DMS Seals square o ring sizes for static sealing

Company Advantages
1. Dms Seals Technology Co.,limited insists on using first-class raw material.
2. The independent design of square o ring sizes provides guarantees for our own brand promotion at the source.
3. square o ring sizes takes an important role in area, due to its .
4. This product has good color retention. The dye molecules are tightly bound to the fibers so that they do not fall off the fibers.
5. The product has the advantage of overloading protection. It is equipped with an overload protection device to prevent the major components from being damaged due to overloading.
6. The product features good wear resistance. The structure is constructed with abrasion-proof materials and its surface has been treated with special method to prevent wear.
7. Mature sales network of DMS Seals will bring more convenience for customers.
8. Before delivery, square o ring sizes will conduct several rounds of strict tests for quality.
9. The crafts of square o ring sizes is exquisite which also ensures the high quality.
10. DMS Seals has enough capability to ensure the quality of square o ring sizes .
11. Dms Seals Technology Co.,limited has built long term business relationship with many overseas customers.

1. Installation Recommendation

2. Application and properties

Double acting seals, the sealing effect is achieved by the deformation of the section of the O-Rings, and the deformation is determined by the depth of the installation groove. Under pressure, the O-ring has a large surface tension like liquid, used for static sealing more. It is only recommended for better conditions in dynamic applications. System lubrication, pressure, temperature, sealing clearance, speed, medium and surface quality of metal parts determine the service life of O-Rings. It is not recommended if the lubrication is not sufficient during rotary motion.

3. Standard materials

NBR / FKM

4. Performance parameter

	Static Seal	Dynamic Seal
Working Pressure	No support ring, up to 20MPa; With the support ring, up to 40MPa; With special support ring, up to 200MPa.	No support ring, up to 5MPa; With the support ring, higher pressure.
Movement Speed	Maximum reciprocating speed up to 0.5m / s; maximum rotation speed up to 2.0m/s.
Temperature	NBR: -30℃ - 100℃;  FKM: -20℃ - 220℃.

5. Wire Diameter Tolerance

Wire diameter of O-Ring (mm)	Tolerance (±mm)
0-1.8	0.08
1.80-2.65	0.09
2.65-3.55	0.10
3.55-5.30	0.13
5.30-7.00	0.15
7.00-8.00	0.18
8.00-10.00	0.21
10.00-12.00	0.25



6. Inner diameter tolerance

Inner Diameter d1 mm	Tolerance ±mm	Inner Diameter d1 mm	Tolerance ±mm	Inner Diameter d1 mm	Tolerance ±mm
0.70-2.50 2.50-4.50 4.50-6.30	0.13 0.14 0.15	43.70-45.00 46.00-46.20 46.20-47.50	0.42 0.43 0.44	95.00-97.50 97.50-100.00 100.00-103.00	0.83 0.84 0.87
6.30-8.50 8.50-10.00 10.00-11.20	0.16 0.17 0.18	47.50-48.70 48.70-50.00 50.00-51.50	0.45 0.46 0.47	103.00-106.00 106.00-109.00 109.00-112.00	0.89 0.91 0.93
11.20-14.00 14.00-16.00 16.00-18.00	0.19 0.20 0.21	51.50-53.00 53.00-54.50 54.50-56.00	0.48 0.50 0.51	112.00-115.00 115.00-118.00 118.00-122.00	0.95 0.97 1.00
18.00-20.00 20.00-21.20 21.20-23.60	0.22 0.23 0.24	56.00-58.00 58.00-60.00 60.00-61.50	0.52 0.54 0.55	122.00-125.00 125.00-128.00 128.00-132.00	1.03 1.05 1.08
23.60-25.00 25.00-26.50 26.50-28.00	0.25 0.26 0.28	61.50-63.00 63.00-65.00 65.00-67.00	0.56 0.58 0.59	132.00-136.00 136.00-140.00 140.00-145-00	1.10 1.13 1.17
28.00-30.00 30.00-31.50 31.50-33.50	0.29 0.31 0.32	67.00-69.00 69.00-71.00 71.00-73.00	0.61 0.63 0.64	145.00-150.00 150.00-155.00 155.00-160.00	1.20 1.24 1.27
33.50-34.50 34.50-35.50 35.50-36.50	0.33 0.34 0.35	73.00-75.00 75.00-77.50 77.50-80.00	0.66 0.67 0.69	160.00-165.00 165.00-170.00 170.00-175.00	1.31 1.34 1.38
36.50-37.50 37.50-38.70 38.70-40.00	0.36 0.37 0.38	80.00-82.50 82.50-85.00 85.00-87.50	0.71 0.73 0.75	175.00-180.00 180.00-185.00 185.00-190.00	1.41 1.44 1.48
40.00-41.20 41.20-42.50 42.50-43.70	0.39 0.40 0.41	87.50-90.00 90.00-92.50 92.50-95.00	0.77 0.79 0.81	190.00-195.00 195.00-200.00 200.00-206.00	1.51 1.55 1.59
206.00-212.00 212.00-218.00 224.00-230.00	1.63 1.71 1.75	325.00-335.00 335.00-345.00 345.00-355.00	2.43 2.49 2.56	500.00-515.00 515.00-530.00 530.00-545.00	3.54 3.63 3.72
230.00-236.00 236.00-243.00 243.00-250.00	1.79 1.83 1.88	355.00-365.00 365.00-375.00 375.00-387.00	2.62 2.68 2.76	545.00-560.00 560.00-580.00 580.00-600.00	3.81 3.93 4.05
250.00-258.00 258.00-265.00 265.00-272.00	1.93 1.98 2.02	387.00-400.00 400.00-412.00 412.00-425.00	2.84 2.91 2.99	600.00-615.00 615.00-630.00 630.00-650.00	4.13 4.22 4.34
272.00-280.00 280.00-290.00 290.00-300.00	2.08 2.14 2.21	425.00-437.00 437.00-450.00 450.00-462.00	3.07 3.15 3.22	650.00-670.00	4.46
300.00-307.00 307.00-315.00 315.00-325.00	2.25 2.30 2.37	462.00-475.00 475.00-485.00 485.00-500.00	3.30 3.37 3.45

Company Features
1. Based on years of manufacturing experience, Dms Seals Technology Co.,limited has grown into a competitive manufacturer of in the industry. As a reliable manufacturer of based in China, Dms Seals Technology Co.,limited stands for reliability and outstanding quality the world over. Dms Seals Technology Co.,limited is a leading enterprise specializing in manufacturing . Our outstanding capability in this industry is well-known in the market. Having been providing for years, Dms Seals Technology Co.,limited is known as a professional and exceptional manufacturer in the market.
2. In the past years, we have received many honorable prizes in the industry. For instance, we have been awarded the title of "China Famous Exporter", which means that we are strong enough to serve overseas customers. We have imported a series of state-of-the-art manufacturing facilities. These facilities constantly underwent routine inspections and are maintained in good conditions. This will greatly support our whole production process. Our production equipment is arranged according to the principle of lean production. They enable us to maintain the highest levels of efficiency and quality throughout the production process from product design to custom protective containers.
3. We are marching forwards a more environmental-friendly and greener production way. We promise to eliminate any practices that will harm society and our environment. For example, during production, the waste will be carefully handled by our QC team. Over the years, Dms Seals Technology Co.,limited has improved credibility, customer satisfaction, and revenue. We are committed to creating business growth whilst ensuring that impact on the environment is minimized and that all activities are conducted safely by well-trained and qualified employees.

DMS Seals square o ring sizes for static sealing

square o ring sizes

Type:
