DMS Seals seal pneumatics inc vendor for sale1

Company Advantages
1. According to different requirements of customers, the process used to manufacture DMS Seals is not the same, mainly including ordinary weaving, washing, dyeing, iron removal and so on.
2. We check the fabric of DMS Seals before production. It is evaluated according to weight, printing quality, defects and feel.
3. DMS Seals is designed according to the customer's wishes. It's color, font and form all meet the demands of the product to be packaged.
4. We adopt statistical quality control technology to ensure stable product quality.
5. Our strict quality control procedures ensure that our products are of good quality.
6. Quality and reliability are the basic characteristics of a product.
7. Till now this product has demonstrated a huge market prospect.
8. DMS Seals has obtained fame and reputation in seal pneumatics inc market.
9. With a high export growth rate, this product shows great market support.

1. Installation Recommendation

2. Installation Sizes

Rod Diameter    dN h9			Groove Diameter	Groove Width	Radius	Radial Clearance                S max.			O-Ring Cross-Section
Standard Application	Light Application	Heavy Duty Application	D1 H9	L1+0.2	R1	10MPa	20MPa	40MPa	d2
3-7.9	8-18.9	-	dN+4.9	2.2	0.4	0.3	0.20	0.15	1.78
8-18.9	19-37.9	-	dN+7.3	3.2	0.6	0.4	0.25	0.15	2.62
19-37.9	38-199.9	8-18.9	dN+10.7	4.2	1.0	0.4	0.25	0.20	3.53
38-199.9	200-255.9	19-37.9	dN+15.1	6.3	1.3	0.5	0.30	0.20	5.33
200-225.9	256-649.9	38-199.9	dN+20.5	8.1	1.8	0.6	0.35	0.25	7.00
256-649.9	650-999.9	200-255.9	dN+24.0	8.1	1.8	0.6	0.35	0.25	7.00
650-999.9	≥1000.0	256-649.9	dN+27.3	9.5	2.5	0.7	0.50	0.30	8.40
≥1000.0	-	650-999.9	dN+38.0	13.8	3.0	1.0	0.70	0.60	12.00

3. Application and properties

Applicable to high and low speed reciprocating motion environment, a wide range of fluids and high temperature condition. Suitable for larger gap of piston rod. Low friction, simple groove, be able to work in themedium with oil spots.

Meet the standard of GB/T 15242.3.



4. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM



5. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3 - 1600mm	0 - 60MPa	-45℃ +200℃	15 m/s	hydraulic oil, flame retardant liquid, water, gas



6. Installation Dimensions

Rod Dia.	Groove Dia.	Groove Width	Order No.	O-Ring Dimensions
DN h9	D1 H9	L1+0.2
20 20 22	27.3 30.7 29.3	3.2 4.2 3.2	GSI20*27.3*3.2 GSI20*30.7*4.2 GSI22*29.3*3.2	21.89*2.62 25.0*3.53 25.07*2.62
22 24 25	32.7 31.3 32.3	4.2 3.2 3.2	GSI22*32.7*4.2 GSI24*31.3*3.2 GSI25*32.3*3.2	26.57*3.53 26.64*2.62 28.24*2.62
25 26 28	35.7 36.7 35.3	4.2 4.2 3.2	GSI25*35.7*4.2 GSI26*36.7*4.2 GSI28*35.3*3.2	29.74*3.53 29.74*3.53 29.82*2.62
28 30 30	38.7 37.3 40.7	4.2 3.2 4.2	GSI28*38.7*4.2 GSI30*37.3*3.2 GSI30*40.7*4.2	32.92*3.53 32.99*2.62 34.52*3.53
32 32 35	39.3 42.7 42.3	3.2 4.2 3.2	GSI32*39.3*3.2 GSI32*42.7*4.2 GSI35*42.3*3.2	34.59*2.62 36.09*3.53 37.77*2.62
35 36 36	45.7 43.3 46.7	4.2 3.2 4.2	GSI35*45.7*4.2 GSI36*43.3*3.2 GSI36*46.7*4.2	37.69*3.53 39.34*2.62 40.87*3.53
38 38 40	48.7 53.1 50.7	4.2 6.3 4.2	GSI38*48.7*4.2 GSI38*53.1*6.3 GSI40*50.7*4.2	40.87*3.53 43.82*5.33 44.04*3.53

Company Features
1. Dms Seals Technology Co.,limited has accumulated enough experience and industry know-how. We are one of the major manufacturers and supplier of . Since inception, Dms Seals Technology Co.,limited has exhibited capacities for designing and manufacturing seal pneumatics inc . We are regarded as one of the most top-grade suppliers in the industry. Dms Seals Technology Co.,limited is a trustworthy manufacturer and supplier of . We have received a good reputation in the industry. Based in China, Dms Seals Technology Co.,limited is a famous manufacturing company specializing in design, development, manufacturing, sales, and distribution of . Dms Seals Technology Co.,limited is one of the leading manufacturers of in China. We have many years of experience in this particular line of business.
2. With the development of techniques, our high-end cheap oil seals can achieve finest quality. DMS Seals has extremely advanced technology. DMS Seals attaches great importance to the value of technical power. Integrating the finest technology and excellent staff together, DMS Seals has been always offering rod seals or piston seal with long lasting performance. Dms Seals Technology Co.,limited has a large number of high-level technicians, senior skilled workers and excellent management personnel.
3. Relying on service tenet of , we endeavor to do the best. Call! To serve our customers with heart and soul is what we should do in Dms Seals Technology Co.,limited. Call! Dms Seals Technology Co.,limited will continue to strive towards the goal of domestic first-class hydraulic cylinder gaskets company. Call!
