DMS Seals Latest 4 inch metal o rings cost for static sealing
1. DMS Seals 4 inch metal o rings boasts fine design and delicate workmanship.
2. The design of DMS Seals combines aesthetics and functionality.
3. DMS Seals 4 inch metal o rings is manufactured by our competent workforce utilizing well-tested material and sophisticated technology following the set norms of the industry.
4. DMS Seals is produced in fast and accurate flexibility of production methods.
5. The production of DMS Seals 4 inch metal o rings is rather efficient, guaranteeing a short lead time.
6. By a rounded analysis of , 4 inch metal o rings is considered as a good in both .
7. The vigorous development of 4 inch metal o rings due to its features.
8. In order to cater to the requirements of customers, DMS Seals has developed 4 inch metal o rings with .
9. 4 inch metal o rings have always found a traditional use in the industries.
10. All defected 4 inch metal o rings will be picked up and not allowed to deliver to our customers.
11. The quality of 4 inch metal o rings can meet with .
12. Dms Seals Technology Co.,limited has great confidence in quality of 4 inch metal o rings and can send samples to customers.
13. Dms Seals Technology Co.,limited will have a stronger competitive advantage in the long term.
14. Taking an innovative approach based on scientific research, DMS Seals is able to develop 4 inch metal o rings and enhance its performance.
1. Installation Recommendation
2. Application and properties
Double acting seals, the sealing effect is achieved by the deformation of the section of the O-Rings, and the deformation is determined by the depth of the installation groove. Under pressure, the O-ring has a large surface tension like liquid, used for static sealing more. It is only recommended for better conditions in dynamic applications. System lubrication, pressure, temperature, sealing clearance, speed, medium and surface quality of metal parts determine the service life of O-Rings. It is not recommended if the lubrication is not sufficient during rotary motion.
3. Standard materials
NBR / FKM
4. Performance parameter
Static Seal | Dynamic Seal | |
Working Pressure | No support ring, up to 20MPa; With the support ring, up to 40MPa; With special support ring, up to 200MPa. | No support ring, up to 5MPa; With the support ring, higher pressure. |
Movement Speed | Maximum reciprocating speed up to 0.5m / s; maximum rotation speed up to 2.0m/s. | |
Temperature | NBR: -30℃ - 100℃; FKM: -20℃ - 220℃. | |
5. Wire Diameter Tolerance
Wire diameter of O-Ring (mm) | Tolerance (±mm) |
0-1.8 | 0.08 |
1.80-2.65 | 0.09 |
2.65-3.55 | 0.10 |
3.55-5.30 | 0.13 |
5.30-7.00 | 0.15 |
7.00-8.00 | 0.18 |
8.00-10.00 | 0.21 |
10.00-12.00 | 0.25 |
6. Inner diameter tolerance
Inner Diameter d1 mm | Tolerance ±mm | Inner Diameter d1 mm | Tolerance ±mm | Inner Diameter d1 mm | Tolerance ±mm |
0.70-2.50 2.50-4.50 4.50-6.30 | 0.13 0.14 0.15 | 43.70-45.00 46.00-46.20 46.20-47.50 | 0.42 0.43 0.44 | 95.00-97.50 97.50-100.00 100.00-103.00 | 0.83 0.84 0.87 |
6.30-8.50 8.50-10.00 10.00-11.20 | 0.16 0.17 0.18 | 47.50-48.70 48.70-50.00 50.00-51.50 | 0.45 0.46 0.47 | 103.00-106.00 106.00-109.00 109.00-112.00 | 0.89 0.91 0.93 |
11.20-14.00 14.00-16.00 16.00-18.00 | 0.19 0.20 0.21 | 51.50-53.00 53.00-54.50 54.50-56.00 | 0.48 0.50 0.51 | 112.00-115.00 115.00-118.00 118.00-122.00 | 0.95 0.97 1.00 |
18.00-20.00 20.00-21.20 21.20-23.60 | 0.22 0.23 0.24 | 56.00-58.00 58.00-60.00 60.00-61.50 | 0.52 0.54 0.55 | 122.00-125.00 125.00-128.00 128.00-132.00 | 1.03 1.05 1.08 |
23.60-25.00 25.00-26.50 26.50-28.00 | 0.25 0.26 0.28 | 61.50-63.00 63.00-65.00 65.00-67.00 | 0.56 0.58 0.59 | 132.00-136.00 136.00-140.00 140.00-145-00 | 1.10 1.13 1.17 |
28.00-30.00 30.00-31.50 31.50-33.50 | 0.29 0.31 0.32 | 67.00-69.00 69.00-71.00 71.00-73.00 | 0.61 0.63 0.64 | 145.00-150.00 150.00-155.00 155.00-160.00 | 1.20 1.24 1.27 |
33.50-34.50 34.50-35.50 35.50-36.50 | 0.33 0.34 0.35 | 73.00-75.00 75.00-77.50 77.50-80.00 | 0.66 0.67 0.69 | 160.00-165.00 165.00-170.00 170.00-175.00 | 1.31 1.34 1.38 |
36.50-37.50 37.50-38.70 38.70-40.00 | 0.36 0.37 0.38 | 80.00-82.50 82.50-85.00 85.00-87.50 | 0.71 0.73 0.75 | 175.00-180.00 180.00-185.00 185.00-190.00 | 1.41 1.44 1.48 |
40.00-41.20 41.20-42.50 42.50-43.70 | 0.39 0.40 0.41 | 87.50-90.00 90.00-92.50 92.50-95.00 | 0.77 0.79 0.81 | 190.00-195.00 195.00-200.00 200.00-206.00 | 1.51 1.55 1.59 |
206.00-212.00 212.00-218.00 224.00-230.00 | 1.63 1.71 1.75 | 325.00-335.00 335.00-345.00 345.00-355.00 | 2.43 2.49 2.56 | 500.00-515.00 515.00-530.00 530.00-545.00 | 3.54 3.63 3.72 |
230.00-236.00 236.00-243.00 243.00-250.00 | 1.79 1.83 1.88 | 355.00-365.00 365.00-375.00 375.00-387.00 | 2.62 2.68 2.76 | 545.00-560.00 560.00-580.00 580.00-600.00 | 3.81 3.93 4.05 |
250.00-258.00 258.00-265.00 265.00-272.00 | 1.93 1.98 2.02 | 387.00-400.00 400.00-412.00 412.00-425.00 | 2.84 2.91 2.99 | 600.00-615.00 615.00-630.00 630.00-650.00 | 4.13 4.22 4.34 |
272.00-280.00 280.00-290.00 290.00-300.00 | 2.08 2.14 2.21 | 425.00-437.00 437.00-450.00 450.00-462.00 | 3.07 3.15 3.22 | 650.00-670.00 | 4.46 |
300.00-307.00 307.00-315.00 315.00-325.00 | 2.25 2.30 2.37 | 462.00-475.00 475.00-485.00 485.00-500.00 | 3.30 3.37 3.45 |
Company Features
1. Characterized by , 4 inch metal o rings takes the lead in O Ring Manufacturer industry. Dms Seals Technology Co.,limited is increasing its capacity to meet up with larger needs for square section o ring sizes from our customers. As the prime rectangular o ring seal manufacturer, Dms Seals Technology Co.,limited is able to provide the best o ring seal groove dimensions .
2. Dms Seals Technology Co.,limited has a strong scientific research personnel, with rich experience and the production of innovative thinking. Dms Seals Technology Co.,limited has introduced and absorbed advanced technology for o ring seal manufacturers production. Dms Seals Technology Co.,limited sets up a professional R&D team for best 10 inch o ring . Dms Seals Technology Co.,limited has the strength to independently develop o ring seal material products.
3. We expect that DMS Seals brand will precede more than many businesses to direct the 3mm rubber o ring marketplace. Inquire! DMS Seals is always honest with colleagues and our partners. Inquire! We insist on continuously improving the quality of 52mm o ring . Inquire! Dms Seals Technology Co.,limited is well prepared to deal with all difficulties and challenges. Inquire! Dms Seals Technology Co.,limited wants to be one of the leading lip seal o ring provider in this field. Inquire!
