DMS Seals viton rubber seal factory for pressure work and sliding high speed occasions

Company Advantages
1. The design of DMS Seals covers sophisticated steps. It includes information collecting of the latest furniture designs and trends, sketch drawing, sample making, assessment, and production drawing.
2. During the design of DMS Seals , a broad range of factors has been pondered. They include limb alignment, the stress put on the joints, walking posture, and weight distribution of the pelma.
3. The design of DMS Seals is carried out by professional apparel designers. It involves the fashion trends in the garment industry, aking styles, color mix, pattern, and fabric types into consideration.
4. Different factors have been taken into consideration during the design of DMS Seals . They are space planning, room layout, furniture layout, as well as the whole space integration.
5. DMS Seals is manufactured covering a few stages. It goes through the materials cutting, cleaning, molding, shaping, buffing, and finishing stages.
6. The product has the advantage of spalling resistance. It has the ability to undergo certain sharp temperature variations without failing.
7. The product has enough hardness. It can effectively resist scratching due to the friction or pressure from a sharp object.
8. The product cause no infection and microbial contamination. It will not leave any trace metal residue on the tissue of the body.
9. The product is heat resistant. Made of high quality metal materials, it is not prone to deformation when exposed in high temperatures.
10. The product features dimensional stability. Its size is not easy to make a change under mechanical force, heat or other external conditions.
11. This product is able to provide people's feet with comfort and support all day long. It offers an easy-walk experience for people.
12. This material will help make shoes that are able to withstand the different forces and conditions they will be exposed to during their lifetimes.
13. This product can help the wearer to make a statement and show off his or her original flair and individuality.

1. Installation Recommendation

2. Installation Sizes

Rod Diameter	Outer Diameter	Groove Width	Install Chamfer	Radius	Radial Clearance                S max.
d f8	D H8	L+0.2	L1	R1	10MPa	20MPa	40MPa
50-69.9	d+15.0	7.5	5.0	0.4	0.5	0.4	0.3
70-149.9	d+20.0	10.1	6.0	0.4	0.7	0.5	0.4
200-244.9	d+25.0	12.5	8.5	0.4	0.8	0.6	0.5
245-519.9	d+30.0	15.0	10.0	0.8	0.9	0.7	0.6
520-769.9	d+35.0	17.5	13.0	1.2	1.0	0.8	0.7
770-1500	d+40.0	20.0	15.0	1.2	1.0	0.8	0.7

3. Application and properties

Applied for larger diameter piston rods and heavy-duty hydraulic rod sealing system in hard working conditions. High pressure resistance, excellent resistance to gap extrusion, wear-resisting.

4. Standard materials

Sealing ring: filled PTFE

O-Ring: NBR / FKM



5. Working Conditions

Working  Conditions
Diameter Range	Pressure Range	Temperature Range	Speed	Medium
3 - 1600mm	0 - 60MPa	-30℃ +100℃	5 m/s	hydraulic oil, flame retardant liquid, water, gas

6. Installation Dimensions

Rod Dia.	Outer Dia.	Groove Width	Order No.
d f8	D H8	L+0.2
50 60 70	65 75 85	7.5 7.5 7.5	GSJ-W50*65*7.5 GSJ-W60*75*7.5 GSJ-W70*85*7.5
75 80 100	95 100 120	10 10 10	GSJ-W75*95*10 GSJ-W80*100*10 GSJ-W100*120*10
110 115 120	130 135 140	10 10 10	GSJ-W110*130*10 GSJ-W115*135*10 GSJ-W120*140*10
130 140 145	150 160 165	10 10 10	GSJ-W130*150*10 GSJ-W140*160*10 GSJ-W145*165*10
150 160 170	170 180 190	10 10 10	GSJ-W150*170*10 GSJ-W160*180*10 GSJ-W170*190*10
175 180 200	195 200 220	10 10 10	GSJ-W175*195*10 GSJ-W180*200*10 GSJ-W200*220*10
230 240 250	255 265 275	12.5 12.5 12.5	GSJ-W230*255*12.5 GSJ-W240*265*12.5 GSJ-W250*275*12.5
260 265 270	285 290 295	12.5 12.5 12.5	GSJ-W260*285*12.5 GSJ-W265*290*12.5 GSJ-W270*295*12.5
280 290 300	305 315 325	12.5 12.5 12.5	GSJ-W280*305*12.5 GSJ-W290*315*12.5 GSJ-W300*325*12.5
