DMS Seals piston rod seal for sale1

Company Advantages
1. DMS Seals is produced under a complete sophisticated production process, including forging and pressing, mechanical processing, cleaning, and surface treating.
2. DMS Seals is made from quality materials that come with written certification from the supplier stating it meets the flame resistance requirements and providing the lot number and test results.
3. The design of DMS Seals piston rod seal considers how thread count, fabric type and denier (fiber thickness) will affect the overall performance, and the decisions are made based on how this product will be used.
4. piston rod seal can be relatively , and provide features like .
5. The great operation of indicates the high performance of piston rod seal .
6. In order to control the influence of , our engineers especially design piston rod seal .
7. Once I pulled it hard to check its strength and hardness, I found that it was not deformed. It really surprised me. - One of our customers said.
8. The product is an integral part of people's daily life. It has greatly increased production efficiency and lowered the burden on operators.
9. The product is a perfect choice decorate bedroom. With its color, pattern and luxurious. This is recommended when you are considering bed linen in the bedroom.

1. Installation Recommendation

2. Application and properties

The standard combination seal is suitable for a wide range of pressure work and sliding high speed occasions. Low friction, strong wear resistance.

3. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM

4. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3 - 1600mm	0 - 35MPa	-30℃ +200℃	1.5 m/s	general hydraulic oil, water glycol Hydraulic oil and water emulsion type hydraulic oil.

5. Installation Dimensions

Nominal Size of Packing, and Housing dimensions				Order No.
d	D	H	L +0.2
3 4 5	6 7 8	2.3 2.3 2.3	2.5 2.5 2.5	SPNC3*6*2.5 SPNC4*7*2.5 SPNC5*8*2.5
6 7 8	9 10 11	2.3 2.3 2.3	2.5 2.5 2.5	SPNC6*9*2.5 SPNC7*10*2.5 SPNC8*11*2.5
9 10 10	12 13 14	2.3 2.3 3.0	2.5 2.5 3.2	SPNC9*12*2.5 SPNC10*13*2.5 SPNC10*14*3.2
11 11.2 12	15 15.2 16	3.0 3.0 3.0	3.2 3.2 3.2	SPNC11*15*3.2 SPNC11.2*15.2*3.2 SPNC12*16*3.2
12.5 14 15	16.5 18 19	3.0 3.0 3.0	3.2 3.2 3.2	SPNC12.5*16.5*3.2 SPNC14*18*3.2 SPNC15*19*3.2
16 18 20	20 22 24	3.0 3.0 3.0	3.2 3.2 3.2	SPNC16*20*3.2 SPNC18*22*3.2 SPNC20*24*3.2
20 21 22	24 25 26	3.0 3.0 3.0	3.2 3.2 3.2	SPNC20*24*3.2 SPNC21*25*3.2 SPNC22*26*3.2
22 22.4 24	28 28.4 30	4.4 4.4 4.4	4.7 4.7 4.7	SPNC22*28*4.7 SPNC22.4*28.4*4.7 SPNC24*30*4.7
25 25.5 26	31 31.5 32	4.4 4.4 4.4	4.7 4.7 4.7	SPNC25*31*4.7 SPNC25.5*31.5*4.7 SPNC26*32*4.7
28 29 29.5	34 35 35.5	4.4 4.4 4.4	4.7 4.7 4.7	SPNC28*34*4.7 SPNC29*35*4.7 SPNC29.5*35.5*4.7
30 31 31.5	36 37 37.5	4.4 4.4 4.4	4.7 4.7 4.7	SPNC30*36*4.7 SPNC31*37*4.7 SPNC31.5*37.5*4.7
32 34 35	38 40 41	4.4 4.4 4.4	4.7 4.7 4.7	SPNC32*38*4.7 SPNC34*40*4.7 SPNC35*41*4.7
35.5 36 38	41.5 42 44	4.4 4.4 4.4	4.7 4.7 4.7	SPNC35.5*41.5*4.7 SPNC36*42*4.7 SPNC38*44*4.7

Company Features
1. A solid foundation in piston rod seal field has been laid in Dms Seals Technology Co.,limited. DMS Seals brand is a globally famous piston seal hydraulic manufacturer. Dms Seals Technology Co.,limited is a model for Chinese hydraulic sealing solutions manufactures seeking to become known multinational brands. Dms Seals Technology Co.,limited is one of the earliest professional rod end seals manufacturers in China.
2. We have imported a wide range of brand-new facilities from some of the world-famous brands. So we are equipped with the latest and most cost-efficient technology for our production activities. We have a group of professionals. They have abundant knowledge and experience in developing, creating, and inventing new products for clients, as well as a deep understanding of market trends. We have set up a team of experts in production. They demonstrate their strong expertise in product design, manufacturing, overall production flow, and packaging. We are staffed by a team of highly skilled professionals. Owing to their proficiency and passion for their work, we have achieved specified production goals. We have an experienced resource purchasing team. With their many years of experience in materials purchases, they can control the purchase costs effectively while guaranteeing high-quality materials.
3. Our business philosophy is to provide our customers with the highest level of products and services. We constantly work with our clients by providing effective solutions and cost benefits. We actively promote the progress of projects in the field of environmental protection. We recycle and reuse most of the wastes and utilize the rest of the waste to generate energy, aiming to develop a cyclic economy. Integrity will become the heart and soul of our company's culture. In business activities, we will never cheat our partners, suppliers, and clients no matter what. We will always work hard to realize our commitment to them. The main current mission of our company is to increase customer satisfaction. Under this target, we continuously improve our product quality, update catalog, and strength timely communication with clients.
