DMS Seals pneumatic rod seals factory for sale

Company Advantages
1. The design of DMS Seals relies on different industrial cutting-edge techs. CAD pattern design tech, 2D/3D printing tech, and 3D digital human foot model collection tech have all adopted for the design.
2. DMS Seals is designed combining different subjects of knowledge. They include biomechanics, foot anatomy and movement, Weight Distribution System (WDS), and human's physiological structure development.
3. Several factors of DMS Seals have been taken into consideration. These factors cover softness, breathability, wear resistance, odor resistance, and hypoallergenic property.
4. DMS Seals has passed a series of quality tests. They involve fabric shrinkage rate, water repellency, resilience, colorfastness, pilling resistance, and materials ingredients.
5. The quality of DMS Seals is ensured. It is tested by the industry’s leading certification bodies, like THX® and ISF®, to achieve reference performance into every aspect of its fabrics.
6. It is antimicrobial. It contains antimicrobial silver chloride agents which inhibit the growth of bacteria and viruses and greatly reduce allergens.
7. The product runs stably with good electromagnetic compatibility. It does not emit levels of EM energy that cause electromagnetic interference in other devices in the vicinity.
8. It is smooth and soft. During the production, the raising process, which allows the fabric surface to treat with sharp teeth to lift the surface fibers thereby imparting hairiness and softness, is conducted.
9. The product is not affected by temperature. It has gone through high and low temperature treatment such as firing and cooling, thereby it has stable physical properties.
10. Our customers all appreciate the good moisture control and insulation performance of this product, and it can be used all-year-round.
11. The product can significantly offer the economic benefit of efficient energy use without sacrificing the features, performance, style, or convenience.
12. This multi-use product is designed with the objective of bringing convenience and safety to people, making people's life more efficient.
13. The product enables people to consume less time to finish their final goal or task. It is obvious that it plays an important role in improving people's overall efficiency.

1. Installation Recommendation

2. Installation Sizes

Rod Diameter	Outer Diameter	Groove Width	Install Chamfer	Radius	Radial Clearance                S max.
d f8	D H8	L+0.2	L1	R1	10MPa	20MPa	40MPa
50-69.9	d+15.0	7.5	5.0	0.4	0.5	0.4	0.3
70-149.9	d+20.0	10.1	6.0	0.4	0.7	0.5	0.4
200-244.9	d+25.0	12.5	8.5	0.4	0.8	0.6	0.5
245-519.9	d+30.0	15.0	10.0	0.8	0.9	0.7	0.6
520-769.9	d+35.0	17.5	13.0	1.2	1.0	0.8	0.7
770-1500	d+40.0	20.0	15.0	1.2	1.0	0.8	0.7

3. Application and properties

Applied for larger diameter piston rods and heavy-duty hydraulic rod sealing system in hard working conditions. High pressure resistance, excellent resistance to gap extrusion, wear-resisting.

4. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM



5. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3 - 1600mm	0 - 60MPa	-30℃ +100℃	5 m/s	hydraulic oil, flame retardant liquid, water, gas

6. Installation Dimensions

Rod Dia.	Outer Dia.	Groove Width	Order No.
d f8	D H8	L+0.2
50 60 70	65 75 85	7.5 7.5 7.5	GSJ-W50*65*7.5 GSJ-W60*75*7.5 GSJ-W70*85*7.5
75 80 100	95 100 120	10 10 10	GSJ-W75*95*10 GSJ-W80*100*10 GSJ-W100*120*10
110 115 120	130 135 140	10 10 10	GSJ-W110*130*10 GSJ-W115*135*10 GSJ-W120*140*10
130 140 145	150 160 165	10 10 10	GSJ-W130*150*10 GSJ-W140*160*10 GSJ-W145*165*10
150 160 170	170 180 190	10 10 10	GSJ-W150*170*10 GSJ-W160*180*10 GSJ-W170*190*10
175 180 200	195 200 220	10 10 10	GSJ-W175*195*10 GSJ-W180*200*10 GSJ-W200*220*10
230 240 250	255 265 275	12.5 12.5 12.5	GSJ-W230*255*12.5 GSJ-W240*265*12.5 GSJ-W250*275*12.5
260 265 270	285 290 295	12.5 12.5 12.5	GSJ-W260*285*12.5 GSJ-W265*290*12.5 GSJ-W270*295*12.5
280 290 300	305 315 325	12.5 12.5 12.5	GSJ-W280*305*12.5 GSJ-W290*315*12.5 GSJ-W300*325*12.5

Company Features
1. Since establishment, Dms Seals Technology Co.,limited has been interpreting high-quality pneumatic rod seals and services to the world. Dms Seals Technology Co.,limited has a profound impact on manufacturing hydraulic seal kits suppliers which is labeled high cost-performance ratio. DMS Seals now has become an internationally famous brand in the field of manufacturing hydraulic oil seal sizes . Dms Seals Technology Co.,limited has grown to be a leading Chinese maker of pneumatic seals . Dms Seals Technology Co.,limited is an expert provider of molded seals and has its own independent factory.
2. Dms Seals Technology Co.,limited has always set high demand on quality from material selection to package. Except professional employees, our advanced technology also contributes to the popularity of hydraulic cylinder seal kits . Dms Seals Technology Co.,limited has ensured the excellent quality of its products with its strong technical force.
3. Our mission is to provide the highest quality products and focus on timely delivery. We are committed to providing comprehensive services that exceed customer requirements with reliable management and committed production control. Inquire online! We connect everything – people, process, data, and things – and we use those connections to change our world for the better. We don’t just dream it, we do it every day. And we’re doing it faster than ever before, in ways no one else can. Inquire online! Dms Seals Technology Co.,limited aims to provide you with a competitive price system. Inquire online! We work to improve our use of raw materials, energy, and water in the manufacture of our products and provision of our services, and we will strive to reduce the emissions, discharges, and wastes that our operations generate.

DMS Seals pneumatic rod seals factory for sale

pneumatic rod seals

Type:
