DMS Seals lead seal manufacturers o ring for piston and hydraulic cylinder

Company Advantages
1. Chemicals used in DMS Seals color do not include formaldehyde, chlorine bleach, carcinogenic and sensitizing dyes, all of which are known to be harmful to human health.
2. The entire manufacturing process of DMS Seals is strictly controlled. It may be divided into several important processes: the provision of working drawings, the selection&machining of raw materials, veneering, staining, and spray polishing.
3. DMS Seals goes through a series of production processes. They involve CAD/CAM design, prototyping, milling, turning, fabrication, welding, spraying, and commissioning.
4. DMS Seals is designed with a range of protection systems. It is built with overpressure, overload, electric circuits, and loss of voltage protection.
5. This product is regarded as a green and eco-friendly product. It contains no heavy metals which may cause pollution.
6. The product features water resistance. The fabrics used has good impermeability, which makes it behave well in case of torrential rain.
7. The product is portable. The materials used are extremely lightweight that can facilitate device portability without sacrificing strength.
8. This product has no electrical safety problem. A built-in protection system on the board helps avoid electric leakage.
9. The market prospects and development potential of this product is optimistic.
10. We have the professional QC team to secure the quality of lead seal manufacturers .
11. Dms Seals Technology Co.,limited's well-equipped facilities and excellent quality control throughout all stages of production enable us to guarantee total customer satisfaction.

1. Installation Recommendation

2. Installation Sizes

Rod Diameter d e8	Groove Diameter D H9	Groove Width L D10	H
20-30	d+8	7.5	7
31-35	d+8	7.5	7
36-44	d+8	8.5	8
45-55	d+10	11.0	10
56-119	d+15	13.0	12
120-319	d+20	17.0	16
320-499	d+30	21.0	20
＞499	d+40	26.5	25

3. Application and properties

Applicable to hydraulic cylinder piston rod, generally used in conjunction with the guide sleeve. The special-shaped Y-Ring has the sealing function, provides the elasticity to the seal ring, and compensates for the abrasion. Wear-resisting, non stick slip phenomenon. It has a high stability under pressure and harsh conditions.

4. Standard materials

Sealing ring: filled PTFE

Y-Ring: NBR / PU

5. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3 - 1600mm	0 - 60MPa	-30℃ +100℃	1 m/s	Petroleum base hydraulic oil, nonflammable hydraulic fluid, water, and others.

6. Installation Dimensions

Rod Dia.	Outer Dia.	Groove Width	Order No.
d e8	D H9	L D10
20 22 23	28 30 31	7.5 7.5 7.5	TDI20*28*7.5 TDI22*30*7.5 TDI23*31*7.5
25 28 30	33 36 38	7.5 7.5 7.5	TDI25*33*7.5 TDI28*36*7.5 TDI30*38*7.5
32 35 36	40 43 44	7.5 7.5 8.5	TDI32*40*7.5 TDI35*43*7.5 TDI36*44*8.5
40 42 45	48 50 55	8.5 8.5 11	TDI40*48*8.5 TDI42*50*8.5 TDI45*55*11
47 48 50	57 58 60	11 11 11	TDI47*57*11 TDI48*58*11 TDI50*60*11
52 55 56	62 65 71	11 11 13	TDI52*62*11 TDI55*65*11 TDI56*71*13
60 63 65	75 78 80	13 13 13	TDI60*75*13 TDI63*78*13 TDI65*80*13
68 70 72	78 85 87	13 13 13	TDI68*78*13 TDI70*85*13 TDI72*87*13
75 80 83	90 95 98	13 13 13	TDI75*90*13 TDI80*95*13 TDI83*98*13

Company Features
1. DMS Seals is so influential in the field of lead seal manufacturers that most people choose it. With its deep insights and leading innovations, Dms Seals Technology Co.,limited is uniquely positioned in rubber seal round field. Dms Seals Technology Co.,limited provides customers with one-stop dowty seal manufacturer including . Dms Seals Technology Co.,limited is a professional manufacture of seals manufacturer. Dms Seals Technology Co.,limited takes diaphragm seal manufacturer as the core businesses.
2. We are proud to acknowledge that we deal with clients located all over the world. Our clients are broad, covering a wide range of sizes and forms, including government agencies and non-profit organizations. Our manufacturing plant is equipped with advanced machinery including 3D design and CNC machines. These machines enable us to manufacture the highest quality products by adopting the latest manufacturing techniques. We have a team of dedicated management members. Based on their years of expertise and experience, they are able to put forward innovative management methods for the whole manufacturing process. The factory's production processes have been complying with the standards of the ISO 9001 system. This system is the foundation for us to carry out product development, design, manufacturing, quality control, packaging, and shipping. We have newly introduced a series of manufacturing facilities featuring a high automation level. They not only help achieve mass production but also guarantee consistent product quality.
3. Our ultimate goal is to become an internationally competitive exporter. Inquire! Years of development laid the foundation for Dms Seals Technology Co.,limited to establish a leading position in the hydraulic oil seal industry. Inquire! Our team ​​attaches great importance to the details of any quality or service. Inquire!
