA100*90*16 DDMA105*95*16 DDMA115*105*16 |
120 125 130 | 110 113 118 | 15 15 15 | 16 16 16 | 7 10 10 | DDMA120*110*16 DDMA125*113*16 DDMA130*118*16 |
135 140 145 | 123 128 133 | 15 15 15 | 16 16 16 | 10 10 10 | DDMA135*123*16 DDMA140*128*16 DDMA145*133*16 |
150 155 160 | 138 143 148 | 15 15 15 | 16 16 16 | 10 10 10 | DDMA150*138*16 DDMA155*143*16 DDMA160*148*16 |
170 180 190 | 158 168 178 | 15 15 15 | 16 16 16 | 10 10 10 | DDMA170*158*16 DDMA180*168*16 DDMA190*178*16 |
200 210 220 | 188 198 208 | 15 15 15 | 16 16 16 | 10 10 10 | DDMA200*188*16 DDMA210*198*16 DDMA220*208*16 |
225 235 240 | 213 223 228 | 15 15 15 | 16 16 16 | 10 10 10 | DDMA225*213*16 DDMA235*223*16 DDMA240*228*16 |
Company Features1. Dms Seals Technology Co.,limited takes the role of a dependable manufacturer of . We are engaged in design, production, and distribution. Dms Seals Technology Co.,limited has defeated many peer manufacturers in China market when it comes to hydraulic rod wipers development and production. Dms Seals Technology Co.,limited develops, manufactures, tests, and distributes piston seal additive . We are called the excellent manufacturer by industry experts. Dms Seals Technology Co.,limited is a leading manufacturer of functional products in China, specializing in the design, manufacturing, and sales of . Dms Seals Technology Co.,limited is a famous manufacturer in China. We have a significant international influence.
2. With a sense of responsibility, rubber piston seals of DMS Seals is of good quality. Dms Seals Technology Co.,limited has numbers of excellent engineers and mould-making technicians, which make a strong research and development ability. By revolutionizing the technology of producing hydraulic seal kit manufacturers , DMS Seals is able to provide one-stop solution for customers. Dms Seals Technology Co.,limited's R&D capability has highlighted through hydraulic cylinder piston seal leakage . DMS Seals always keeps innovative to update the hydraulic seal design .
3. The mission of DMS Seals is to build itself into a brand that can be trusted and to give customers the most compelling purchasing experience possible. We are a company built on relationships so we listen to our customers. We take their needs on as our own and move as quickly as they need us to. Get more info! The core value of our company to gain success is to keep changing. We have a keen sense of the market trends which constantly changes, and we keep innovating so as to progress continuously. Get more info!
