DMS Seals hydraulic swivel seals vendor for sale

Company Advantages
1. In terms of surface finishes, DMS Seals provide all possible options. The surface treatment is available in a variety of ways. DMS Seals provides professional design and production of high-grade o-ring seals
2. With this product, a commodity can stand out from the competition. Personalized customization makes it possible to differentiate commodity. Our products mainly include rod seals, piston seals, scraper seals, rotary seals, rubber seal products and spring seals
3. This product is not prone to oxidization. When oxygen reacts with it, it is not easy to form an oxide on the surface. DMS Seals takes the lead in grasping the development trend of the industry

1. Installation Recommendation

2. Application and properties

Standard bidirectional seal, a wide range of applications. Friction resistance is very low, no crawling phenomenon, strong wear resistance, and saving installation space.



3. Standard materials

Sealing ring: filled PTFE

O-ring: NBR / FKM





4. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3 - 1600mm	0 - 35MPa	-30℃ +200℃	1.5 m/s	hydraulic oil, flame retardant liquid, water and others.

NO.	SIZE	NO.	SIZE
1	DPO20*14*3.2	32	DPO135*121*6.5
2	DPO25*19*3.2	33	DPO140*126*6.5
3	DPO30*21.5*4	34	DPO150*136*6.5
4	DPO31.5*23*4	35	DPO160*146*6.5
5	DPO32*23.5*4	36	DPO170*150*10
6	DPO35*26.5*4	37	DPO180*160*10
7	DPO35.5*27*4	38	DPO190*170*10
8	DPO40*31.5*4	39	DPO200*180*10
9	DPO45*36.5*4	40	DPO180*160*10
10	DPO50*41.5*4	41	DPO190*170*10
11	DPO53*44.5*4	42	DPO200*180*10
12	DPO55*46.5*4	43	DPO210*190*10
13	DPO56*47.5*4	44	DPO220*200*10
14	DPO60*51.5*4	45	DPO224*204*10
15	DPO63*49*6.5	46	DPO230*210*10
16	DPO65*51*6.5	47	DPO240*220*10
17	DPO70*56*6.5	48	DPO250*230*10
18	DPO71*57*6.5	49	DPO260*240*10
19	DPO75*61*6.5	50	DPO270*250*10
20	DPO80*66*6.5	51	DPO280*260*10
21	DPO85*71*6.5	52	DPO290*270*10
22	DPO90*76*6.5	53	DPO300*280*10
23	DPO95*81*6.5	54	DPO310*290*10
24	DPO100*86*6.5	55	DPO320*300*10
25	DPO105*91*6.5	56	DPO340*320*10
26	DPO110*96*6.5	57	DPO350*330*10
27	DPO112*98*6.5	58	DPO360*340*10
28	DPO115*101*6.5	59	DPO375*355*10
29	DPO120*106*6.5	60	DPO380*360*10
30	DPO125*111*6.5	61	DPO400*380*10
31	DPO130*116*6.5

Company Features
1. Through years of unremitting efforts, Dms Seals Technology Co.,limited has developed into a professional hydraulic swivel seals developer and manufacturer in China.
2. DMS Seals uses high-tech to produce bonded piston seal .
3. DMS Seals ​​will try to be for each product. Call!
