DMS Seals Top hyd cylinder seal kit company for pneumatic equipment

Company Advantages
1. Thanks to the design of hyd cylinder seal kit , our products are unequal in performance.
2. Our independent design for hyd cylinder seal kit can greatly help to improve our brand awareness.
3. hyd cylinder seal kit we produced is characterized by its its high quality and durability.
4. hyd cylinder seal kit is developed with high-performance materials.
5. The product features the desired safety. It has passed IEC 60335 electrical safety testing which aims to find any potential electric shock risks and fire hazards.
6. This product has excellent impact resistance. Its high compressibility and rebound resilience allow it to work under high-pressure mechanical movement.
7. The product functions properly in an environment with a certain level of electromagnetic disturbance. It won't be easily affected by other devices.
8. The product takes full advantage of the expertise of acoustics. The retractable seal on the top and bottom can effectively interlock together to achieve the desired acoustic seal.
9. The product can offer water that is clean and harmless. Its activated charcoal, with maximized number of pores, has largely widens its absorption surface to remove more pollutant molecules.
10. Using this product, people will be comfortable with their energy bills. They can save a lot of money spent on paying bills.
11. This product helps increase overall productivity. This means that it can help increase profits and cut labor costs in the meanwhile.
12. During the day, the translucency of the product provides a soft diffused naturally lit space that reduces the cost of indoor lighting.
13. A room that has this product is undoubtedly worthy of attention and praise. It will give a great visual impression to many guests.
14. When use this product, it is more convenient to sell a commodity as there is no need to spend extra costs on marketing.

1. Installation Recommendation

2. Application and properties

Extreme wear resistance, easy installation on single-part piston without assembly aids due to the split design of the sealing ring. Assembly on one-part piston is possible. Insensitive to extreme pressure peaks. Extreme high extreme pressure resistance. High pressure an large gaps due to the special compound properties of the seal ring. Dimensions according to ISO 7425-1. Short axial assembly length. Installation in closed and undercut housings. Additional sizes of machined products available on short notice.

3. Standard materials

Sealing ring: filled modified thermoplast

O-ring: NBR

4. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed
25 - 480mm	0 - 80MPa	-30℃ +110℃	≤1 m/s

5. Installation Dimensions

D1	d1	L	Order No.
25 32 40	16 21 26.3	4.2 4.2 5.8	OK25*16*4.2 OK32*21*4.2 OK40*26.3*5.8
40 50 50	29 34.5 36.3	4.2 6.3 5.8	OK40*29*4.2 OK50*34.5*6.3 OK50*36.3*5.8
50 50 55	37 39 44	8 4.2 4.2	OK50*37*8 OK50*39*4.2 OK55*44*4.2
55 60 60	44 41.7 49	4.2 7 4.2	OK55*44*4.2 OK60*41.7*7 OK60*49*4.2
63 63 63	44.7 47.5 52	7 6.3 4.2	OK63*44.7*7 OK63*47.5*6.3 OK63*52*4.2
70 70 70	51.7 54.5 54.5	7 6.3 6.3	OK70*51.7*7 OK70*54.5*6.3 OK70*54.5*6.3
70 75 75	59 54 59.5	4.2 8 6.3	OK70*59*4.2 OK75*54*8 OK75*59.5*6.3
80 80 85	59 64.5 64	8 6.3 8	OK80*59*8 OK80*64.5*6.3 OK85*64*8
90 90 95	69 74.5 74	8 6.3 8	OK90*69*8 OK90*74.5*6.3 OK95*74*8
100 100 105	79 84.5 84	8 6.3 8	OK100*79*8 OK100*84.5*6.3 OK105*84*8
110 110 115	89 94.5 94	8 6.3 8	OK110*89*8 OK110*94.5*6.3 OK115*94*8
115 120 125	100 99 104	8 8 8	OK115*100*8 OK120*99*8 OK125*104*8
125 130 130	109.5 109 114.5	6.3 8 6.3	OK125*109.5*6.3 OK130*109*8 OK130*114.5*6.3
130 135 135	115 114 119.5	8 8 6.3	OK130*115*8 OK135*114*8 OK135*119.5*6.3
140 140 145	119 125 124	8 8 8	OK140*119*8 OK140*125*8 OK145*124*8
150 150 152.4	129 135 131.5	8 8 8	OK150*129*8 OK150*135*8 OK152.4*131.5*8
160 160 165	139 148 144	8 8 8	OK160*139*8 OK160*148*8 OK165*144*8
170 175 180	149 154 159	8 8 8	OK170*149*8 OK175*154*8 OK180*159*8
190 200 210	169 179 189	8 8 8	OK190*169*8 OK200*179*8 OK210*189*8
220 220 230	199 205 209	8 8 8	OK220*199*8 OK220*205*8 OK230*209*8
240 250 260	225 229 239	8 8 8	OK240*225*8 OK250*229*8 OK260*239*8
270 280 290	249 255.5 271	8 8 9.5	OK270*249*8 OK280*255.5*8 OK290*271*9.5
300 320 330	272 292 302	9.5 9.5 9.5	OK300*272*9.5 OK320*292*9.5 OK330*302*9.5
350 370 420	322 342 392	9.5 9.5 9.5	OK350*322*9.5 OK370*342*9.5 OK420*392*9.5
450 480	422 452	9.5 9.5	OK450*422*9.5 OK480*452*9.5

Company Features
1. Dms Seals Technology Co.,limited is one of Chinese leading manufacturers for hyd cylinder seal kit . Dms Seals Technology Co.,limited is engaged in production and sales of pneumatic cylinder rod seal and is globally well recognized. Dms Seals Technology Co.,limited is the preferred brand hallite hydraulic seals manufacturer for business alliances!
2. In Dms Seals Technology Co.,limited, our seals for hydraulic pumps are of great quality. Dms Seals Technology Co.,limited has strong technical force and product development capability. DMS Seals attaches great importance to the quality of hydraulic packing kits . Dms Seals Technology Co.,limited has employed a group of technical talents with academic degrees.
3. With the tenet of , we are striving for the top-ranking brand. Get an offer! Customers can be totally assured of our quality and after-sale service for piston seals . Get an offer! The brand tenet of DMS Seals is an operation instruction to develop work. Get an offer! is the development tenet of our company. Get an offer! High quality is top list of Dms Seals Technology Co.,limited. Get an offer!
